Feature
Dec.
10 cpi
0
Hex.
00
12 cpi
1
01
proportional
2
02
condensed
4 04
emphasized
8 08
double-strike
16
10
double-wide
32 20
italics
64
40
underline
128 80
For example, to print a title, you may want to use double-wide 12
cpi characters and print them in double-strike mode. You add three
numbers together to calculate the value of
IZ:
12
cpi
1
Double-strike 16
Double-wide
32
n
= 49
After calculating the value of
IZ,
you use the Master Select command
to send the value to the printer.
ASCII:
ESC !
1
Decimal: 27 33 49
Hexadecimal:
1B
21 31
The print quality and font must be set separately, either using
SelecType or the ESC x and ESC k commands. There are two more
things to consider when using the Master Select command:
l Master Select cancels any of the listed features that you do not
try to set. For example, if you have already set a character size
other than 10 cpi and you use Master Select to set emphasized
double-strike, the character width is reset to 10 cpi.
l Proportional overrides 10, 12, and 15 cpi.
Using Software and Graphics
