User Manual Excel G-Lite Read instructions before use Version 1.2 (updated 16/10/2009) See www.vanosmedical.
Overall user manual YOU AND / OR YOUR ATTENDANT MUST READ AND FULLY UNDERSTAND THIS MANUAL BEFORE USE General information You have just purchased a Van Os Medical UK Ltd wheelchair and we want to thank you for the confidence in our EXCEL® products. The EXCEL® wheelchair is a quality product. It is adjustable in many different ways and it can also be easily upgraded. The policy of Van Os Medical UK Ltd is to continually improve the quality and reliability of our products.
Overall user manual Contents 1. IDENTIFICATION.................................................................................................................................................................. 3 2. GENERAL EXPLANATION CONCERNING YOUR WHEELCHAIR ............................................................................................... 4 2.1 COMPONENTS OF THE WHEELCHAIR ....................................................................................................................
Overall user manual 1. IDENTIFICATION Your wheelchair is equipped with a unique identification number. You can find this number on the cross frame of your wheelchair. Below is an example of the frame label on which you can find the identification number. Furthermore you will find the explanation of the various data stored on the frame label listed below. 3 2 1 5 6 4 7 1. Production date The date on which your wheelchair was manufactured. 2.
Overall user manual 2. GENERAL EXPLANATION CONCERNING YOUR WHEELCHAIR 2.1 Components of the wheelchair 1 2 13 15 3 14 15 11 4 10 12 5 9 8 6 7 1 2 3 4 5 6 7 8 Padded backrest Push handle Side Panel Brake Handle Rear wheel Identification label Front castor Front Fork 9 10 11 12 13 14 15 Foot plate Foot Rest Swing Arm Seat Heel Strap Arm Rest Velcro Pocket Folding Backrest Clip Your wheelchair is equipped with a number of elements and parts.
Overall user manual 3. SAFETY REGULATIONS VAN OS MEDICAL UK Ltd specifically disclaims responsibility for any body injury or property damage which may occur during any use which does not comply with laws or ordinances. If used correctly, the Excel wheelchair is an utmost safe and stable product, if the instructions for use as described in this manual are followed. However, it is possible when the Excel wheelchair is not used correctly, dangerous situations may occur. 3.
Overall user manual - A ‘wheelie’ is extremely dangerous to the user and will cause serious damage to the wheelchair 3 - Never connect anything to the wheels, this may cause damage to the chair and also effect the balance of the chair and may injure the user; Do not stand on the footrest this will cause the chair to tip and injure the user (figure 4); 4 - For suitable protection of potential obstruction the lowest point of the footrests serves minimum 7 cm free of the ground; Place the wheelchair on
Overall user manual 4 INSTRUCTIONS FOR USE You will have to learn the characteristics of your wheelchair. It is most important to learn the safest methods to develop the daily activities in accordance to your life style. Consult your medical advisor or therapist for assistance by developing safe and effective techniques for your daily activities and your physical possibilities. 4.
Overall user manual Reaching / bending sideward 1. 2. 3. Manoeuvre the chair as closely as possible to the object you want to reach. You can use your rear wheels; Make sure the front wheels are fully turned to the front. If not, go forwards and then backwards to turn the wheels fully to the front; You can now pick up the object. While you pick up the object you need to make sure you keep it as close as possible to the wheelchair (picture 7 and picture 8). 7 8 Reaching / bending backward 1. 2. 3.
Overall user manual - The attendant is already standing on the pavement and makes sure that the wheelchair stands with the rear wheels as closely to the pavement as possible. The user of the wheelchair needs to lean backwards. This way the wheelchair will tip backwards and the attendant can pull the chair on the pavement. The attendant needs to make sure that the front wheels are on the pavement before he lets the wheelchair down.
Overall user manual We recommend you to use anti-tip wheels. They prevent you from tipping the wheelchair over backwards (figure 12). Depending on the model of your Excel wheelchair sometimes these are a standard item and sometimes they are an optional extra. Do not carry any weight on the back of the wheelchair whilst ascending (figure 13). This changes the balance and increases the chances of tipping backwards.
Overall user manual 4.4 Going up and down stairs Stairs are one of the largest obstacles for wheelchair users. However, with a little help from others it is possible to climb up and down the stairs when a wheelchair elevator is not available. Only you and your attendants must be aware of the rather heavy weight to be replaced. Going up the stairs You need to go up the stairs backwards. We advise if you want to climb the stairs with a wheelchair you will do this with the help of a minimum of two attendants.
Overall user manual THE CHANGE OF INSTITUTIONS TO YOUR WHEELCHAIR CAN HAVE MAJOR IMPACT ON THE OPERATION OF THE WHEELCHAIR AND YOUR SAFETY. INSTITUTIONS OF THE FACTORY SPECIAL INSTITUTIONS FOR OWN RISK. 5 INSTRUCTIONS FOR USE AND MOUNTING OPTIONS In this chapter we will explore all the possibilities that you have with your wheelchair. All setting and user instructions, such as the removal of the footrest, will be discussed.
Overall user manual Folding the wheelchair - Fold away the foot plates and remove the foot or leg rest, see chapter 5.3; - Make sure you are next to the wheelchair; - Get a hold of the seat material at the front and rear in the middle and pull it straight up, see figure 2; - Tilt the wheelchair slightly and then push the sides toward each other to completely fold the wheelchair. Figure 1 Figure 2 5.
Overall user manual Setting height of the footplate For adjusting the height of the footplate you need to use an allen key. - Loosen the bolt on the footrest completely, see figure 7; - You can now remove the footplate or adjust the height; - When you wanted to adjust the height, please select the desired height now and tighten the bolt down; - Make sure the footplate is in place and that the length is equal on both sides. Figure 5 Figure 7 Figure 6 5.
Overall user manual 5.7 Using accessories and other options on your wheelchair Seat Belt Your wheelchair is equipped with a seat belt which you can use the following way: - When in the wheelchair, you can fasten the belt by clicking the two loose ends together, see figure 11; - You can adjust the length of the seatbelt making it looser or tighter, see figure 12; - To release the seat belt, push the two plastic clips and pull apart.
Overall user manual EN 12183 EN 1041 Product identification Product Brand Model/type Version ISO 7176-15 ISO 7176 : Physically propelled wheelchair : Excel : G-Lite : Manufacturer: EU Representative: Technical constructed file Prepared by: Function: Issue date: TCF date: Recertification date: Name Address Van Os Medical B.V. Koperslagerij 9 Country The Netherlands Name W. van Os Address Koperslagerij 9 Country The Netherlands Function Director Name J.M.J.
Overall user manual 6. TRANSPORT AND TRANSIT IN CAR Your Excel® wheelchair is designed to be easily transported by car. Your wheelchair is foldable so the total width is limited to an average measure of 20 cm. Further your wheelchair is equipped with swing away and detachable footrests. At the same time some wheelchairs can be equipped with a couple of size decreasing accessories, like quick release (detachable) rear wheels and a foldable backrest. 6.
Overall user manual PU tyres: More and more we use PU tyres (polyurethane or puncture-free tyres) on the wheelchair. You can recognise these tyres because they do not have a valve. These tyres have the advantage that they do not need to be pumped up and can not be punctured. This PU tyre can just as an air tyre wear out. Check periodically to see if the tread is still deep enough. For the maximum tyre pressure we direct you to chapter 5, ‘ Instructions for use and mounting options’.
Overall user manual 7.7 Cleaning It is important to clean your wheelchair regularly. - Clean the upholstery, chassis and plastic components on the wheelchair regularly with a mild soap and water. Never use abrasive cleaners, they can damage the varnish. Also never use steam or high pressure cleaners; - Wax the varnish of the chassis regularly. Never use solvents, abrasive waxes, caustic chemicals or spray silicone; - Dry the wheelchair after cleaning.
Overall user manual 9. WARRANTY 9.1 Warranty application Together with your wheelchair you get the factory warranty. However, it is possible that your dealer offers a supplementary warranty. This manual only handles the factory warranty as given by Van Os Medical. 10 years COMPONENT 2 years None This warranty is only granted to you as the consumer. It is not intended to be used commercially (like hiring or institutional use).
Overall user manual With normal circumstances no responsibility is accepted when the wheelchair needs replacement or repairs as a direct result from: 1. Not maintaining the wheelchair and parts according to the recommendations of the manufacturer, or not using the specific original parts; 2. Damaging the wheelchair or parts by inattentive use, accident or wrong use; 3.
Overall user manual 10.2 Service checklist For optimal life your wheelchair should be periodically maintained by an authorized dealer. Service Schedule Service interval: ................................
