User’s Guide
Notations Used in This Guide • Safety indications The documentation and the projector use graphical symbols to show how to use the projector safely. Please understand and respect these caution symbols in order to avoid injury to persons or property. Warning This symbol indicates information that, if ignored, could possibly result in personal injury or even death due to incorrect handling.
Contents 3 Notations Used in This Guide . . . . . . . . . . . . . . . . . . . . . . . . 2 Basic Usage Projecting Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Introduction Projector Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 List of Functions by Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Quick and Easy Set up, Projection, and Storage . . . . . . . . . . . . . . . . . .
Contents 4 Security Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Managing Users (Password Protect) . . . . . . . . . . . . . . . . . . . . . . . . . . . . Kinds of Password Protect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Setting Password Protect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Entering the Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents 5 Appendix Optional Accessories and Consumables . . . . . . . . . . . . . . . . . . . . . . 87 Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87 Consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87 Screen Size and Projection Distance . . . . . . . . . . . . . . . . . . . . . . . . . 88 Projection Distance (For EB-W02/EB-W01) . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction This chapter explains the projector's features and the part names.
Projector Features 7 List of Functions by Model Available functions differ depending on the model being used. See the table below for a list of the functions available for each model.
Projector Features Quick and Easy Set up, Projection, and Storage • • • • Turn the projector on and off by simply plugging in or unplugging. Project onto large screens from a short distance. Make easy height adjustments with one lever. No cool down delay makes it easy to put away. Connecting with a USB cable and projecting (USB Display) By simply connecting a USB cable, you can project images from a computer's screen without a computer cable. s "Projecting with USB Display" p.
Projector Features • Control Panel Lock restricts button operation on the control panel You can use this to prevent people changing projector settings without permission at events, in schools, and so on. s "Restricting Operation (Control Panel Lock)" p.51 • Equipped with various anti-theft devices The projector is equipped with the following types of anti-theft security devices. • Security slot • Security cable installation point s "Anti-Theft Lock" p.
Part Names and Functions 10 All of the features in this guide are explained using illustrations of EB-W02 unless otherwise mentioned. Front/Top Name Function C Foot adjust lever Press the foot adjust lever to extend and retract the front adjustable foot. s "Adjusting the Image Position" p.36 D Front adjustable foot When setup on a surface such as a desk, extend the foot to adjust the position of the image. s "Adjusting the Image Position" p.
Part Names and Functions 11 Name Rear Name Function A Remote receiver Receives signals from the remote control. B Power inlet Connects the power cable to the projector. s "From Installation to Projection" p.26 C Video port (EB-X14G/EB-W02/EBX02/EB-S02 only) Inputs composite video signals from video sources. D Security slot The security slot is compatible with the Microsaver Security System manufactured by Kensington. s "Anti-Theft Lock" p.
Part Names and Functions 12 Base Name Function A Ceiling mount fixing points (three points) Attach the optional Ceiling Mount here when suspending the projector from a ceiling. s "Installing the Projector" p.19 s "Optional Accessories" p.87 B Rear feet When setup on a surface such as a desk, turn to extend and retract to adjust the horizontal tilt. s "Adjusting the Horizontal Tilt" p.
Part Names and Functions 13 Name Control Panel Name Function A [t] button Turns the projector power on or off. s "From Installation to Projection" p.26 B [Source Search] button Changes to the next input source that is sending an image. s "Automatically Detect Input Signals and Change the Projected Image (Source Search)" p.27 C [Enter] button [ ] • When the Configuration menu or the Help screen is displayed, it accepts and enters the current selection and moves to the next level.
Part Names and Functions Name 14 Function G [a][b] buttons or [Wide][Tele] buttons • For EB-X14G/EB-W02/EB-X02/EB-W01 [a] Decreases the volume. [b] Increases the volume. s "Adjusting the Volume" p.37 • For EB-S02/EB-S01 [Wide]: Enlarges the size of the projected image. [Tele]: Reduces the size of the projected image. s "Adjusting the Image Size" p.36 • EB-X14G only Corrects keystone distortion in the horizontal direction when the Keystone screen is displayed. s "H/V-Keystone (EB-X14G only)" p.
Part Names and Functions Name 15 Function A [t] button Turns the projector power on or off. s "From Installation to Projection" p.26 B [Computer] button Changes to images from the Computer port. C [Video] button Each time the button is pressed, the input changes between images from the S-Video port to the Video port. (EB-X14G/EB-W02/EB-X02/EB-S02 only) D Numeric buttons Enter the Password. s "Setting Password Protect" p.
Part Names and Functions Name 16 Function O [Help] button Displays and closes the Help screen which shows you how to deal with problems if they occur. s "Using the Help" p.65 P [Freeze] button Images are paused or unpaused. s "Freezing the Image (Freeze)" p.43 Q [Volume] buttons [a][b] [a] Decreases the volume. [b] Increases the volume. s "Adjusting the Volume" p.37 R [Pointer] button Displays the on-screen pointer. s "Pointer Function (Pointer)" p.
Part Names and Functions Caution Check the positions of the (+) and (-) marks inside the battery holder to ensure the batteries are inserted the correct way. c Replace the battery cover. Press the battery compartment cover until it clicks into place.
Preparing the Projector This chapter explains how to install the projector and connect projection sources.
Installing the Projector 19 Installation Methods Warning The projector supports the following four different projection methods. Install the projector according to the conditions of the installation location. • Project images from in front of the screen. (Front projection) • Project images from behind a translucent screen. (Rear projection) • A special method of installation is required when suspending the projector from a ceiling (ceiling mount).
Installing the Projector • Install the projector so that it is parallel to the screen. If the projector is installed at an angle to the screen, keystone distortion occurs in the projected image. • Place the projector on a level surface. If the projector is tilted the projected image is also tilted. 20 a When you correct keystone distortion, the projected image may be reduced.
Installing the Projector EB-S02/EB-S01 21
Connecting Equipment 22 Illustrations in this section are of EB-W02. The port name, location, and connector orientation differ depending on the source being connected. Connecting a Computer To project images from a computer, connect the computer using one of the following methods. A When using the supplied or commercially available computer cable Connect the computer's display output port to the projector's Computer port.
Connecting Equipment 23 Connecting Image Sources To project images from DVD players or VHS video and so on, connect to the projector using one of the following methods. A When using a commercially available video or S-video cable (EB-X14G/EB-W02/EB-X02/EB-S02 only) Connect the video output port on the image source to the projector's Video port. Or, connect the S-video output port on the image source to the projector's S-Video port.
Connecting Equipment 24 Attention • If the input source is on when you connect it to the projector, it could cause a malfunction. • If the orientation or shape of the plug differs, do not try to force it in. The device could be damaged or could malfunction. a • If the source you want to connect to has an unusually shaped port, use the cable supplied with the device or an optional cable to connect to the projector.
Basic Usage This chapter explains how to project and adjust images.
Projecting Images From Installation to Projection This section explains the procedure for connecting the projector to a computer with the computer cable and projecting images. 26 f Change the computer's screen output. When using a laptop computer, you need to change the screen output from the computer. Hold down the Fn key (function key), and press the b key. a The method for changing differs depending on the computer being used. See the documentation supplied with the computer.
Projecting Images 27 Automatically Detect Input Signals and Change the Projected Image (Source Search) Press the [Source Search] button to project images from the port currently receiving an image. Using the remote control Using the control panel * (EB-X14G/EB-W02/EB-X02/EB-S02 only) When two or more image sources are connected, press the [Source Search] button until the target image is projected. When your video equipment is connected, start playback before beginning this operation.
Projecting Images 28 Switching to the Target Image by Remote Control You can change directly to the target image by pressing the following buttons on the remote control. Remote control Projecting with USB Display You can use a USB cable to connect the projector to a computer to project images from the computer. You can send the computer's audio with the projected image. To start USB Display, set USB Type B to USB Display from the Configuration menu. s Extended - USB Type B p.
Projecting Images 29 Amount of Memory 256 MB or more Recommended: 512 MB or more Hard Disk Space 20 MB or more Display Resolution of no less than 640x480 and no higher than 1600x1200. Display color in 16-bit color or greater Connecting for the first time The first time you connect the projector and the computer using the USB cable, the driver needs to be installed. The procedure is different for Windows and Mac OS. a *1 Service Pack 4 only *2 Except for Service Pack 1 For Mac OS OS Mac OS X 10.
Projecting Images c d Computer images are projected. It may take a while before computer images are projected. Until computer images are projected, leave the equipment as it is and do not disconnect the USB cable or turn off the power to the projector. Disconnect the USB cable when you finish projection. When disconnecting the USB cable, there is no need to use Safely Remove Hardware. a • If it is not installed automatically, double-click My Computer - EPSON_PJ_UD - EMP_UDSE.EXE on your computer.
Projecting Images For Windows XP a b c Click Start, and then click Control Panel. Double-click Add or Remove Programs. Select Epson USB Display and click Remove. For Windows Vista/Windows 7 a b c Click Start, and then click Control Panel. Click Uninstall a program under Programs. Select Epson USB Display and click Uninstall. For Mac OS a b Open the Applications folder, double-click USB Display, and then double-click Tool. Run USB Display UnInstaller.
Adjusting Projected Images Correcting Keystone Distortion 32 • Correcting manually (Quick Corner) (EB-X14G only) Manually correct the four corners independently. You can correct keystone distortion using one of the following methods. • Correcting automatically (Auto V-Keystone) (EB-X14G/EB-W02/EB-X02/ EB-S02 only) Automatically corrects vertical keystone distortion. • Correcting manually (V-Keystone) (EB-W02/EB-X02/EB-S02/EB-W01/ EB-S01 only) Manually corrects vertical keystone distortion.
Adjusting Projected Images a 33 • Auto V-Keystone works only when Projection is set to Front from the Configuration menu. s Extended - Projection p.61 • If you do not want to enable Auto V-Keystone, set Auto VKeystone or Auto Keystone to Off. s Settings - Keystone - H/V-Keystone - Auto V-Keystone p.59 s Settings - Auto Keystone p.59 Correcting manually You can manually correct keystone distortion. • You can use V-Keystone to correct the projected image under the following conditions.
Adjusting Projected Images 34 a Press the [Menu] button while projecting. s "Using the Configuration Menu" p.55 Using the remote control Press the [a] or [b] buttons to correct horizontal distortion. a Using the control panel b Select Keystone from Settings. c Select Quick Corner, and then press the [ You can also set H/V-Keystone from the Configuration menu. s Settings - Keystone - H/V-Keystone p.
Adjusting Projected Images d e 35 Using the [ ], [ ], [ ], and [ ] buttons on the remote control, or the [w], [v], [a], and [b] buttons on the control panel, select the corner to correct, and then press the [ ] button. Using the [ ], [ ], [ ], and [ ] buttons on the remote control, or the [w], [v], [a], and [b] buttons on the control panel, correct the position of the corner. When you press the [ displayed. ] button, the screen shown in step 4 is If the message "Cannot adjust any further.
Adjusting Projected Images a 36 If the [Esc] button is held down for about two seconds while the corner selection screen from step 4 is displayed, the following screen is displayed. Reset Quick Corner: Resets the result of Quick Corner corrections. Switch to H/V-Keystone: Switches the correction method to H/V-Keystone. s "Settings Menu" p.59 Adjusting the Image Position Adjusting the Image Size EB-X14G/EB-W02/EB-X02/EB-W01 Press the foot adjust lever to extend and retract the front adjustable foot.
Adjusting Projected Images Adjusting the Horizontal Tilt Extend and retract the rear feet to adjust the projector's horizontal tilt. 37 Adjusting the Volume You can adjust the volume using one of the following methods. • Press the [Volume] button on the control panel or the remote control to adjust the volume. [a] Decreases the volume. [b] Increases the volume. Using the remote control Using the control panel (EB-X14G/EB-W02/EB-X02/EB-W01 only) A Extend the rear foot. B Retract the rear foot.
Adjusting Projected Images Mode Dynamic 38 Application Ideal for use in a bright room. This is the brightest mode, and reproduces shadow tones well. Presentation Ideal for making presentations using color materials in a bright room. Theatre Ideal for watching films in a dark room. Gives images a natural tone. Photo*1 Ideal for projecting still pictures, such as photos, in a bright room. The images are vivid and brought into contrast. Sports *2 Ideal for watching TV programmes in a bright room.
Adjusting Projected Images 39 Changing methods Each time you press the [Aspect] button on the remote control, the aspect mode name is displayed on the screen and the aspect ratio changes. Remote control c d Select On. The setting is stored for each Color Mode. a You can set the aspect ratio from the Configuration menu. s Signal - Aspect p.58 Press the [Menu] button to finish making settings. a Changing the aspect mode Auto Iris can only be set when the Color Mode is Dynamic or Theatre.
Adjusting Projected Images 40 B 16:9 Projecting images from a computer The following shows projection examples for each aspect mode. EB-W02/EB-W01 Aspect Mode Input Signal XGA 1024X768(4:3) Normal A B C D E Normal 16:9 16:9 Full Zoom Native Full Projecting images from video equipment (for EB-X14G/EB-X02/EB-S02/EB-S01) Each time the [Aspect] button is pressed, the aspect mode changes in the order 4:3 and 16:9.
Adjusting Projected Images Aspect Mode 41 Input Signal XGA 1024X768(4:3) WXGA 1280X800(16:10) Native EB-X14G/EB-X02/EB-S02/EB-S01 Aspect Mode Input Signal XGA 1024X768(4:3) WXGA 1280X800(16:10) Normal 4:3 16:9 a If parts of the image are missing, set the Resolution setting to Wide or Normal from the Configuration menu, according to the size of the computer panel. s Signal - Resolution p.
Useful Functions This chapter explains useful tips for giving presentations, and the Security functions.
Projection Functions Hiding the Image and Sound Temporarily (A/V Mute) You can use this when you want to focus the audience's attention on what you are saying, or if you do not want to show details such as when you are changing between files during presentations from a computer. 43 Freezing the Image (Freeze) When Freeze is activated on moving images, the frozen image continues to project on the screen, so you can project a moving image one frame at a time like a still photo.
Projection Functions 44 a a Display the Pointer. Each time you press the [Pointer] button, the pointer appears or disappears. Remote control b Move the Pointer icon ( ). Remote control When any pair of adjacent [ ], [ ], [ ], or [ ] buttons are pressed at the same time, the pointer can be moved diagonally. You can select the shape of the pointer icon from the Configuration menu. s Settings - Pointer Shape p.
Projection Functions 45 Enlarging Part of the Image (E-Zoom) b This is useful when you want to expand images to see them in greater detail, such as graphs and tables. a Remote control ) to the area of the image that you want to enlarge. Remote control When any pair of adjacent [ ], [ ], [ ], or [ ] buttons are pressed at the same time, the pointer can be moved diagonally. Start E-Zoom. Press the [z] button to display the Cross ( Move the Cross ( ). c Enlarge.
Projection Functions 46 Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse) Once set, the mouse pointer can be controlled as follows. Moving the mouse pointer [ You can control the computer's mouse pointer from the projector's remote control. This function is called Wireless Mouse. ][ ][ ][ ] buttons: Moves the mouse pointer. The following operating systems are compatible with Wireless Mouse.
Projection Functions a • When any pair of adjacent [ 47 ], [ ], [ ], or [ ] buttons are pressed at the same time, the pointer can be moved diagonally. • If the mouse button settings are set to reverse on the computer, the operation of the remote control buttons will also be reversed. • The Wireless Mouse function does not work under the following conditions.
Projection Functions a • When User's Logo Protect from Password Protect is set to On, a message is displayed and the User's Logo cannot be changed. You can make changes after setting User's Logo Protect to Off. s "Managing Users (Password Protect)" p.49 48 e When you press the [ ] button and the message "Select this image?" is displayed, select Yes. f Select the zoom factor from the zoom setting screen. g When the message "Save this image as the User's Logo?" is displayed, select Yes.
Security Functions The projector has the following enhanced security functions. • Password Protect You can limit who can use the projector. • Control Panel Lock You can prevent people changing the settings on the projector without permission. s "Restricting Operation (Control Panel Lock)" p.51 • Anti-Theft Lock The projector is equipped with the following anti-theft security device. s "Anti-Theft Lock" p.
Security Functions b 50 Select the type of Password Protect you want to set, and then press the [ ] button. Remote control (4) c Select On, and then press the [ d Set the password. ] button. Press the [Esc] button, the screen displayed in step 2 is displayed again. Entering the Password When the password entry screen is displayed, enter the password using the remote control.
Security Functions Attention • If an incorrect password is entered three times in succession, the message "The projector's operation will be locked." is displayed for approximately five minutes, and then the projector switches to standby mode. If this happens, disconnect the power plug from the electrical outlet and then reinsert it and turn the projector's power back on. The projector displays the password entry screen again so that you can enter the correct password.
Security Functions d Select Yes when the confirmation message is displayed. The control panel buttons are locked according to the setting you chose. a You can release the control panel lock by one of the following two methods. • Select Off from Control Panel Lock. s Settings - Control Panel Lock p.59 • Press and hold down the [ ] button on the control panel for about seven seconds, a message is displayed and the lock is released.
Monitoring and Controlling ESC/VP21 Commands 53 The main contents are listed below. Item You can control the projector from an external device using ESC/VP21. Power ON/OFF Connect the projector to the computer with the USB cable. Signal selection On PWR ON Off PWR OFF Computer Before starting a Install the USB communication driver (EPSON USB-COM Driver) to your computer.
Configuration Menu This chapter explains how to use the Configuration menu and its functions.
Using the Configuration Menu This section explains how to use the Configuration menu. Although steps are explained using the remote control as an example, you can perform the same operations from the control panel. Check the guide under the menu for the available buttons and their operations. a b 55 c Select a submenu item. d Change settings. e Press the [Menu] button to finish making settings. Display the Configuration menu screen. Select a top menu item.
List of Functions 56 Top Menu Name Configuration Menu Table Image menu s p.57 Signal menu s p.
List of Functions Top Menu Name Reset menu s p.63 57 Submenu Name Items or Setting Values Source - Input Signal - Resolution - Video Signal - Refresh Rate - Sync Info - Status - Serial Number - Reset All - Reset Lamp Hours - s "Automatically Detect Input Signals and Change the Projected Image (Source Search)" p.27 *1 The number of supported languages differs depending on the region where the projector is used.
List of Functions Submenu 58 Function Color Adjustment (This item cannot be selected if Color Mode is set to sRGBg.) You can adjust the color strength for Red, Green, and Blue individually. Auto Iris (This item can be set only if Color Mode is set to Dynamic or Theatre.) Set to On to adjust the iris to obtain the optimum light for images being projected. The setting is stored for each Color Mode. s "Setting Auto Iris" p.
List of Functions Submenu 59 Function Progressive (This setting can only be adjusted when a component video with an interlaced signal (480i/576i/1080i) is input.) Interlaceg (i) signal is converted to Progressiveg (p). (IP conversion) On: Ideal for still images. Off: Ideal for images with a large amount of movement. Input Signal You can select input signal from Computer port. If set to Auto, the input signal is set automatically according to the connected equipment.
List of Functions Submenu 60 Function Control Panel Lock You can use this to restrict operation of the projector's control panel. s "Restricting Operation (Control Panel Lock)" p.51 Pointer Shape You can select the shape of the pointer. Submenu User Button You can select and assign an item from the Configuration menu with the remote control's [User] button.
List of Functions 61 Submenu Extended Menu Submenu Display User's Logo *1 Projection Select from one of the following projection methods depending on how the projector is installed. Front, Front/Ceiling, Rear, and Rear/Ceiling You can change the setting as follows by pressing down the [A/V Mute] button on the remote control for about five seconds. FrontWFront/Ceiling RearWRear/Ceiling s "Installation Methods" p.
List of Functions Submenu Reset 62 Function You can reset the adjustment values for Display*1 and Operation*2 from the Extended menu to their default settings. See the following to return all menu items to their default settings. s "Reset Menu" p.63 s "Automatically Detect Input Signals and Change the Projected Image (Source Search)" p.27 *1 When User's Logo Protect is set to On in Password Protect, settings related to user's logo cannot be changed.
List of Functions Submenu Serial Number * 63 Function Displays the projector's serial number. The cumulative use time is displayed as "0H" for the first 10 hours. 10 hours and above is displayed as "10H", "11H", and so on. Reset Menu Submenu Function Reset All You can reset all items in the Configuration menu to their default settings. The following items are not reset to their defaults: Input Signal, User's Logo, Lamp Hours, Language, Password, Zoom (EBS02/EB-S01 only), and User Button.
Troubleshooting This chapter explains how to identify problems and what to do if a problem is found.
Using the Help 65 If a problem occurs with the projector, the Help screen is displayed to assist you by pressing the Help button. You can solve problems by answering the questions. a c Confirm the selection. Using the remote control Using the control panel Press the [Help] button. The Help screen is displayed. Using the remote control Using the control panel Questions and solutions are displayed as shown on the screen below. Press the [Help] button to exit the Help. b Select a menu item.
Problem Solving 66 If you are having a problem with the projector, first check the projector's indicators and refer to "Reading the Indicators" below. See the following if the indicators do not show clearly what the problem might be. s "When the Indicators Provide No Help" p.69 Reading the Indicators The projector is provided with the following three indicators that indicate the operating status of the projector. A Power indicator Indicates the operating status.
Problem Solving 67 Refer to the following table to see what the indicators mean and how to remedy problems that they indicate. If all indicators are off, check that the power cable is connected correctly and that the power is being supplied normally. Sometimes, when the power cable is unplugged, the [t] indicator remains lit for a short period, but this is not a fault.
Problem Solving Status 68 Cause Remedy or Status If the lamp is not cracked: Reinstall the lamp and turn on the power. If the error continues: Replace the lamp with a new one and then turn on the power. If the error continues: Stop using the projector, remove the power plug from the electrical outlet, and contact your local dealer or the nearest address provided in the Epson Projector Contact List.
Problem Solving 69 When the Indicators Provide No Help If any of the following problems occur and the indicators do not offer a solution, refer to the pages given for each problem. Problems Relating to Images s p.70 • No images appear Projection does not start, the projection area is completely black, or the projection area is completely blue. • Moving images are not displayed Moving images being projected from a computer appear black and nothing is projected. s p.
Problem Solving 70 Problems Relating to Images No images appear Check Remedy Did you press the [t] button? Press the [t] button to turn the power on. Are the indicators switched off? The power cable is not connected correctly or power is not being supplied. Connect the projector's power cable correctly. s "From Installation to Projection" p.26 Check that your electrical outlet or power source is functioning correctly.
Problem Solving 71 Moving images are not displayed (only the moving image portion turns black) Check Is the computer's image signal being output to the LCD and the monitor? (Only when projecting images from a laptop computer or a computer with a built-in LCD screen) Remedy Change the image signal from the computer to external output only. Check your computer's documentation, or contact the computer's manufacturer.
Problem Solving 72 Check Are the image signals being output to the projector? (Only when projecting images from a laptop computer or a computer with a built-in LCD screen) Remedy If the image signals are only being output to the computer's LCD monitor or to the accessory monitor, you need to change the output to an external destination as well as the computer's own monitor.
Problem Solving 73 Interference or distortion appear in images Check Remedy Is the image signal format setting correct? (Only when projecting images from a video source) Change the setting according to the signal for the connected equipment. s Signal - Video Signal p.58 Are the cables connected correctly? Check that all the cables required for projection are securely connected. s "Connecting Equipment" p.
Problem Solving 74 Check Remedy Is the computer set for dual display? (Only when projecting computer images) If dual display is activated in the Display Properties of the computer's Control Panel, only about half of the image on the computer screen is projected. To display the entire image on the computer screen, turn off the dual display setting.
Problem Solving 75 Images appear dark Check Remedy Is the image brightness set correctly? Adjust the Brightness and Power Consumption settings from the Configuration menu. s Image - Brightness p.57 s Settings - Power Consumption p.59 Is the contrastg adjusted correctly? Adjust the Contrast setting from the Configuration menu. s Image - Contrast p.57 Is it time to replace the lamp? When the lamp is nearly ready for replacement, the images become darker and the color quality becomes poorer.
Problem Solving 76 Check Is the correct setting for the remote receiver selected? Remedy Check the Remote Receiver from the Configuration menu. s Settings - Remote Receiver p.59 Other Problems No sound can be heard or the sound is faint Check Remedy Check that the audio/video cable is securely attached to both the projector and audio source. (EB-X14G/EB-W02/EB-X02/EB-S02 only) Disconnect the cable from the Audio port, and then reconnect the cable.
Problem Solving 77 Check Remedy Is direct sunlight or strong light from fluorescent lamps shining onto Set the projector up in a location where strong light does not shine onto the remote receiver. Or set the remote receiver to the remote receiver? Off from Remote Receiver in the Configuration menu. s Settings - Remote Receiver p.59 Is the correct setting for the Remote Receiver selected? Check the Remote Receiver from the Configuration menu. s Settings - Remote Receiver p.
Maintenance This chapter provides information on maintenance procedures to ensure the best level of performance from the projector for a long time to come.
Cleaning You should clean the projector if it becomes dirty or if the quality of projected images starts to deteriorate. Attention 79 Attention Do not rub the lens with harsh materials or subject the lens to shocks, as it can easily become damaged. Turn off the projector's power before cleaning. Cleaning the Air Filter Cleaning the Projector's Surface Clean the projector's surface by wiping it gently with a soft cloth.
Cleaning a 80 • If a message is frequently displayed, even after cleaning, it is time to replace the air filter. Replace it with a new air filter. s "Replacing the Air Filter" p.84 • It is recommended that you clean these parts at least once every three months. Clean them more often than this if using the projector in a particularly dusty environment.
Replacing Consumables This section explains how to replace the lamp and the air filter. 81 • The projected image gets darker or starts to deteriorate. Attention Replacing the Lamp Lamp replacement period It is time to replace the lamp when: • The following message is displayed. "Time to replace the lamp. Please contact your Epson projector reseller or visit www.epson.com to purchase.
Replacing Consumables 82 Warning • When replacing the lamp because it has stopped illuminating, there is a possibility that the lamp may be broken. If replacing the lamp of a projector which has been installed on the ceiling, you should always assume that the lamp is cracked, and you should stand to the side of the lamp cover, not underneath it. Remove the lamp cover gently. • Never disassemble or remodel the lamp.
Replacing Consumables 83 e Install the new lamp. Insert the new Lamp along the guide rail in the correct direction so that it fits in place, push in firmly, and once it is fully inserted tighten the two screws. ① ② d Take out the old Lamp by pulling the handle. If the Lamp is cracked, replace it with a new lamp, or contact your local dealer for further advice.
Replacing Consumables f Replace the lamp cover. 84 Replacing the Air Filter Air filter replacement period If the message is displayed frequently even though the air filter has been cleaned, replace the air filter. How to replace the air filter The air filter can be replaced even when the projector is suspended from a ceiling. Attention • Make sure you install the lamp securely. If the lamp cover is removed, the power turns off automatically as a safety precaution.
Replacing Consumables c 85 Remove the air filter. Grip the air filter cover tab and pull it straight out. e d Install the new air filter. Slide the air filter from the outside and press in until it firmly clicks into place. Close the air filter cover. a Dispose of used air filters properly in accordance with your local regulations.
Appendix
Optional Accessories and Consumables The following optional accessories and consumables are available. Please purchase these products as and when needed. The following list of optional accessories and consumables is current as of: May 2011. Details of accessories are subject to change without notice and availability may vary depending on the country of purchase. Optional Accessories Interactive Unit ELPIU01 Use when operating the computer screen on the projection surface.
Screen Size and Projection Distance 88 A Projection Distance (For EB-W02/EB-W01) 4:3 Screen Size Minimum (Wide) to Maximum (Tele) B 60" 120x91 190 - 229 -13 70" 142x107 222 - 267 -15 80" 160x120 255 - 306 -17 100" 200x150 319 - 383 -22 150" 300x230 480 - 577 -33 200" 410x300 641 - 770 -44 280" 570 x 430 898 - 1079 -61 Unit: cm A 16:9 Screen Size A Projection distance B Distance from the center of the lens to the base of the screen (or to the top of the screen, if suspende
Screen Size and Projection Distance 89 Unit: cm A 16:10 Screen Size Minimum (Wide) to Maximum (Tele) B 35" 76x47 97 - 117 -7 40" 86x54 111 - 134 -8 50" 110x67 139 - 168 -10 60" 130x81 168 - 202 -12 80" 170x110 225 - 270 -15 100" 220x130 281 - 338 -19 150" 320x200 424 - 509 -29 200" 430x270 566 - 680 -38 320" 690 x 430 907 - 1089 -62 Projection Distance (For EB-X14G/EB-X02) A Projection distance B Distance from the center of the lens to the base of the screen (or to
Screen Size and Projection Distance 90 A 4:3 Screen Size Minimum (Wide) to Maximum (Tele) B 60" 120x91 180 - 217 -10 80" 160x120 241 - 290 -14 100" 200x150 302 - 363 -17 150" 300x230 454 - 546 -25 200" 410x300 607 - 729 -34 250" 510x380 759 - 912 -42 300" 610x460 912 - 1095 -51 Projection Distance (For EB-S02/EB-S01) Unit: cm A 16:9 Screen Size Minimum (Wide) to Maximum (Tele) B 30" 66x37 97 - 117 1 40" 89x50 130 - 156 1 50" 110x62 163 - 196 1 60" 130x75 19
Screen Size and Projection Distance 4:3 Screen Size 91 A B Minimum (Wide) to Maximum (Tele) (Wide) 70" 142x107 207 - 280 -12 80" 160x120 237 - 321 -13 100" 200x150 297 - 401 -17 150" 300x230 446 - 603 -25 200" 410x300 595 - 805 -33 Unit: cm 16:9 Screen Size A B Minimum (Wide) to Maximum (Tele) (Wide) 30" 66x37 96 - 130 1 50" 110x62 161 - 218 1 60" 130x75 193 - 262 2 70" 155x87 226 - 306 2 80" 180x100 258 - 349 2 100" 220x120 323 - 437 3 150" 330x190
Supported Monitor Displays 92 For EB-S02/EB-S01 Supported Resolutions Computer signals (analog RGB) For EB-X14G/EB-W02/EB-X02/EB-W01 Signal Refresh Rate (Hz) Resolution (dots) VGA 60/72/75/85 640x480 SVGA 56/60/72/75/85 800x600 XGA 60/70/75/85 1024x768 WXGA 60 1280x768 60 1360x768 60/75/85 1280x800 WXGA+ 60/75/85 1440x900 SXGA 70/75/85 1152x864 60/75/85 1280x1024 60/75/85 1280x960 60/75 1400x1050 60 1680x1050 UXGA 60 1600x1200 MAC13" 67 640x480 MAC16" 75 832x624
Supported Monitor Displays 93 Signal Refresh Rate (Hz) Resolution (dots) SDTV (480p) 60 720x480 SDTV (576p) 50 720x576 HDTV (720p) 50/60 1280x720 HDTV (1080i) 50/60 1920x1080 Composite video (EB-X14G/EB-W02/EB-X02/EB-S02 only) Signal Refresh Rate (Hz) Resolution (dots) TV (NTSC) 60 720x480 TV (SECAM) 50 720x576 TV (PAL) 50/60 720x576
Specifications 94 Projector General Specifications EB-X14G Product name EB-W02 EB-X02 0.55" LCD panel size 0.59" Wide 0.55" EB-S01 0.59" Wide 0.55" 1,024,000 pixels WXGA (1280 (W)x 800 (H) dots)x 3 480,000 pixels SVGA (800 (W) x 600 (H) dots) x 3 Manual (1 to 1.2) Digital (1 to 1.35) 2W 2W 0.
Specifications 95 S-Video port *1 1 Mini DIN 4-pin Audio Input port *1 1 RCA pin jack x 2 USB(TypeB) port *2 1 USB connector (Type B) *1 EB-X14G/EB-W02/EB-X02/EB-S02 only. *2 Supports USB 2.0. However, USB ports are not guaranteed to operate all devices that support USB.
Specifications This product is also designed for IT power distribution system with phase-to-phase voltage 230V. Angle of tilt If you use the projector tilted at an angle of more than 30˚ it could be damaged and cause an accident.
Specifications 97 DECLARATION of CONFORMITY According to 47CFR, Part 2 and 15 Class B Personal Computers and Peripherals; and/or CPU Boards and Power Supplies used with Class B Personal Computers We: Located at: Tel: Epson America, Inc. 3840 Kilroy Airport Way MS: 3-13 Long Beach, CA 90806 562-290-5254 Declare under sole responsibility that the product identified herein, complies with 47CFR Part 2 and 15 of the FCC rules as a Class B digital device.
Appearance A B 98 Center of lens Distance from center of lens to suspension bracket fixing point Units: mm
Glossary 99 This section briefly explains the difficult terms that are not explained in the text of this guide. For details, refer to other commercially available publications. Aspect Ratio The ratio between an image's length and its height. Screens with a horizontal:vertical ratio of 16:9, such as HDTV screens, are known as wide screens. SDTV and general computer displays have an aspect ratio of 4:3.
Glossary 100 VGA A screen size standard with a resolution of 640 (horizontal) x 480 (vertical) dots. XGA A screen size standard with a resolution of 1,024 (horizontal) x 768 (vertical) dots.
General Notes All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation. No patent liability is assumed with respect to the use of the information contained herein. Neither is any liability assumed for damages resulting from the use of the information contained herein.
Index A 102 D A/V Mute ...................................................... 43 Air exhaust vent ........................................... 10 Air filter replacement period ..................... 84 Aspect ...................................................... 39, 59 Auto Iris .................................................. 38, 58 Auto Keystone .............................................. 59 Auto Setup .................................................... 58 Auto V-Keystone ..........................
Index Power On Protect ........................................ Presentation .................................................. Problem Solving ........................................... Progressive .................................................... Projection ...................................................... 103 49 38 66 59 61 Q Quick Corner ............................................... 59 S 61 61 94 92 11 62 58 Temp indicator ............................................ Test Pattern .....
