Specifications Sheet

Model Code:
ECC604T-C
Product:
60cm Touch Control
Ceramic Cooktop
Features
4 zones
Front touch controls
9 stage power setting
Automatic safety switch o
Fremeless glass
Product dimensions
Packaged (w, d, h mm):
→ 640 × 552 × 102mm
Physical (w, d, h mm):
→ 590 × 520 × 55mm
Weight:
→ 9.8kg
Cleaning
Durable ceramic glass
Single piece of glass
Warranty
24 Months
Accessories
Sealing strip
(attached to c/top underside)
Safety
Residual heat indicator lights
Child lock function
Requirements
Rated Voltage:
→ 220-240V, 50/60 Hz
Hard-wired installation
Maximum Power:
→ 6000W
→ 30 AMP
Burner outputs (KW)
2 × 1.8kW radiant zones
2 × 1.2kW radiant zones
↑ Product ↑ Installation
