USB interface
USB 2.0 High Speed mode
Note:
❏ Only computers equipped with a USB connector and running Windows Vista, Vista x64, XP, XP
x64, 2000, Server 2003, or Server 2003 x64, support the USB interface.
❏ Your computer must support USB 2.0 in order to use USB 2.0 as the interface to connect your
computer to the printer.
❏ Since USB 2.0 is fully compatible with USB 1.1, USB 1.1 can be used as an interface.
❏ USB 2.0 can be used with Windows Vista, Vista x64, XP, XP x64, 2000, Server 2003, and Server
2003 x64, operating systems.
Ethernet interface
You can use an IEEE 802.3 100BASE-TX/10 BASE-T straight-through shielded, twisted-pair interface
cable with an RJ45 connector.
Options and Consumable Products
Optional paper cassette unit
Product code/Model:
C12C802542 / L571AC1
*
Paper size: A3, A4, A5, B4, B5, Letter (LT), Legal (LGL)
Paper weight: 60 to 90 g/m (17 to 24 lb)
Paper feed: One paper cassette mounted
Automatic feed delivery system
Cassette capacity up to 500 sheets
Paper types: Plain paper
Power supply: DC 24 V / 1.7 A and DC 3.3 V / 0.1 A supplied by the printer
Dimensions and weight:
Height: 143 mm (5.6 in.)
EPSON AcuLaser M8000 Series User's Guide
Technical Specifications 234
