Measuring Power or Loss
80 AXS-100 Series
Defining the List of Favorite Wavelengths
Defining the List of Favorite Wavelengths
You can put the wavelengths you want to use on a list of favorite
wavelengths. Only wavelengths selected from this list are available for
measurements.
By default, the list contains all the calibrated wavelengths: 850 nm,
1300 nm, 1310 nm, 1490 nm, 1550 nm, 1625 nm, 1650 nm.
Note: The list must always contain at least one selected wavelength.
To customize the list of favorite and selected wavelengths:
1. Press Menu, select Setup > Power Meter, and then press Enter.
OR
From the Power Meter pane, press Setup (F1/F2 key).
2. Using the up/down arrows, scroll through the
list.
3. Press Enter to select/deselect the highlighted
wavelength.
OR
Press Select (F1 key).
A check mark appears beside selected wavelengths.
4. Repeat these steps for other wavelengths as necessary.
