Installation Guide

(E) 1/10/05
ASSEMB LY I NST R UCT I ONS FOR W B 1237
MUR R AY FEI SS
© M URRAY FEISS I MPOR T LLC.
IMPORTANT
TURN OFF THE POWER AT THE MAIN FUSE
OR CIRCUIT BREAKER BOX
BEFORE STARTING INSTALLATION
Carefully unpack and identify all 
parts before assembly. Bulb 
not included.
1. Follow first enclosed “Multiple
Standard Installation
Instructions” for electrical and
fixture installation onto wall outlet
box.
2. Install a hex nut onto long threaded
pipe leaving about 1” (25 mm)
thread exposed at bottom. Slip the
short threaded end of the long
threaded pipe through hole which is
located at bottom of fixture plate.
Then lock into position by fastening
with a lock washer and another hex
nut from above.
3. Gently slip glass shade until it rest
onto ring. NOTE: To allow easier
slipping of glass shade, make certain
bottom hole of glass shade pass
through, not over, the socket.
4.  Install fitter onto the long threaded
pipe by fastening with the finial.
5. Install light bulb (not included). See
relamping label at socket area for
type and maximum allowed wattage.
Bulb
(not included)
Mounting Strap
Ring
Fitter
Finial
Cap Nut
Fixture Plate
Glass Shade
Socket
Long threaded pipe
Hex nut
Lock washer
