Commands in Numerical Order
The following list shows control codes and ESC sequences (with
their decimal and hexadecimal values), and the page number where
the complete command description can be found.
ASCII
Dec. Hex Description
Page
BEL
7
07
BS
8
08
HT
9 09
LF 10 0A
VT
11 0B
FF
12 0C
CR 13 0D
so
14 0E
SI
15 0F
DC1
17 11
DC2
18 12
DC3
19 13
DC4 20 14
CAN
24 18
DEL 127 7F
ESC SO 14 0E
ESC SI 15 OF
ESC EM
25 19
ESC SP 32 20
ESC !
33 21
ESC
#
35 23
ESC
$
36 24
ESC %
37 25
ESC & 38 26
ESC
*
42 2A
ESC
(-
40 28
ESC +
43 2B
ESC
-
45 2D
Command Summary
Beeper
..........................................................
8-12
Backspace
...................................................
8-19
Tab
horizontally ....................................... .8-20
Line feed
.................................................... .8-14
Tab vertically
.............................................
8-17
Form feed
....................................................
8-13
Carriage return
..........................................
8-12
Select double-wide mode (1 line).
..........
.8-25
Select condensed mode
........................... .8-24
Select printer
................................................
8-8
Cancel condensed mode ......................... .8-25
Deselect
printer ........................................... .8-9
Cancel double-wide mode (1 line).
........
.8-26
Cancel line
................................................. .8-12
Delete character
.......................................... .8-9
Select double-wide mode (1 line)............8-25
Select condensed mode
........................... .8-24
Cut sheet feeder mode
............................. .8-10
Set
intercharacter
space
........................... .8-30
Master Select
............................................. .8-22
Cancel MSB control
..................................
.8-11
Set absolute
print position ...................... .8-19
Select user-defined set
............................. .8-33
Define user-defined
characters
...............8-32
Select
graphics
mode
............................... .8-35
Select Line
.................................................. .8-29
Select
n/360-inch line spacing.. ...............8-16
Turn underlining on/off ......................... .8-29
8-5
