FOX Extenders
Control Program
The Extron FOX Extenders Control Program provides an alternate method to control
and configure the FOX T UWP 302. The application provides controls to adjust device
parameters that are specific to the basic and advanced setup of the transmitter. Users can
also manage firmware and check for updates to the application. The Extron FOX Extenders
Control Program communicates with the transmitter via the Remote RS-232 port on the rear
panel Remote RS-232 and Alarm connector or front panel USB Config port. The program
is compatible with Microsoft
®
Windows
®
2000, Windows XP, or later Windows operating
systems. Updates to this program can be downloaded from the Extron website
(www.extron.com). Topics in this section include:
• Installing the Software
• Starting the Software
• Using the Software
Installing the Software
The program is contained on the Extron Software Products DVD or available for download
on the Extron website, www.extron.com.
To install the software from the DVD:
1. To install the software, insert the DVD into the DVD drive. The Extron software DVD
window should appear automatically. If it does not self-start, run Launch.exe from the
DVD.
2. Click the Software tab, scroll to the desired program, and click Install.
3. Follow the instructions that appear on the screen. By default, the installation creates a
folder in the Program Files directory for the FOX Extenders Control Program.
To download the software from the website:
1. On the Extron website, click the Download tab.
2. From the left sidebar, click the Software link.
3. Navigate to FOX Extenders.
4. Click the Download link to the right of the desired device.
5. Submit any required information to start the download. Note where the file is saved.
6. Open the executable (.exe) file from the save location.
7. Follow the instructions that appear on the screen. By default, the installation creates a
folder in the Program Files directory for the FOX Extenders Control Program.
21FOX T UWP 302 Wallplate Transmitter • FOX Extenders Control Program
