Paper
Width
Length
Thickness
Weight:
Printable
area:
Single sheet
envelope
bin 1 and bin 2
bin 1
7.17” to 14.3”
6.50” to 9.49”
(182mm to 364mm)
(166mm to 241mm)
8.27” to 14.3”
3.62” to 4.09”
(210mm to 364mm)
(92mm to 104mm)
0.0028” to 0.0039”
0.0063” to 0.0205”
(0.07mm to O.lmm)
(0.16mm to 0.52mm)
17 to 22 lb. paper 12 to 24 lb. paper
8.5 mm (0.33”) or more
3 mm
(0.12”)
)r more
or more
13.5 mm
/0.53”J
or more
T
or more
I, 22 mm
It
3 mm
(0.12”!
or more
1
(0.87”)
or
more
A-8
Technical Specifications
