Dimensions Guide

CONTROL OPTIONS:
FP6258BNMW
Ceiling Fan
INSTALLATION REQUIREMENTS:
Fan must be attached to a securely anchored electrical junction
box capable of withstanding a load of at least 35 lbs.
ELECTRICAL REQUIREMENTS:
Requires a grounded electrical supply line of 120 volts AC, 60 Hz, 15
amp circuit.
MOTOR SPECS:
188 x 22 AC motor is designed for optimal performance
with this fan.
PALMA
™
Available Finish
BNMW
Brushed Nickel with Matte White
Housing and Blade
LIGHTING OPTIONS:
One 18-watt LED included.
LOCATION USE:
Fan is rated for dry and damp locations.
A B
Fan w/ 6˝ downrod 15.13˝ 11.05˝
Fan w/12˝ downrod 21.13˝ 17.05˝
Fan w/18˝ downrod 27.13˝ 23.05˝
Fan w/24˝ downrod 33.13˝ 29.05˝
Fan w/36˝ downrod 45.13˝ 41.05˝
Fan w/48˝ downrod 57.13˝ 53.05˝
Fan w/60˝ downrod 69.13˝ 65.05˝
Fan w/72˝ downrod 81.13˝ 77.05˝
BLADES:
A set of three 22˝ composite blades is included.
DOWNROD OPTIONS:
Fan comes with a 1˝ dia. x 6˝ long downrod (DR1-6). Optional downrods are available in 12˝, 18˝, 24˝, 36˝, 48˝, 60˝ and
72˝ lengths. A downrod coupler is available for installations requiring a downrod longer than 72˝. The fan can be mounted
on a sloped ceiling up to 27°. Optional sloped ceiling ball kits (SCB1-52) are available for slope angles greater than 27° and
up to 42°. Optional close-to-ceiling kit is available as well—sold separately. Call technical support for more information.
13° Blade Pitch
Net Hanging Weight: 24.69 lbs
6.50˝ dia
B
A
Airflow / Energy Efficiency Info (120V)
Fan Speed Max RPM CFM CFM / Watts Amps Watts
162 6508 0.63
97 3790 0.39
49 1995
86
129
186
76
29
110.23
High
Med
Low
Light Bulb Information (120V)
Bulb Type Watts Lumens Amount Color Temp CRI
18 1440 3000 80%
LED
Power
(Wave)
Total Air Delivery
(CFMave)
Estimated Yearly
Energy Cost ($)
Ceiling Fan
Efficiency
(CFM/W)
45 3346 13 75
CW60WH-6258 wall control is included. Switch control has 3 fan speeds, infinite light levels and off button. The reverse
switch is on the motor housing. Optional CW1SW and CW2 wall conrtols available—sold separately. Optional BTCR9
and CRL4WH remote controls with receiver unit and BTR9 receiver unit are available—sold separately. Instructions are
provided with each control.
Energy Guide FTC
