Owner's manual

Threaded Stud
Bottom Font
Bottom Finial
Main Frame
Small Threaded
Stud
Ball Cap Nut
Bulb
(not Included)
Socket
Mounting Plate
(E) 04/04
ASSEMBLY INSTRUCTIONS FOR OL3000
MURRAY FEISS
©MURRAY FEISS IMPORT CORP.
IMPORTANT
TURN OFF THE POWER AT THE MAIN
FUSE OR CIRCUIT BREAKER
BOX BEFORE STARTING
INSTALLATION
Carefully unpack and identify all parts 
before assembly. Bulbs are not 
included.
1. Hold main frame securely while 
removing 2 ball cap nut from top cover. 
This will allow the entire bottom 
assembly to drop. Install bulb 
(refer to maximum wattage label on 
socket housing).
2. Place top cover onto small threaded 
studs of main frame and secure with ball 
cap nuts.
3. Twist bottom finial onto threaded stud. 
Slip bottom font over threaded stud and 
screw threaded stud into bottom of
main frame.
4. Follow enclosed
“fixture installation 
instructions”
for electrical installation 
and lantern installation to outlet box.
Top Cover
