Command ASCII Command
(Host to Device)
Response
(Device to Host)
Additional Description
Internal temperature
View internal temperature
20S
X!]
Internal temperature in
degrees Fahrenheit and
Celsius.
Factory reset
System reset (factory default)
EZXXX} Zpx]
Resets unit to factory
default (see System Reset
on page 12).
Reset audio gain and
attenuation
EZA} Zpa]
Reset audio gain and
attenuation to default levels.
Upload firmware
Upload firmware
EUpload} SendHeader]
SFP module
View SFP module information
40S
X1*
•
X1(
•
X2)
•
X2!]
NOTE: X! = Internal temperature
X1* = Vendor or manufacturer name
X1( = Transmit (Tx) output power in dBm
X2) = Receive (Rx) optical power in dBm
X2! = Operation temperature of the SFP modules in degrees Celsius
FOX T UWP 302 Wallplate Transmitter • SIS Configuration and Control 20
