IPI 100 Series, IPI 200 Series • Introduction
Introduction, cont’d
1-4
Features
• Two-way, half-duplex voice communications over an IP
network
• Compatibility with IP Intercom-enabled MLC 226 IP
MediaLink Controllers (IPI 101 AAP and IPI 104 AAP)
• Backlit, congurable Push To Talk buttons
• Integrated speaker and microphone
• Three-position switch to adjust speaker volume levels (IPI 101
AAP and IPI 104 AAP only)
• LED indicator to show when the room is being monitored
• Four space and 2-gang Architectural Adapter Plate (AAP)
opening mounting
• Connection via existing network cable drops (one drop per
MLC-IPI pair, IPI 101 AAPs and IPI 104 AAPs, only)
System Requirements
The IP Intercom HelpDesk software is available at no charge via
the Extron Web site (http://www.extron.com) or the CD that
comes with your IPI. To install and run IP HelpDesk, you need
a PC with the following things installed:
• Windows 2000 or Windows XP Professional
• Pentium 4, 2 GHz or faster microprocessor
• 500 MB RAM, recommended (256 MB minimum)
• 50 MB or more available hard disk space
• Windows-supported sound card, microphone, and speakers
• Microsoft Direct X version 9.0c or later
• Microsoft .NET framework, version 2.0 or later
• network card and a network connection
