CI F I C AT I O N fo IONS • S S P E O AT C r WEB CERTIFIED SYSTEM F FS ET PUB L I Certified – June, 2004 ColorBurst RIP for Epson Stylus Pro Edition 3800 4800 7800 9800 ® Printed in USA CPD-20261R1 GETTING STARTED
Getting Started The enclosed CD includes the advanced ColorBurst® RIP server software and client PPD (PostScript® Printer Description) software, as well as the SpectralVision™ utility for printer linearization. Before setting up the ColorBurst RIP, see your Epson Stylus® Pro manual to set up the Stylus Pro printer on the computer that will run the RIP server. To set up the RIP server, double-click the installer icon and follow the on-screen instructions.
Once the RIP server is installed and set up, see the appropriate section to set up client systems for printing: ■ “Mac OS X Clients Printing to a Mac OS X RIP Server” below “Mac OS X Clients Printing to a Windows RIP Server” on page 3 ■ “Windows Clients Printing to a Windows RIP Server” on page 5 ■ “Windows Clients Printing to a Mac OS X RIP Server” on page 6 ■ Note: For a reliable connection, make sure client computers are on the same subnet as the ColorBurst RIP server computer.
7. Open the Printer Setup Utility in the Applications > Utilities folder. 8. Click Add. In Mac OS X 10.4.x, the ColorBurst RIP print server name appears in the list. In Mac OS X 10.3.x, select Rendezvous from the pop-up menu. 9. Select the ColorBurst RIP print server name from the Bonjour or Rendezvous printers. 10. Make sure ColorBurst Epson RIP is selected in the Printer Model or Print Using list.
3. Double-click the CD-ROM icon, then double-click the ColorBurst Client Installer icon. 4. Enter your Mac OS X Admin password, then click OK. 5. Follow the on-screen instructions to install the ColorBurst client software. 6. When installation is complete, check the ColorBurst RIP server computer to make sure ColorBurst is running. 7. Open the Printer Setup Utility in the Applications > Utilities folder. 8. Click Add. If you are using Mac OS X 10.4.x, click More Printers. 9.
Note: If the Windows server has a firewall enabled, you may need to enter a user name and password. Contact your network administrator for assistance or see your Windows Help for more information. 14. Click Add to add the printer. You see the ColorBurst RIP Print Server name in the printer list. Tip: To rename the printer, highlight the name of the ColorBurst RIP, click Show Info, type a new name, then click Apply Changes. 15. Close the Printer Setup Utility. You’re ready to print to the ColorBurst RIP.
5. Select Browse for a printer (Windows XP) or Type your printer name (Windows 2000), then click Next. 6. Browse the network and select the ColorBurst RIP printer, then click Next. Click Yes to continue. 7. If you want to use the ColorBurst RIP as your default printer, choose Yes. If not, choose No. Click Next. 8. Click Finish when you see a screen telling you that setup is complete. You’re ready to print to the ColorBurst RIP.
6. Make sure the Local printer attached to this computer button is selected and Automatically detect and install my Plug and Play printer is unchecked. Then click Next. 7. Click Create a new port, select Standard TCP/IP Port, and click Next. 8. When you see the Add Standard TCP/IP Print Port Wizard screen, click Next. 9. Enter the IP address for the Macintosh that is running the ColorBurst RIP server (located under System Preferences > Network settings), then click Next.
16. Click Finish to close the Add Standard TCP/IP Printer Port Wizard. 17. At the next screen, click Have Disk, then click Browse. 18. Browse to the folder that you unzipped. Click ColorBurst Epson.INF. 19. Click Open to return to the Install from Disk window. 20. Click OK. 21. Select ColorBurst, then click Next. 22. Leave the default name or enter a new name in the Printer name box. Then click Next. 23. Follow the on-screen instructions to install the software. 24.
