Ribbon:
MCBF:
MTBF:
Print head life:
Dimensions and weight:
Voltage:
Power consumption:
Frequency:
Insulation resistance:
Black ribbon cartridge
#7762:
Life expectancy (in Letter Quality
characters, at 48 dots/character): 3 million
Color ribbon cartridge
#7763:
Life expectancy (in Letter Quality
characters, at
48
dots/character)
Black:
1.0 million
Cyan:
0.7
million
Magenta:
0.7
million
Yellow
0.5
million
Film ribbon cartridge #7764:
Life expectancy (at 10 cpi, with bi-
directional printing, using
136
columns):
0.1
million*
* This number may vary depending on
print direction, characters per inch, or
text density per page.
For all components excluding print head:
5
million lines
6000 power-on hours (at
25%
duty)
200 million strokes per wire
Height: 7.7”
Width:
26.6"
Depth:
20.4"
Weight :
approx. 44 lbs
120
VAC
f
10%
400
watts maximum
49.5 to 60.5 Hz
10M ohms between AC power line and chassis
Dielectric strength (between AC line and chassis):
Can withstand
1.00
kV rms applied for one
minute or
1.2
kV
rms applied for one second.
Technical Specifications
A-5
