User's Guide



NOTE: Whenmountingtosurfacesthatdonotallowwirestoberoutedfrom
behind(suchasonmasonryorconcretewalls)andthewiresareroutedtothe
speakersviaaraceway,usethealternateaccesspointstorunthewirestothe
quickconnectspeakercontacts(seethefiguresbelow).
OR
0° Mounting Plate
Alternate Access Point
Alternate Access Points
10° Mounting Plate
SM 3 User Guide • Installation 8
