O P E R AT I N G MANUAL EN FIBARO MOTION SENSOR FGBHMS-001 CONTENTS #1: Description and features #2: Powering the accessory #3: Pairing the accessory #4: Physical installation #5: Reset v1.
Important safety information ! Read this manual before attempting to install the device! Failure to observe recommendations included in this manual may be dangerous or cause a violation of the law. The manufacturer, Fibar Group S.A. will not be held responsible for any loss or damage resulting from not following the instructions of operating manual.
#1: Description and features FIBARO Motion Sensor is a HomeKit-enabled multi-sensor using Bluetooth® low energy technology. Along with detecting motion, the accessory measures the ambient temperature and light intensity. The sensor has a built-in accelerometer to detect any tampering with the accessory. FIBARO Motion Sensor is battery powered and designed to be installed quickly and easily on any surface.
#2: Powering the accessory 1. Turn the cover counter-clockwise and open it. i NOTE Remember to use only battery type specified in the manual and keep the right polarity. i 2. Remove the battery blocker and check if the battery is placed correctly. NOTE If the accessory blinks green after powering, it is already paired and has to be reset to pair again. 3. The accessory will glow red – it is ready to be paired. 4. Close the cover and turn it clockwise, dots on the casing should align.
#3: Pairing the accessory 1. Open the Settings app on your iOS device. 2. Go to the Bluetooth® section, and turn the Bluetooth® on. 3. Place the accessory next to your iOS device. 4. Open a HomeKit compatible app of your choosing on your iOS device. 5. Open pairing window in your HomeKit app to detect available accessories. 6. Choose Motion Sensor you wish to pair. 7. You can identify it - Motion Sensor will triple blink blue 3 times. 8.
#4: Physical installation Installing the Motion Sensor: 1. Install the holder (using an expansion bolt or a sticker). Sticker 2. Insert the device into the holder. 3. Test the operation - check whether the accessory indicates motion detection. Installation location and working conditions: The Motion Sensor should be installed in a corner of the room or perpendicularly to the doors.
#5: Reset Resetting the Motion Sensor to factory defaults: Reset procedure allows to restore the accessory back to its factory settings including HomeKit pairing. 1. Open the cover. 2. Press and hold the button. Button 3. Wait for the LED indicator to glow yellow. 4. Release the button. 5. Click the button to confirm. 6. Accessory will glow red to confirm reset. 7. Delete the accessory from the app before pairing it again.
#6: Functionality Motion detection: The Motion Sensor detects movement using PIR sensor and reports it to your iOS device. Blink of LED indicates detected motion. Color of blink is dependent on current ambient temperature (smooth transition through blue, green and red). Brightness of blink is adjusted by measured light intensity. Tamper detection: The Motion Sensor detects tampering when accessory is moved and reports it to your iOS device.
#7: Configurable parameters 1. Motion detection – sensor sensitivity This parameter allows to set sensitivity of PIR sensor used for motion detection. The higher the value of this parameter, the higher the sensitivity. Available settings: 1 – low sensitivity 2 – medium sensitivity Default setting: 3 – high sensitivity 2 (medium sensitivity) 2. Tamper – sensor sensitivity This parameter allows to set sensitivity of tamper detection. The higher the value of this parameter, the higher the sensitivity.
5. Motion detection - sustain time This parameter allows to set how long the information about detected motion is sustained by the accessory. Each subsequent motion detection causes time to be counted from the beginning.
#8: Specifications Power supply: 3.0V DC battery Battery type: CR123A EU directives compliance: RoHS 2011/65/EU RED 2014/53/EU Radio protocol: Bluetooth® low energy Radio frequency: 2.4 GHz Range: up to 50m (free range) (164 feet) Recommended installation height: 2.4 meters (7.87 feet) Operating temperature: 0-40°C (32-104°F) Temperature measuring range: 0-40°C (32-104°F) Temperature measuring accuracy: ±0.5°C (±0.
#9: Regulations This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: 1. This device may not cause harmful interference 2. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
DGT Warning Statement Article 12 Without permission, any company, firm or user shall not alter the frequency, increase the power, or change the characteristics and functions of the original design of the certified lower power frequency electric machinery.
Declaration of conformity Hereby, Fibar Group S.A. declares that the device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.manuals.fibaro.com WEEE Directive Compliance Device labelled with this symbol should not be disposed with other household wastes.
