These three kinds of initialization have slightly different effects. In
particular, ESC @ resets
the
typestyle to the current SelecType setting;
the other two methods reset the typestyle according to the default
settings selected by the SelecType settings. Also, ESC @ does not
initialize the printer mechanism, clear
the
input data buffer, or clear the
user-defined character set.
Default Settings
The following table shows the default conditions
that
become valid when
the printer is initialized.
I Item
I
Reset to:
I
Top of form position
Left and right margins
Line spacing
Vertical tab positions
Horizontal tab positions
VFU channel
Font selection
User-defined characters
Current paper position
SelecType setting
l/6-inch line spacing
Cleared
Every eight characters
Channel 0
Reset to the current SelecType setting
Hardware: Cleared
Software: Deselected only
In addition, the data buffer is cleared when the printer is initialized by
turning on the power or by sending an INIT signal.
Note: The user-defined character set is not cleared when the
printer is initialized by ESC @.
