10
10 | Introduction
Options and Accessories
Your Epson Stylus
®
Pro 7800/9800 offers these optional upgrades and
accessories:
* Designed for use with heavy media, which can damage the printer’s built-in
cutter.
In addition, you can order these user-replaceable items:
Optional equipment
Option Part number
EpsonNet Internal 10/100 BaseTX (Ethernet
™
) Type-B
Print Server (interface card)
C12C824341
Automatic Take-Up Reel System (Stylus Pro 9800 only) C12C815251
Replacement 44-inch Take-up Reel Core
(Stylus Pro 9800 only)
C815121
Paper Roller Spindle (Normal Tension) — 2- or 3-inch
Epson Stylus Pro 7800:
Epson Stylus Pro 9800:
C12C811161
C12C811151
Paper Roller Spindle (High Tension) — 2- or 3-inch
Epson Stylus Pro 7800:
Epson Stylus Pro 9800:
C12C811155
C12C811152
Manual Media Cutting System*
Epson Stylus Pro 7800:
Epson Stylus Pro 9800:
C12C815231
C815182
Replacement Manual Cutting Blade (for Manual Media
Cutting System)
C815192
One-year extended warranty EPP7898B1
Two-year extended warranty EPP7898B2
Tip: Check the Epson Pro
Graphics web site at
http://prographics.epson.
com for accessories and
options that are currently
available.
Consumables and user-replaceable parts
Part Part number
Replacement Ink Maintenance Tank (see page 141) C12C890191
Replacement Printer Cutter Blade (see page 138) C12C815291
Ink Cartridges See page 128 for a
complete listing.
