3.8 Trigger Button Operation
3.9 Landscape and Portrait Shot Switching
Manually move camera to desired position,and hold for half a second, new tilt
position is automatically saved.
Payload in
portrait mode
Load weight:
100~200g
Load weight:
≤130g
Hold the gimbal horizontally, press and hold the trigger button, and then
single tag function button to switch between landscape and portrait mode.
Press and hold
the trigger button
Press and hold
the trigger button
Single tap the
function button
Single tap the
function button
Reset to
Landscape Mode
Portrait Mode
Reset to
Landscape Mode
Portrait Mode
Effected only when tilt axis on right side.
Please power off the gimbal first.
Press buttons to switch
Rotate the Smartphone Holder to switch
1
1
2
2
Switching portrait /landscape mode by manually rotate the smartphone
holder left or right.
