Printer User Manual
Table Of Contents
- Copyright and Trademarks
- Contents
- Safety Instructions
- Getting to Know Your Printer
- Printer Features and Various Printing Options
- Paper Handling
- Using the Printer Software with Windows
- About the Printer Software
- Making Changes to Printer Settings
- Making the print quality settings
- Duplex printing
- Displaying information about consumables with the printer driver
- Ordering Consumables
- Resizing printouts
- Modifying the print layout
- Using a watermark
- Using headers and footers
- Using an overlay
- Using storage form overlay
- Making Extended Settings
- Making Optional Settings
- Printing a status sheet
- Using the Reserve Job Function
- Monitoring Your Printer Using EPSON Status Monitor
- Setting Up the USB Connection
- Canceling Printing
- Uninstalling the Printer Software
- Sharing the Printer on a Network
- Using the Printer Software with Macintosh
- Using the PostScript Printer Driver
- Using the PCL6/PCL5 Printer Driver
- Using the Control Panel
- Installing Options
- Replacing Consumable Products
- Cleaning and Transporting the Printer
- Troubleshooting
- Clearing Jammed Paper
- Printing a Status Sheet
- Operational Problems
- Printout Problems
- Color Printing Problems
- Print Quality Problems
- Memory Problems
- Paper Handling Problems
- Problems Using Options
- Correcting USB Problems
- Status and Error Messages
- Canceling Printing
- Printing in the PostScript 3 Mode Problems
- The printer does not print correctly in the PostScript mode
- The printer does not print
- The printer driver or printer that you need to use does not appear in the Printer Setup Utility (Mac OS 10.3.x and 10.4.x), Print Center (Mac OS 10.2.x), or Chooser (Mac OS 9)
- The font on the printout is different from that on the screen
- The printer fonts cannot be installed
- The edges of texts and/or images are not smooth
- The printer does not print normally via the USB interface
- The printer does not print normally via the network interface
- An undefined error occurs (Macintosh only)
- Insufficient memory to print data (Macintosh only)
- Customer Support
- Technical Specifications
- Index
Technical Specifications 292
EPSON AcuLaser C3800 User's Guide
Mechanical
Electrical
*
Values represent power consumption while all operations are completely suspended. Power consumption
varies depending on errors and operating conditions, and whether a type B interface card is installed or a
USB memory is inserted.
Standard and approvals
U.S. model:
Dimensions Height: 508 mm (20.0 in.)
Width: 420 mm (16.5 in.)
Depth: 501 to 575 mm (19.7 to 22.6 in.)
Weight Approx. 27.0 kg (about 59.4 lb) with Duplex Unit
Approx. 26.0 kg (about 57.2 lb) without Duplex Unit
(Excluding consumables and options)
120 V Model
KEAS-1
220-240 V Model
KEBS-1
Rated voltage 110 V-120 V ± 10% 220 V-240 V ± 10%
Rated frequency 50 Hz / 60 Hz ± 3 Hz 50 Hz / 60 Hz ± 3 Hz
Rated current Up to 8 A Up to 4 A
Power
consumption
During
printing
Average
(Color printing)
376 W 361 W
Average (Black
and white printing)
354 W 347 W
MAX 750 W
(with Duplex Unit)
730 W
(without Duplex
Unit)
750 W
(with Duplex Unit)
730 W
(without Duplex
Unit)
During standby mode 82 W 78 W
During sleep mode
*
Up to 17 W Up to 17 W
Safety UL60950-1
CAN/CSA-C22.2 No.60950-1
EMC FCC Part 15 Subpart B Class B
CAN/CSA-CEI/IEC CISPR 22 Class B
