- Extron Electronics Ethernet control interface User's Manual

IPI 100 Series, IPI 200 Series • Programming and Control
IPI 201/204 SIS
™
Programming, cont’d
5-18
Command ASCII (Telnet)
(host to intercom)
URL Encoded (Web) (host to intercom)
Response (intercom to host)
Additional description
Read IP address
E
CI
}
W CI
| X1$
]
Leading zeros in each of the four elds are suppressed in returned values.
Read hardware address (MAC)
E
CH
}
WCH
| X1*
]
or
Iph•
X1*
]
X1*
= hardware (MAC)
address (xx-xx-xx-xx-xx-xx).
Set subnet mask
24
E
X1(
CS
}
W
X1(
CS
|
Ips•
X1(
] X1(
= subnet mask (xxx.xxx.
xxx.xxx). Syntax is the same as for IP addresses. Leading zeros are optional in setting values.
Read subnet mask
E
CS
}
WCS
| X1(]
Leading zeros are suppressed.
Set gateway IP address
24
E
X1$
CG
}
W
X1$
CG
|
Ipg•
X1$
] X1$
= IP address (xxx.xxx.
xxx.xxx). Leading zeros are optional.
Read gateway IP address
E
CG
}
WCG
| X1$ ]
