4.5 Disassembly and Assembly of Printer Unit
Flowchart 4-3. Disassembly Procedure for Printer Unit
Carriage concerned
Paper feeding concerned
Other parts
Panel Unit Removal (p.41)
START
Scanner Unit Removal (p.42)
ASF Unit Removal (p54)
Power Unit (p56)
Middle Housing Removal (p.43)
Disassembly of ASF Unit (p55)
Carriage Unit (p51)
CR Scale (p50)
Printhead (p53)
Front Frame Assembly (p57)
Front Paper Guide (p57)
Waste Liquid Pad (p58)
