Testing Fibers
OTDR 49
Monitoring Fiber in Real Time Mode
7. Select range as follows:
7a. Use the arrows to select the Range list, and then press Enter to
open the list.
7b. Use the up/down arrows to select the desired distance range, and
then press Enter to confirm.
8. Select pulse as follows:
8a. Use the arrows to select the Pulse list, and then press Enter to
open the list.
8b. Use the up/down arrows to select the desired pulse, and then
press Enter to confirm.
9. Press F
ASTRACE to start the acquisition.
To deactivate the Real time mode:
If you only want to stop monitoring, press F
ASTRACE once again.
OR
If you are ready to start a test, proceed as follows:
1. Press Esc to exit the Trace pane.
2. In the displayed panel, open the OTDR mode list, and then select
Manual.
