Temperature:
Humidity:
Operation:
40°F to 95°F
(ST
to 35°C)
Storage:
-22°F to 140°F (-30°C to 60°C)
Operation:
10% to 80%
(without
condensation)
Storage:
5%
to
85%
(without condensation)
Shock:
Operation: Up to
1
G within
1 ms
Storage: Up to
2
G within
1 ms
Vibration:
Operation: Up to
0.25
G at up to
55 Hz
Storage: Up to 0.50 G at up to 55 Hz
Double-Bin Cut Sheet Feeder (Optional)
Dimensions and weight:
26.7”(W) X 22.9”(D) x 16.5”(H)
(mounted on the printer)
approx.
13.2
lbs.
Bin capacity:
bin
1
Single
sheets: Up to
150
sheets of
22
lb. paper
Up to
185
sheets of
17
lb. paper
(Total thickness should not
exceed 0.59” or 15mm)
Envelopes* :
Up to
25
(plain and bond type)
Up to 30 (air mail)
bin 2
Single sheets: Up to
150
sheets of
22
lb. paper
Up to
185
sheets of
17
lb. paper
(Total thickness should not exceed
0.59” or
15mm)
* Envelopes can only be used in bin
1.
A-6
Technical Specifications
