User Guide

X2^
= EDID output resolution and refresh
rate
See the tables below.
VGA - PC
SIS
Value
Resolution Refresh
Rate (Hz)
SIS
Value
Resolution Refresh
Rate (Hz)
SIS
Value
Resolution Refresh
Rate (Hz)
1 800x600 60 7 1360x768 60 12 1600x1200 60
2 1024x768 60 8 1366x768 60 13 1680x1050 60
3
1280x720
(default - analog)
60 9 1400x1050 60 14 1920x1080 60
4 1280x768 60 10 1440x900 60 15 1920x1200 60
5 1280x800 60 11 1600x900 60 16 2048x1080 60
6 1280x1024 60
DVI - PC
SIS
Value
Resolution Refresh
Rate (Hz)
SIS
Value
Resolution Refresh
Rate (Hz)
SIS
Value
Resolution Refresh
Rate (Hz)
17 800x600 60 23 1360x768 60 28 1600x1200 60
18 1024x768 60 24 1366x768 60 29 1680x1050 60
19 1280x720 60 25 1400x1050 60 30 1920x1080 60
20 1280x768 60 26 1440x900 60 31 1920x1200 60
21 1280x800 60 27 1600x900 60 32 2048x1080 60
22 1280x1024 60
HDMI - PC with 2-channel Audio
SIS
Value
Resolution Refresh
Rate (Hz)
SIS
Value
Resolution Refresh
Rate (Hz)
SIS
Value
Resolution Refresh
Rate (Hz)
33 800x600 60 38 1360x768 60 43 1600x1200 60
34 1024x768 60 39 1366x768 60 44 1680x1050 60
35 1280x768 60 40 1400x1050 60 45 1920x1200 60
36 1280x800 60 41 1440x900 60 46 2048x1080 60
37 1280x1024 60 42 1600x900 60
HDMI HDTV
SIS
Value
Resolution Refresh
Rate (Hz)
SIS
Value
Resolution Refresh
Rate (Hz)
SIS
Value
Resolution Refresh
Rate (Hz)
47
480p
2-ch audio
60 51
1080i
2-ch audio
50 54
1080p
2-ch audio
60
48
576p
2-ch audio
50 52
1080i
2-ch audio
60 55
VGA user
assigned or
imported 1
49
720p
2-ch audio
50 53
1080p
2-ch audio
50 56
HDMI user
assigned or
imported 2
50
720p
2-ch audio
(default - digital)
60
FOX T UWP 302 Wallplate Transmitter • SIS Configuration and Control 15
