EPSON Stylus CX3100/3200 Revision A
PRODUCT DESCRIPTION Overview 10
NOTE: The product is Energy Star compliant.
NOTE: The holding current to the motors is reduced when the printer has stayed
in non-operation status for 5 minutes.
NOTE: The Scanner lamp is turned off when the Scanner has stayed in non-
operation status for 15 minutes.
1.1.2.2 Interface
In compliance with USB (Universal Serial Bus) Revision 1.1
Connector
USB Series B
1.1.2.3 Conformity to Safety and EMC Standards
1.1.2.4 Environmental Conditions
Temperature
Operating
10
~
35 °C
Non-operating
-20
~
60 °C (In the shipment container.)
NOTE: 1 month at 40 °C or 120 hours at 60 °C
Humidity (no condensation)
Operating
20
~
80%RH
Non-operating
5
~
85%RH (In the shipment container.)
Resistance to physical shock
Operating
1 G, 1 x 10
-3
second
Non-operating
2 G, 2 x 10
-3
second (In the shipment container.)
Resistance to physical vibration
Operating
0.15 G
Non-operating
0.50 G (In the shipment container.)
Table 1-2. Conformity to Safety and EMC Standards
100 V Model 120 V Model 220-240 V Model
Safety -
• UL1950
• CSA22.2 No.950
• EN 60950
EMC
• VCCI Class B
•
Guideline for the Suppression
of Harmonics in Household
and General-Use Equipment
• FCC part15
subpart B class B
• CSA C108.8 class
B
• EN 55022 (CISPR
Pub.22) class B
• EN 55024
• EN 61000-3-2
• EN 61000-3-3
• AS/NZS 3548
Class B
