Instructions / Assembly
OFF
Photo 2
Photo 1
Photo 3
Photo 4
ON
OPERATION
ON/OFF: The unit is shipped in the OFF position. Locate the ON/OFF switch on the bottom of
the solar unit and press button to ON position (Photo #1). In the ON position, the solar cell
will light up automatically at dusk and will shut OFF automatically when the solar panel is
exposed to daylight.
Location: Select a sunny location. Place the unit in direct sunlight for at least one day to fully
charge the battery. The more direct sunlight your new solar light is exposed to during the day,
the longer the light will operate in the evening.
MAINTENANCE
Cleaning: The solar panel has an epoxy cover that will need to be kept free of dirt and debris,
and snow, all the time. Wipe the panel periodically with a damp cloth. Failure to do so will
prevent the battery from charging properly, reducing operating time and the life of the battery.
Check the battery periodically, especially after winter months, and replace when necessary.
The battery may need to be replaced after a year of continuous use. To replace, open the
battery compartment by unscrewing the four screws (Photo #2) and pulling the battery cover
off the unit (Photo #3). Replace the battery with a 300mAh Ni-MH AAA 1.2V rechargeable
battery (Photo #4). The capacity of the replacement battery shall not be less than the
recommended capacity. Replace the battery cover and screw four screws in firmly to seal the
unit.
Warning:
• Only use rechargeable Ni-MH AAA 300mAh 1.2V battery.
• Failure to insert the battery in the correct polarity, as indicated in the battery compartment,
may shorten the life of the battery or cause the battery to leak.
• Do not dispose of batteries in fire, or heat, as battery may explode.
• Do not open, short circuit, or mutilate battery, as injury may occur.
• Batteries should be recycled, or disposed of, in accordance with Federal, state and local
regulations.
• Electrical rating is 0.05W.
Attach stake bottom to stake top by inserting it through the opening.
Ni-MH
Battery must be recycled or
disposed of properly. Do not
short circuit or dispose of in re.
FOR DECORATIVE USE IN THE GARDEN. NOT TO BE GIVEN TO CHILDREN AS TOY.
© 2020 Exhart - Chatsworth, CA 91311. Made in China / Fabrique en Chine. All Rights Reserved.
For help please call 1-800-775-5503 | support@exhart.com
exhart.com
06159-RS
