Section 1
Unpack and Organize
The table below lists the parts and components needed to retrofit a Sensor+ touring rack
(SP+ 48, 96, or 96 “Double Small”) to become a Sensor3 rack with a CEM3. Each part is
listed to reflect the different quantities for the different kits and types of racks.
* Need/quantity based on specific rack or door type. See Sensor3 Touring Rack Retrofit Kit order sheet for details or
contact ETC Technical Services (see Contacting Technical Services, page 1).
Parts/Components
ETC Part Number
SP+48/96
Universal Kit
7143K1005
Parts Included in the Kit
Touring Backplane Baffle
7053A3023
1
CEM3 SP DMX/Beacon Control Assembly
7142B5610
1
Sensor3 Touring Rack Door Label
7143A4119
1
CEM+ to CEM3 Backplane Power Adapter Harness
7141B7007
1
Sensor3 Rack Backplane Assembly
7142A2006-CFG
1
Sensor Touring Rack CEM+ to CEM3 Retrofit Manual
7143M2300
1
Second Fan Indicator Label
7143A4001
1
Screw 8-32 X 3/8 Ph PH MS CP W/Patch
HW377
5
Cable tie 4" Hi-temp Black
HW7121
5
Screw M3.5 x 4 mm
HWM1036
2
CEM3 Backplane 1/8” #8 screw spacer
HW9343
5
Additional Items SP48 SP96
SP96
“Double Small”
Additional
Line Items
SP48/96 Door Baffle Replacement Kit
7143A2002
1* 2* 1*
SP96 “Double Small” Right Baffle Replacement Kit
7143A2005
001*
SP48/96 Left Door Replacement Kit
7143B3004
1* 2* 1*
SP96 Right Door Replacement Kit
7143B3007
001*
Sensor3 AF Card (Optional)
7150B5623
244
CEM3
7140A1000
111
Required Tools
#1 Phillips screwdriver
#2 Phillips screwdriver
Flat-blade or square-drive screwdriver
5/16” nut driver or socket
Diagonal wire cutter
Permanent marker
Wire strippers
