Datasheet

PRODUCT DATASHEETPRODUCT DATASHEET
UV510
UVA Light Meter
Features
• Sensor wavelength range 320 to 390nm
• UV sensor with cosine correction measures irradiance
from UVA light sources up to 20.00mW/cm
2
• Backlit LCD to view in dimly lit areas
• Zero function
• Data Hold and Min/Max functions
• Auto power off with disable
• Tripod mount (optional TR100 Tripod sold separately)
• Complete with wrist strap, light sensor cover, and three
AAA batteries
Specifications Range
UVA Range 0 to 1.999mW/cm
2
, 2 to 20.00mW/cm
2
Resolution 0.001mW/cm
2
Accuracy ±4%FS
Dimensions 5.5 x 2.3 x 1" (141 x 58 x 25mm)
Weight 5.6oz (160g)
Ordering
UV510 ............... UVA Light Meter
www.extech.com
Specifications subject to change without notice. Copyright © 2017 FLIR Systems, Inc. All rights reserved including the right of reproduction in whole or in part in any form.
Rev. 9/5/17
UPC Code: 793950215104
The Extech UV510 UV light meter measures UVA light
radiation from natural and artificial light sources. It offers a
backlit dual display, cosine corrected sensor, two selectable
ranges, zero function, min/max recording, display hold, and
auto power off. Compact size with handy wrist strap gives you
convenience in taking quick UV reading wherever you go.
