ETA-ECS3 SPECIFICATIONS
GENERAL
Type PowerSequencer,PowerConditioner&Suppressor
Sequencer Sections 3,FixedTimeof3SecondsBetween“On”Sequence2&3,“Off”2&1
Load Rating 15A
FRONT PANEL
Outlets 2 Unswitched
Lights 1PulloutLEDwithDimmerSwitch
Activation Switch Momentary
Circuit Breaker 15A Resettable
AC Mains Voltmeter Three Digits Digital
Indicators SequencerSections1,2&3,AbnormalVoltage,ACFault,BreakerOpen,WiringFault
REAR PANEL
AC Outlets 7 Outlets Total
Sequence Section 1 (3 Outlets)
Sequence Section 2 (2 Outlets)
Sequence Section 3 (1 Outlet)
Unswitched (1 Outlet).
External Switch Activation Trigger MomentaryContacts,2PositionEuro/PhoenixTypeConnector
External Voltage Activation Trigger 5–24VDCContinuous,10mA,2PositionEuro/PhoenixTypeConnector
DC Output 24VDC 100mA Output Paralleled to Sequencer Section 3 Timing
LED Light Socket XLRSockettoProvide12VDCforOptional16"GooseneckLamp,AP-GNL18
LED Light Switch Two Position On / Off
Grounding Terminal HandScrewTypeTerminaltoChassisGround
AC Mains Power Cord 9' (3m) 14-gauge
