Product Information 231
Chapter 7
Product Information
Printer Specifications
Printing
Printable area
Printing method On-demand ink jet
Nozzle
configuration
Black: 180 nozzles × 3
(Photo Black or Matte Black, Light Black, Light Light Black)
Color: 180 nozzles × 5
(Cyan, Vivid Magenta, Light Cyan, Vivid Light Magenta,
Yellow)
A Roll paper The minimum top margin is 0.12 in. (3.0 mm)
A Cut sheets
B-L Roll paper The minimum left margin is 0 in. (0 mm)
B-L Cut sheets
B-R Roll paper The minimum right margin is 0 in. (0 mm)
B-R Cut sheets
C Roll paper The minimum bottom margin is 0.12 in. (3.0 mm)
C Cut sheets The minimum bottom margin is 0.55 in. (14.0 mm)
A
B-L B-R
C
