Manufactured in the USA

proprietary and may not be shared, modified, distributed, reproduced, or reused without the express

written permission of EZ-ACCESS

, a division of Homecare Products, Inc.

18555 REV 02-24-2020

PATHWAY® HD

Code Compliant Modular Access System

TECHNICAL SPECIFICATIONS

Summary of content (9 pages)

PAGE 1
PATHWAY® HD Code Compliant Modular Access System TECHNICAL SPECIFICATIONS Manufactured in the USA © Homecare Products, Inc. All rights reserved. All text and images contained in this document are proprietary and may not be shared, modified, distributed, reproduced, or reused without the express written permission of EZ-ACCESS®, a division of Homecare Products, Inc.
PAGE 2
OVERVIEW SCOPE OF WORK: PROVIDE PREFABRICATED MODULAR ALUMINUM ACCESS RAMPS AND STEPS 1. SUBMITTALS 1.1 Product Literature must be submitted with bid. 1.2 Warranty must be submitted with bid. 1.3 Shop Drawings: Include detailed shop drawings upon receipt of purchase order. 1.4 Engineering: Provide sealed professional engineering drawings or empirical independent test results upon request. 2. QUALITY ASSURANCE 2.1 Manufacturer: EZ-ACCESS, a division of Homecare Products, Inc., 700 MILWAUKEE AVE.
PAGE 3
.3 STEPS 3.3.1 3.3.2 3.3.3 3.4 3.5 LEGS 3.4.1 Engineering 3.3.1.1 Step Systems shall be designed for a Uniform Live Load of 100 pounds per square foot (psf) minimum and a concentrated vertical load of 300 pounds over an area of 4 square inches. Materials 3.3.2.1 Step Systems shall be constructed using 6000 series aluminum alloy with 6061-T6 or 6005T5 being used for structural components. Design 3.3.3.1 Step risers shall be between 7” maximum and 4” minimum (6” typical) high and shall be closed. 3.3.
PAGE 4
DIMENSIONAL SPECIFICATIONS   Unless otherwise specified, weights are expressed in pounds; lengths and widths in feet and/or inches. Weights and dimensions are approximate, contact manufacturer for more information. RAMPS           Made with aircraft grade aluminum. Slip resistant Gecko Grip® walking surface. 4” side rail curb height. 1.5” handrail diameter. 36” (nominal) handrail height. 25” (nominal) child handrail height. 42” (nominal) frame (top rail) height.
PAGE 5
PLATFORMS/LANDINGS        Made with aircraft grade aluminum. Slip resistant Gecko Grip® walking surface. 5.5” minimum landing/platform height without support legs. 42” (nominal) frame (top rail) height. 4” (maximum) guard picket spacing. 22” (nominal) frame midrail height (Two-Line Rails). Designed for a uniform live load of 100 lbs. per square foot (psf) min. and a concentrated vertical load of 300 lbs.
PAGE 6
STEPS          Made with aircraft grade aluminum. Slip resistant, knurled Gecko Grip® walking surface. Standard 6” closed risers from 18” - 60”. 1” safety tape standard; 2” safety tape available. Standard useable width 56”. Standard overall width 60”. Typical tread depth 12.5”. Aluminum feet included for leveling on uneven surfaces. Designed for a uniform live load of 100 lbs. per square foot (psf) min. and a concentrated vertical load of 300 lbs. over an area of 4 square inches.
PAGE 7
TRANSITION PLATES (OPTIONAL)   Made with aircraft grade aluminum. Slip resistant walking surface. Length 48” (nominal) 6.73” 54” (nominal) 6.73” 60” (nominal) 6.73” Width 47.38” 53.37” 59.37” 6.4 7.2 8 Weight (lbs.) Anchor hole diameter Anchor (hole to hole) 0.25” DIA. 45.37 51.37 57.
PAGE 8
RAMP & PLATFORM/LANDING VIEWS (CONTINUED) Isometric View FIGURE 3 Elevation View FIGURE 4 Page 8 of 9
PAGE 9
POLYMER FOOT NYLON INSERT LOCKNUT FIGURE 5 Page 9 of 9
