ESC Y
Select High-Speed Double-Density Graphics Mode
Format:
ASCII code:
ESC Y nl
n2
Decimal:
27 89
nl
n2
Hexadecimal: 1B 59 nl
n2
Comments:
Turns on 8-pin, high-speed, double-density graphics mode. The total
number of columns = n3 +
(n2
X 256).
ESC Z
Select Quadruple-Density Graphics Mode
Format:
ASCII code:
ESC Z
nl
n.2
Decimal :
27 90
nl
L!
Hexadecimal: 1B 5A
nl
n2
Comments:
Turns on 8-pin, quadruple-density graphics mode. The total number of
columns =
n7
+
(n2
X 256).
ESC*
Select Graphics Mode
Format:
ASCII code:
ESC *
m
nl
a2
Decimal:
27 42
m
nl
n2
Hexadecimal: 1B 2A
m
nl
n.2
Comments:
Turns on graphics mode m. See the following table for details on the
available modes. The total number of columns = nl +
(n2
X 256).
Command Summary
8-35
