SE-D1 USER’S MANUAL P/N: M32002-02A2
The team at Escient would like to take this opportunity to thank you for purchasing an Escient FireBall product. Escient is committed to providing our customers the most technologically advanced, yet easierthan-ever to use products that converge the power of the Internet with home entertainment. To maximize your enjoyment, please take a few minutes to review this User’s Manual. It will guide you through all the features and benefits of your new FireBall.
24 24 REGISTRATION 26 WATCHING DVD MOVIES 27 LISTENING TO MUSIC 30 TESTING A BROADBAND CONNECTION BROWSING YOUR MOVIE LIBRARY PLAYING THE CURRENT MOVIE SELECTING A DIFFERENT MOVIE Movie Info CHANGING THE GUIDE VIEW View By Title View By Cover VIEWING BY GENRE BROWSING YOUR MUSIC LIBRARY SHOW AND HIDE TRACKS PLAYING THE CURRENT TITLE SELECTING A DIFFERENT SONG CHANGING THE GUIDE VIEW View By Artist View By Title View By Song View By Cover CHANGING THE CURRENT PLAY MODE VIEWING BY GENRE LISTENING TO
EXTERNAL CONTROL SURROUND MODE SETTINGS IR REMOTE CONTROL DIRECT ACCESS CODES PLAYLIST HOT KEYS BUTTON OVERLAY FIREBALL UTILITIES GETTING INFORMATION ABOUT YOUR FIREBALL RESTARTING THE SYSTEM UPDATING THE SOFTWARE CONTROLLING FIREBALL FROM A WEB BROWSER SETTING UP THE FIREBALL WEB SERVER USING THE WEB USER INTERFACE PAGE 4 62 63 64 65 66 66 67 68 69 70 71 NETWORKED AUDIO USING FIREBALL MUSIC CLIENTS 83 72 ESCIENT TECHNICAL SUPPORT 87 TROUBLESHOOTING 88 ADDITIONAL INFORMATION 89 89 89 89 89 89
PRODUCT INTRODUCTION Thank you for purchasing a FireBall Media Management system from Escient (a division of D&M Holdings). ABOUT THIS MANUAL This FireBall User’s Manual is intended to provide the reader with an overview of the main features and benefits of the Escient FireBall Media Management Systems. For more information, please refer to the Escient web site (www.escient.com) or contact your Escient dealer. RECORD YOUR SERIAL NUMBER The serial number for this unit is located at the rear of the device.
FireBall™ SE-D1 User’s Manual WARNINGS AND PRECAUTIONS • Do not use this apparatus near water. • Clean only with a dry cloth. • Do not block any ventilation openings. • Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. • To reduce the risk of electric shock, do not remove the cover. No user serviceable parts are inside. Refer servicing to qualified service personnel.
TRADEMARKS & SERVICE MARKS Escient®, the Escient logo, and FireBall® are trademarks of Digital Networks North America. FireBall and Physital are trademarks of Escient®. Other product names mentioned herein are used for identification purposes only and may be trademarks of their respective companies. Music recognition technology and related data are provided by Gracenote®. Gracenote is the industry standard in music recognition technology and related content delivery. For more information visit www.
WARRANTY INFORMATION Terms of Coverage - Each Escient branded media management system sold comes with a standard one (1) year warranty. This warranty provides no-charge coverage under normal product usage, for a period of one year from the date of registration and/or purchase (whichever is earlier). This warranty program provides the following key features and benefits: • Twelve (12) months service, parts and labor. • Five (5) day turn around time on all standard in-warranty repairs.
• • • • Additionally, Escient does not cover the following items under the terms or its warranty programs: Installation or removal charges. Cost of initial technical adjustments (setup costs). Battery replacement. Escient’s sole liability for any defective product is limited to the repair or replacement of the product at our discretion.
ESCIENT PRIVACY POLICY Escient is committed to providing you with a product that you enjoy and are confident in using, and are committed to providing services in a private and secure environment. We recognize and respect each individual user’s privacy and have created this Privacy Policy to demonstrate our commitment to your privacy. We want you to be fully informed about the information that we collect, why we collect it, and with whom we share it.
FireBall™ SE-D1 User’s Manual TERMS AND DEFINITIONS Following are terms used throughout this manual: • Button - refers to a graphic item on the display screen. • Group - a collection of similar music titles. Standard genre groups are provided and custom groups can be created by the user. • Highlight - highlighting is used to indicate the user’s selection on screen. When the selection moves up, down, left, or right, the highlight moves to the next nearest item.
SETUP This manual assumes that you followed the printed “Quick Setup Guide” that came with your FireBall. If you have not properly connected your FireBall to your audio/video system, please go back and follow the “Quick Setup Guide” guide before continuing with this User Manual. POWER STATES After the FireBall unit is plugged in, the Standby LED located next to the power button will flash red until the startup process is complete. Please wait. This may take several minutes.
FRONT PANEL OVERVIEW 1 1 - POWER 10 4 3 5 11 1 6 1 - POWER 2 - IR IN 3 - IR OUT 4 - DIGITAL AUDIO OPTICAL OUT 5 - DIGITAL AUDIO OPTICAL IN 6 - ANALOG AUDIO IN PAGE 13 7 8 9 7 - ANALOG AUDIO OUT 8 - VIDEO OUT 9 - VIDEO IN 10 - COMMUNICATION PORTS 11 - ETHERNET FireBall™ SE-D1 User’s Manual 2
REMOTE OVERVIEW CODE SET UNIVERSAL SOURCE SELECT MODE GUIDE SELECT TRANSPORT CONTROLS GUIDE POWER FIREBALL SELECT ALL / NONE NAVIGATION & SELECT VIEW / MENU VOLUME CONTROL KEY PAD CONTROL CONTROL CHANNEL / PAGE CONTROL MACRO FUNCTION DISC PLAY FUNCTIONS MUSIC PLAY FUNCTIONS MUSIC FAVORITES PAGE 14 FireBall™ SE-D1 User’s Manual INFO
ENTERING TEXT WITH THE REMOTE CONTROL The remote control can be used to enter text in all text fields. This text entry capability is provided to allow you to fill out short text fields – such as those that occur in the setup and edit screens. FireBall’s wireless keyboard should be used when extended typing is required. Typing Characters with the Remote The remote control based text entry capability is similar to that provided on standard telephones and cell phones.
display a “C”. The fourth key press displays a lower case “a”, the fifth key press displays a lower case “b”, and the sixth key press displays a lower case “c”. Lastly, pressing the “2” key a seventh time displays the number “2”. When entering the second character in a text field or the second character following a space, FireBall assumes that lower case is preferred and the character entry cycles in the following pattern – lowercase, uppercase, and numeric.
CONNECTING EXTERNAL DISC CHANGER The FireBall SE-D1 supports up to 400 DVD and/or CDs located in one external Sony DVP-777ES CD/DVD changer. If you require storage for more than 400 discs, please visit your Escient dealer to purchase larger capacity Escient products. Connecting a Sony DVP-CX777ES CD/DVD Changer FireBall requires that you connect the changer to the back panel using audio and control cables. Follow these steps to connect your Sony CD/DVD changer to your FireBall: 1.
LOADING DVD MOVIE DISCS INTO CHANGERS Insert DVDs into your changers, following the changer manufacturer’s instructions and close the changer door. Quick Lookup will automatically start in a few seconds. If the Quick Lookup process does not automatically start, then manually start the Lookup using the steps described below. FireBall™ SE-D1 User’s Manual The disc information that FireBall displays on your TV screen is NOT included on the original CDs that you recorded or CDs/DVDs loaded into your changers.
Automatically Getting Disc Information Once your changers are connected to FireBall and loaded with CDs/DVDs, all you have to do is close the changer door and in a few seconds FireBall will begin looking up the disc information from each disc, in each changer. Quick Lookup checks each previously empty slot in the changers to see if any new discs were added, and then checks each previously occupied slot in the changer to see if any discs were removed.
Getting Disc Information for a Range of Discs If you want to lookup the disc information for a specific range of slots in a changer, you can use the Lookup Range feature. FireBall™ SE-D1 User’s Manual Follow these steps to lookup a range of changer slots: 1. Press the SETUP key on the remote to display the Setup menu. 2. Select the CHANGER MANAGEMENT menu. 3. Select the LOOKUP RANGE menu. 4. Enter a valid range of slots to lookup. If you have more than 1 changer, select which changer you want to use. 5.
Getting Disc Information for All Discs If you want to lookup the disc information for all discs you can use the Lookup All feature. FireBall™ SE-D1 User’s Manual Follow these steps to lookup all discs in all changers: 1. Press the SETUP key on the remote to display the Setup menu. 2. Select the CHANGER MANAGEMENT menu. 3. Select the LOOKUP ALL menu. 4. The Lookup All screen displays the progress and results as each disc is looked up.
ADDITIONAL CONNECTION AND HOOKUP INFORMATION This table shows which audio outputs are active for each type of audio source. Digital Optical Audio Source Analog Out Digital Coax Out Out Changer Analog YES Changer Optical YES YES Changer Coax YES YES YES YES Internet Radio YES For example, connecting only the analog audio outputs of the changer to the FireBall will not provide digital audio on the digital outputs of the FireBall.
All video outputs are active at the same time, so you can use as many as you like without causing signal degradation. The Component Video output will provide the best possible video quality for the FireBall User Interface, but will require that your video system has an available component input.
RS-232 CONNECTIONS The Sony disc changer is controlled via two-way serial protocols using an RS-232 serial cable. Connect the Sony changer to COM port “1 Changer”. COM port “2 Auxiliary” is reserved for future use. IR CONNECTIONS The direct IR input jack on the back panel of the FireBall is for controlling FireBall from a wired IR distribution system such as a Xantech system. This connection must be an IR signal with a 36kHz carrier using an 1/8” mono or stereo connector.
In a straight-through cable, wires 1, 2, 3, and 6 at one end of the cable are also wires 1, 2, 3, and 6 at the other end. In a crossed cable, the order of the wires change from one end to the other: wire 1 becomes 3, and 2 becomes 6. To figure out which wire is wire number 1, hold the cable so that the end of the plastic RJ-45 tip (the part that goes into a wall jack first) is facing away from you. Flip the clip so that the copper side faces up (the springy clip will now be parallel to the floor).
REGISTRATION Registering your FireBall is accomplished automatically when you go through the Quick Start process described in the User’s Manual. Registration includes properly configuring your FireBall for Internet access and then connecting to the Escient servers to register your serial number and download the latest Internet Radio stations.
WATCHING DVD MOVIES BROWSING YOUR MOVIE LIBRARY Now that you have your DVD movies loaded into your changers and the movie information has been acquired from the Escient MovieDB using the Quick Lookup feature, it’s time to see what’s in your collection using the Movies Guide. PLAYING THE CURRENT MOVIE Playing the currently highlighted Movie is the same as playing a DVD in a standalone DVD player. Simply press the PLAY key on the remote control and the changer will load the movie and begin to play it.
SELECTING A DIFFERENT MOVIE While a movie is playing, you can press the GUIDE key on the remote control to display the Movies Guide. The current movie is paused when you switch over the to Guide. Press the GUIDE key again to toggle back to the full screen movie and pickup where you left off. Movie Info View detailed infromation for the currently highlighted movie by pressing the Info button on the remote.
FireBall™ SE-D1 User’s Manual VIEWING BY GENRE In addition to the current Guide View, the Movies Guide automatically organizes your DVDs into default “Genres” also called “Groups”. The Group Bar displays a horizontal scrolling list of Genres corresponding to the movies in your library. Five Genres or Groups are visible at one time. The “All” genre is the default, which displays all Titles in your Movie Library.
LISTENING TO MUSIC BROWSING YOUR MUSIC LIBRARY If you have CDs loaded into your external changers or if you have a FireBall Music server on the same network as your SE-D1, the Music Guide is used to access your entire music collection. The Music Guide allows you to browse, locate, and play all of your music in one easy to use on-screen guide. The Music Guide displays a scrolling list of all your Music Titles. Using the remote control, you can navigate up and down the list.
PLAYING THE CURRENT TITLE Playing the currently highlighted Title is the same as playing a CD in a conventional CD player. Simply press the PLAY key on the remote control and it begins to play from track 1. Note: If you press SELECT with a Track highlighted, you will start playback from the selected Track. SELECTING A DIFFERENT SONG In the Music Player you can navigate up and down the track list using the remote control. Highlight a different song and press SELECT to play the song.
CHANGING THE GUIDE VIEW The GUIDE button on the remote control is used to switch between the Music Guide and Music Player screens. When you are viewing the Music Player screen, press the GUIDE button to return to the Music Guide. The Music Guide provides you with several ways to view the contents of your Music Library. One of the easiest ways to browse and sort your Music Library is by using the Music “Views”.
CHANGING THE CURRENT PLAY MODE The default Play Mode will play the current Title from Track 1 to the last track in order, then stop. If you want to change the order of how tracks are played, there are six different Play Modes to choose from: • Normal - play each track in order in the current Title, then stop. • Repeat Track - repeat the same track over and over until you press stop. • Repeat Title - play each track in the current Title in order then repeat the entire disc until you press stop.
VIEWING BY GENRE In addition to the current Guide View, the Music Guide automatically organizes your Music into default “Genres” also called “Groups”. The Group Bar displays a horizontal scrolling list of Genres corresponding to the music in your library. Five Genres or Groups are visible at one time. The “All” genre is the default, which displays all Titles in your Music Library. FireBall™ SE-D1 User’s Manual Using the LEFT and RIGHT arrow keys on the remote, you can select a different Genre.
LISTENING TO INTERNET RADIO BROWSING INTERNET RADIO STATIONS The Radio Guide displays a scrolling list of Internet Radio Stations. Using the remote control, you can navigate up and down the list. As each Station is highlighted, you will notice that the Information Area and Cover Art changes to reflect the currently highlighted Station. • Press the iRADIO key on the remote control to display the Radio Guide.
You’ll notice that a new screen appears displaying information about the selected station. This is the Radio Player screen. The Radio Player displays the station name, location, genre, genre cover art, and status about the current Internet Radio station stream. • Playing Internet Radio requires a valid Internet connection. • Although some stations will work over a Dialup Internet Connection, a broadband Internet connection is recommended.
MANAGING YOUR MEDIA Follow these steps to create your own custom Playlist: 1. Press the MUSIC key to make sure you are in the Music source mode. 2. Press the OPTIONS key to display the Music Options Menu 3. Select the NEW PLAYLIST menu item. 4. Using the remote control or keyboard, enter a name for your Playlist. 5. Select the CONTINUE button on screen to advance to the Edit Playlist Select Guide. The Edit Playlist Select Guide works just like the Music Guide.
To create a custom Group, follow these steps: 1. Press the MOVIES key to make sure you are in the Movies source mode, MUSIC key to make sure you are in the Music source mode or press the RADIO key if you want to create a custom Radio Group. 2. Press the OPTIONS key to display the Options Menu 3. Select the NEW GROUP menu item. 4. Using the remote control or keyboard, enter a name for your Group. 5. Select the CONTINUE button on screen to advance to the Edit Group Select Guide.
ADDING INTERNET RADIO STATIONS FireBall comes preloaded with several high quality streaming Internet Radio Stations from around the world, but that may not be enough for you, so FireBall also let’s you add your own Internet Radio Stations. Internet Radio stations must conform to these specifications: • Windows Media WMA or MPEG II layer 3 streams. • Windows Media 9 or earlier. Assuming you have a valid URL for a station, follow these steps to add your own Internet Radio Station to the Radio Guide: 1.
UPDATING THE INTERNET RADIO STATIONS LIST Escient makes every attempt to insure that the preloaded Internet Radio Stations are alive and well, but due to the dynamic nature of the Internet and the third parties who actually serve up these radio streams, sometimes you will not be able to play a station. The “Tune Stations” feature allows you to download a list of the most recent Internet Radio stations from Escient.
EDITING MOVIE INFORMATION FireBall has access to tens of thousands of DVD titles, but you may still encounter a DVD that does not return the correct disc information from the Escient MovieDB™. You can edit the disc information for any DVD Movie Title using the Edit Disc screens. FireBall™ SE-D1 User’s Manual Editing Disc Info Follow these steps to edit the disc information for the current Movie Title: 1. Highlight the Movie Title you want to edit in the Movies Guide. 2.
Automatically Lookup Information for This Disc The “Lookup This Disc” button will initiate a disc lookup for only this disc. FireBall will connect to the Escient MovieDB™ Service to locate and download the disc information. Follow these steps to lookup information for the current disc: 1. Highlight the Music Title you want to edit in the Movies Guide. 2. Press the OPTIONS key on the remote control. 3. Select the EDIT DISC menu item to display the Edit Disc Information screen. 4.
Follow these steps to search for a cover: 1. Highlight the Movie Title you want to edit in the Movies Guide. 2. Press the OPTIONS key on the remote control. 3. Select the EDIT DISC menu item to display the Edit Disc Information screen. 4. Select the SEARCH FOR MOVIE button to display the Search for Movie screen. 5. The current Movie Title is entered as the default search string. You can change the Title to modify the search. Note that editing the Title WILL NOT change it in the Movie Library.
Selecting an Existing Cover If for some reason you can not download the original cover, you can choose one of the existing covers for the current Title. FireBall™ SE-D1 User’s Manual Follow these steps to select an existing cover to assign to the current Title: 1. Highlight the Movie Title you want to edit in the Movie Guide. 2. Press the OPTIONS key on the remote control. 3. Select the EDIT DISC` menu item to display the Edit Disc Information screen. 4.
Edit Description If for some reason you can not download the original description, you can edit it. FireBall™ SE-D1 User’s Manual Follow these steps to select an existing cover to assign to the current Title: 1. Highlight the Movie Title you want to edit in the Movie Guide. 2. Press the OPTIONS key on the remote control. 3. Select the EDIT DISC` menu item to display the Edit Disc Information screen. 4. Select the EDIT DESCRIPTION button to display the Edit Description screen. 5.
EDITING MUSIC INFORMATION FireBall has access to over 2.5 million CD titles, but you may still encounter a CD that does not return a custom cover or the correct disc information. You can edit the disc information for any Music Title using the Edit Disc and Edit Tracks screens. Editing Disc Info Follow these steps to edit the disc information for the current Music Title: 1. Highlight the Music Title you want to edit in the Music Guide. 2. Press the OPTIONS key on the remote control. 3.
Editing Track Names You can also manually edit the Track/Song names of the currently highlighted Title in the Music Guide. FireBall™ SE-D1 User’s Manual Follow these steps to edit the track information for the current Music Title: 1. Highlight the Music Title you want to edit in the Music Guide. 2. Press the OPTIONS key on the remote control. 3. Select the EDIT DISC INFO Info menu item to display the Edit Disc Information screen. 4. Select the EDIT TRACKS button to display the Edit Tracks screen. 5.
Automatically Lookup Information for This Disc The “Lookup This Disc” button will initiate a disc lookup for only this disc. FireBall will connect to the Gracenote® Music Recognition Service to locate and download the disc information. FireBall™ SE-D1 User’s Manual Follow these steps to lookup information for the current disc: 1. Highlight the Music Title you want to edit in the Music Guide. 2. Press the OPTIONS key on the remote control. 3.
Follow these steps to search for a cover: 1. Highlight the Music Title you want to edit in the Music Guide. 2. Press the OPTIONS key on the remote control. 3. Select the EDIT DISC INFO menu item to display the Edit Disc Information screen. 4. Select the SEARCH FOR COVER button to display the Search for Cover screen. 5. The current Artist Name and Album Title are entered as the default search strings. You can change either one of these to modify the search.
Selecting an Existing Cover If for some reason you can not download the original cover, you can choose one of the existing covers for the current Title. FireBall™ SE-D1 User’s Manual Follow these steps to select an existing cover to assign to the current Title: 1. Highlight the Music Title you want to edit in the Music Guide. 2. Press the OPTIONS key on the remote control. 3. Select the EDIT DISC INFO menu item to display the Edit Disc Information screen. 4.
EDITING RADIO INFORMATION Similar to editing Music Information, you can also Edit the Radio Information. FireBall™ SE-D1 User’s Manual Follow these steps to edit the station information for the currently highlighted Internet Radio Station: 1. Make sure you are in the Radio source mode by pressing the RADIO key on the remote. 2. Press the OPTIONS key to display the Options Menu 3. Select the EDIT STATION menu item to display the Edit Station screen. 4.
Follow these steps to edit a Playlist: 1. Press the MUSIC key to make sure you are in the Music source mode. 2. Highlight the Playlist Name you want to edit. Note: The Playlist group will list all of your Playlists. 3. Press the OPTIONS key to display the Music Options Menu 4. Select the Edit Playlist menu item. 5. Using the remote control or keyboard, change the name of your Playlist or select the CONTINUE button on screen to keep the current name and advance to the Edit Playlist Select Guide. 6.
Follow these steps to edit a Group: 1. Press the MUSIC key if you want to edit the Music Groups or press the RADIO key if you want to edit the Radio Groups. 2. Highlight the Group you want to edit within the Group Bar. 3. Press the OPTIONS key to display the Music Options Menu 4. Select the Edit Group menu item. 5. Using the remote control or keyboard, change the name of your Group or select the CONTINUE button on screen to keep the current name and advance to the Edit Group Select Guide. 6.
DELETING MUSIC You can remove any music you have recorded to a FireBall server by using the Delete Music feature. You may want to do this if you have filled up your FireBall and you can not record any more music or if you want to remove songs that you just don’t listen to. You can not “delete” physical CDs from the Music Library. You must remove the discs from your changers if you want the CDs to be removed from the Music Guide.
DELETING PLAYLISTS FireBall™ SE-D1 User’s Manual You may delete entire Playlists from the Music Guide. Follow these steps to permanently delete one or more Playlists from the Music Guide: 1. Press the MUSIC key to make sure you are in the Music source mode. 2. Press the OPTIONS key to display the Options Menu 3. Select the DELETE PLAYLISTS menu item to display the Delete Playlists screen. 4. For each Playlist you want to delete, highlight the Playlist and press the SELECT key on the remote.
DELETING GROUPS Deleting Groups from the Group Bar is very similar to deleting Playlists. The contents of the Group (the Music Titles, Movie Titles, or Radio Stations) are not deleted. They are still available in any other Groups they may be assigned to and in the All Group. FireBall™ SE-D1 User’s Manual Follow these steps to delete Groups. 1. Press the MUSIC key if you want to edit the Music Groups or press the RADIO key if you want to edit the Radio Groups. 2.
SETTING USER PREFERENCES User preferences are available to specify global configuration options and preferred system settings. Press the SETUP key on the remote control to display the Setup Menu. Use the navigation keys on the remote control (up, down, left, and right) to highlight and select any menu item. SETTING THE SCREEN SAVER PREFERENCES Screen Savers are provided for each source mode.
Retail Demo Mode FireBall has a Retail Demo Mode for use in retail display environments. The Retail Demo Mode (RDM) is a special screen saver that is activated during idle time. The RDM continuously displays key features and benefits of the FireBall product on the attached TV. Pressing any button on the remote will temporarily disable the RDM and allow the user to demo the product. After the specified idle time, the RDM will reactivate as the screensaver.
SETTING YOUR TIME ZONE Specify which US time zone your FireBall is located in. FireBall™ SE-D1 User’s Manual Follow these steps to set your Time Zone: 1. Press the SETUP key on the remote to display the Setup menu. 2. Select the GENERAL Menu 3. Select the TIME ZONE Menu 4. Select your select your Time Zone.
CUSTOMIZABLE USER INTERFACE In addition to the Escient Classic user interface theme, the FireBall allows you to select a custom theme and select your own background images for each Guide, Player, Options, Setup, and Message screens. You can import your own background images into the Backgrounds shared directory using Windows Networking. Images should be 720x480 and saved in either jpg, gif, or png formats. Note: Some backgrounds look better than others.
ENABLING PASSWORD PROTECTION Optional Password Protection enables you to limit user access to the Setup Menus. This is useful to lockout the ability to change the global user settings and preferences. • You must exit Setup and re-enter setup to activate the password protection. • If a user password is specified, you will be prompted for your password whenever you press the Setup key on the remote.
MOVIE RATINGS Movie Ratings are used to prohibit the display of certain movies in the Movies Guide. This feature is used in conjunction with the Password Protection feature. You must have Password Protection enabled and a password entered for the Movie Ratings to be in effect. See the section above for more information on Enabling Password Protection. Select the highest movie ration you want to display in the Movies Guide without entering a password.
NETWORK ETHERNET SETTINGS Ethernet is the preferred networking choice which provides you with the best network performance and allows your FireBall to act as a “server” to deliver your music collection throughout your home network using the optional FireBall Music Players. Ethernet networks require that you configure each device on the network with a valid “address”. These addresses are usually configured automatically by your network hardware.
Testing the Your Connection It is a good idea to verify that your selected network connection is functioning properly before exiting the Network Connections screen. FireBall™ SE-D1 User’s Manual Follow these steps to test your selected network connection: 1. Select the TEST CONNECTION button on the Network Connections screen. 2. Wait for the tests to complete. A check mark next to each test indicates that it passed while an “X” indicates that the test failed. 3.
SETTING THE FIREBALL SERVER SETTINGS FireBall’s server allows you to control it remotely using a web browser on your PC. The FireBall Name allows you to easily locate and connect to your FireBall by name. Follow these steps to enter a name for your FireBall: 1. Press the SETUP key on the remote to display the Setup menu. 2. Select the NETWORK menu. 3. Select the FIREBALL SERVER SETTINGS menu. 4. Enter a name for your FireBall using the remote control or wireless keyboard.
VIDEO OUTPUT PREFERENCES Video Format Allows you to select 4:3 or 16:9 aspect ratios on your TV screen. 4:3 User Interface PAGE 66 16:9 User Interface FireBall™ SE-D1 User’s Manual Follow these steps to center the FireBall screen: 1. Press the SETUP key on the remote to display the Setup menu. 2. Select the VIDEO menu. 3. Select the VIDEO FORMAT menu. 4. Using the Up and Down keys on the remote, select your desired aspect ratio. 5. Press the SELECT key on the remote to highlight the SAVE button. 6.
Centering the FireBall Screen Allows you to center the FireBall user interface horizontally on your TV screen. FireBall™ SE-D1 User’s Manual Follow these steps to center the FireBall screen: 1. Press the SETUP key on the remote to display the Setup menu. 2. Select the VIDEO menu. 3. Select the SCREEN CENTERING menu. 4. Using the Left and Right keys on the remote, adjust the screen so that it appears horizontally centered on your TV. 5. Press the SELECT key on the remote to highlight the SAVE button. 6.
Adjusting your TV’s Brightness FireBall™ SE-D1 User’s Manual Follow these steps to adjust the brightness on your TV: 1. Press the SETUP key on the remote to display the Setup menu. 2. Select the VIDEO menu. 3. Select the BRIGHTNESS menu. 4. Turn your TV’s brightness control all the way up then lower it to the point where the vertical black bar on the left just disappears. This will get your brightness control as close to the proper setting as possible without the use of special software and hardware. 5.
Adjusting your TV’s Contrast The Contrast or Picture Adjustment control allows you to optimize the contrast (which is sometimes called Picture) of their TV, using the TV’s Contrast or Picture controls. This setting helps reduce video “blooming” and create a clearer, more readable user interface. FireBall™ SE-D1 User’s Manual Follow these steps to adjust the contrast on your TV: 1. Press the SETUP key on the remote to display the Setup menu. 2. Select the VIDEO menu. 3. Select the CONTRAST menu. 4.
Adjusting your TV’s Sharpness The Sharpness adjustment allows you the set the Sharpness or Detail control of their TV so that onscreen text is as readable as possible. Proper adjustment of the Sharpness control (sometimes called the Detail control) on your TV, allows you to see video and on screen menus more accurately. FireBall™ SE-D1 User’s Manual Follow these steps to adjust the sharpness on your TV: 1. Press the SETUP key on the remote to display the Setup menu. 2. Select the VIDEO menu. 3.
Adjusting your TV’s Color and Tint Color Bars are used to test the TV monitor’s ability to reproduce the proper color values. FireBall™ SE-D1 User’s Manual Follow these steps to adjust the Color and Tint on your TV: 1. Press the SETUP key on the remote to display the Setup menu. 2. Select the VIDEO menu. 3. Select the COLOR BARS menu. 4.
EXTERNAL CONTROL SURROUND MODE SETTINGS FireBall will automatically switch the video and audio output from the DVD changer when you play a movie title. This allows you to use one input on your a/v receiver or TV for the FireBall and the DVD changer. You may use either composite, S-video, or component video connections and analog, digital, or 5.1 analog audio connections from the changer to the FireBall. Use the same types of connections from FireBall to your A/V receiver or TV monitor.
IR REMOTE CONTROL FireBall is preset from the factory to operate from the FB1 source button, however, the FireBall can be configured to use any one of the four source buttons using the on screen Setup menus. This is useful when there are multiple FireBalls installed at the same location, so all FireBalls don’t respond to the same IR commands.
DIRECT ACCESS CODES Direct Access Codes are used in conjunction with the MACRO key on the remote control to provide an IR code sequence to access just about any media in your FireBall server. This is useful for programming third-party external control systems and programmable IR remote controls such as the Marantz RC9500. The Direct Access Codes are available for all music titles, playlists, groups, and radio stations. IP address and look under Setup->Direct Access Codes.
The following table is used to determine the button sequence for direct access code sequences from the Escient IR remote and IR keyboard.
The following table is used to determine the button sequence for direct access code sequences from the Escient IR remote and IR keyboard.
PLAYLIST HOT KEYS Playlist Hot Keys provides a Keyboard Macro sequence to directly access any five Playlists in your Music collection from any of these five keyboard combinations: • Control + Backspace • Control + Insert • Control + Delete • Control + Top • Control + Bottom Note: If there is nothing in the Playlist Hot Keys list, you must first create Playlists on your FireBall.
BUTTON OVERLAY You may choose to manually enable or disable the Third Party Overlay. The Touch Panel Overlay is used for third-party control systems such as the Elan VIA! and Xatech SPLCD. FireBall™ SE-D1 User’s Manual Follow these steps to enable/disable the button overlay: 1. Press the Setup key on the remote to display the FireBall setup menu. 2. Select the External Control menu item. 3. Select the Button Overlay menu item. 4. Navigate up or down and press SELECT to enable or disable. 5.
FIREBALL UTILITIES GETTING INFORMATION ABOUT YOUR FIREBALL Information about your FireBall hardware and software is available under the Utilities menu. This information is useful for troubleshooting any problems you may encounter with your network connection or verifying the current software versions. FireBall™ SE-D1 User’s Manual Follow these steps to view the FireBall system information: 1. Press the SETUP key on the remote to display the Setup menu. 2. Select the UTILITIES menu. 3.
RESTARTING THE SYSTEM There are two ways of manually performing a full restart or reboot of the FireBall system, one using the front panel power button and the other using the Restart System menu. Follow these steps to restart the system using the front panel Power Button: 1. Press and hold the power button for 4 seconds. 2. When the LED on the front panel begins to flash, release the power button. 3. When the LED on the front panel glows solid RED (standby mode), FireBall is ready to use. 4.
UPDATING THE SOFTWARE FireBall will automatically check the Escient server once a week for any FireBall software updates, and automatically install them. You can also manually check for a software update. FireBall™ SE-D1 User’s Manual Follow these steps to manually update the software: 1. Press the SETUP key on the remote to display the Setup menu. 2. Select the UTILITIES menu. 3. Select the UPDATE SOFTWARE menu. 4. Select the Check for Update button. 5.
CONTROLLING FIREBALL FROM A WEB BROWSER FireBall contains a built-in web server which means you can connect to your FireBall and remotely control it using a standard web browser from a PC, Mac, or PDA over your home network. SETTING UP THE FIREBALL WEB SERVER Your FireBall acts as a web server on your network allowing you to connect and control the FireBall using your PC or Mac computer. This web server is automatically configured and started each time the FireBall is plugged in.
NETWORKED AUDIO USING FIREBALL MUSIC CLIENTS SERVERS A FireBall Server is a Fireball media management system that is capable of “serving” media to other FireBalls over a network. The FireBall is a considered a “server” product. FireBall™ SE-D1 User’s Manual CLIENTS A FireBall Client is a FireBall that can play media from a FireBall Server over a network.
FireBall is built from the ground up with many features that allow you to centrally locate and remotely control your FireBall clients and servers, such as: • Direct IR input • Two way serial control over RS-232 • Two way serial control over ethernet • Wireless IR remote and Keyboard options • Support for 4 different IR banks (4 IR zones) • Templates for integration into many third party wired and wireless IR distribution systems • Philips and Marantz Pronto remote control templates PAGE 84 FireBall™ SE-D1
Distributed A distributed FireBall installation means that your FireBall Servers and Clients are physically distributed or located in different rooms. Distributed FireBalls communicate over a wired or wireless network to share access to your media. FireBall™ SE-D1 User’s Manual The biggest advantage of a distributed clientserver system over a central system is that everything you need is built into FireBall.
CONFIGURING A FIREBALL SERVER Every FireBall capable of server functions is automatically enabled to serve MP3 and FLAC audio whenever it is plugged in and properly configured for your network. It is recommended that you give each of your FireBall servers a unique name that describes it’s location using the SERVER SETTINGS screen which can be accessed from Setup/Network /Server Settings. Names like “LivingRoom”, “HomeTheater”, “MyMusicServer” are all good examples.
ESCIENT TECHNICAL SUPPORT Contact your dealer or Escient’s Customer Support group. Hours: Monday - Friday 9:00am - 7pm EST Phone: 800-372-4368 Press “2” for Sales, or “3” for Support Fax: 317-616-6790 Internet: www.escient.com Email: support@escient.
TROUBLESHOOTING SOFTWARE UPDATE PROBLEMS Manual Software Update Checks Software Updates are automatically checked once a week starting on the day of the week your FireBall was first registered. You can manually check for a software update by accessing the Software Update menu found under the Setup/Utilities Menu. RECORDING PROBLEMS Audio vs. Data CDs FireBall requires Royalty paid blank media when recording audio CDs. Blank CDs marked with “Data” can not be used when creating Red Book audio CDs.
SPECIFICATIONS Specifications are subject to change without notice. Please check the Escient web site for any changes to the specifications. Video Specifications • NTSC • 10 bit Video DACs • Frequency Response: • Composite: -2 dB @ 5MHz • S-Video: -2 dB @ 5MHz • SNR: 50 dB • Crosstalk: 50 dB • Input Impedance: 75Ohm • Output Impedance: 75Ohm Audio Specifications • Frequency Response: 2 – 20,000 Hz, ±1 dB • THD+N (playback) < -80 dB FS A (< 0.
GRACENOTE® END-USER LICENSE AGREEMENT USE OF THIS PRODUCT IMPLIES ACCEPTANCE OF THE TERMS BELOW. This product contains technology and data from Gracenote of Emeryville, California (“Gracenote”). The technology from Gracenote (the “Gracenote Embedded Software”) enables this product to do disc identification and obtain music-related information, including name, artist, track, and title information (“Gracenote Data”), which is included on the Gracenote Database (the “Gracenote Database”).
