Contents Safety Information........................................... 2 Getting Started........................................................ 3 Notifications & Features & Accessories................... 3 Remote Control - 1 ................................................. 6 Connections............................................................ 7 First Time Installation - USB Connections............... 8 TV Menu Features and Functions..........................11 General TV Operation......................
Safety Information If there is lightning or storms, or if the TV is not going to be used for a while (e.g. if going away on holiday), disconnect the TV set from the mains. The mains plug is used to disconnect TV set from the mains and therefore it must remain readily operable. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Getting Started Notifications & Features & Accessories • Headphone connection. Environmental Information This television is designed to consume less energy to help save the environment. To reduce energy consumption, you should take the following steps: You can use the Power Save Mode setting, located in the Picture menu. If you set the Power Save Mode as Eco, the TV will switch to energy-saving mode and the luminance level of TV set will be decreased to the optimum level.
Operation with the Buttons on the TV Press Notification button to decrease volume or button to increase volume. Press P/CH + button to select the next programme or P/CH - button to select Manufactured under license from Dolby Laboratories. TRADEMARK ACKNOWLEDGMENT the previous programme. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories. Press the or button at the same time to view main menu. In the Main menu select sub-menu using TV/AV button and set the submenu using or buttons.
Specification Teletext TV Broadcasting PAL B/G D/K K Receiving Channels VHF (BAND I/III) - UHF (BAND U) - HYPERBAND Press “ ” button to enter. Press again to activate mix mode. Press once more to exit. Follow the instructions displayed on digital teletext screen. Number of Preset Channels 1.000 Channel Indicator On Screen Display RF Aerial Input 75 Ohm (unbalanced) Operating Voltage 220-240V AC, 50Hz. Audio German + Nicam Stereo Audio Output Power (WRMS.
Getting Started Remote Control - 1 1. Source 2. Sleep Timer 3. Internet Portal 4. Play ( in media browser mode ) 5. Programme recording 6. Rapid reverse 7. Mono/Stereo - Dual I-II / Current language (in DVB channels) 8. Green button 9. Red button 10. Numeric buttons 11. Channel List/TV source 12. Menu 13. Volume up / down 14. Back (Return) / Index (in TXT mode) 15. Favourite channel list 16. Expand (in TXT mode) / Screen size 17. My button 1 / Youtube (*) 18. My button 2 (**) 19.
Getting Started Connections Connector Type Cables Device Scart Connection (back) Mini Scart Connection (rear bottom) Mini Scart adapter cable (supplied) VGA Connection (back) PC/YPbPr Audio Connection (back) Side Audio YPbPr or PC Connection Cable (not supplied) HDMI Connection (bottom&side) S/PDIF (Optical Out) Connection (bottom) Side AV (Audio/Video) Connection (side) Side AV Connection Cable (supplied) Headphone Connection (side) YPbPr Video Connection (side) YPbPr Connection Cable(not suppli
Getting Started First Time Installation - USB Connections Cable Installation Switching On/Off To Switch the TV On Connect the power cord to the 220-240V AC, 50 Hz. To switch on the TV from standby mode either: Press the “ ” button, P+ / P- or a numeric button on the remote control. To Switch the TV Off Press the “ ” button on the remote control or press the “ ” touch button on the TV. The TV will now switch to standby mode. To power down the TV completely, unplug the power cord from the mains socket.
Recording a Programme IMPORTANT: When using a new USB hard disk drive, it is recommended that you first format the disk using your TV’s “Format Disk” option. Note: To record a programme, you should first connect a USB disk to your TV while the TV is switched off. You should then switch on the TV to enable the recording feature.
Media Browser Menu You can play photo, music, and movie files stored on a USB disk by connecting it to your TV. Connect a USB disk to one of the USB inputs located on the side of the TV. Pressing the MENU button while in the Media Browser mode will access the Picture, Sound and Settings menu options. Pressing the MENU button again will exit from this screen. You can set your Media Browser preferences by using the Settings Menu.
TV Menu Features and Functions Picture Menu Contents 3D Settings Press to view 3D settings. Mode You can change the picture mode to suit your preference or requirements. The Picture mode can be set to one of these options: Cinema, Game, Sports, Dynamic and Natural. Contrast Sets the lightness and darkness values of the screen. Brightness Sets the brightness value for the screen. Sharpness Sets the sharpness value for the objects displayed on the screen.
Sound Menu Contents Volume Adjusts the volume level. Equalizer Selects the equalizer mode. Custom settings can be made only when in user mode. Balance This setting is used for emphasizing left or right speaker balance. Headphone Sets headphone volume. Sound Mode You can select a sound mode (if the selected channel supports). AVL (Automatic Volume Limiting) This function sets the sound to obtain fixed output level between programmes.
Application Version Displays application version. Hard of Hearing Enables any special feature sent from the broadcaster. Audio Description Audio description refers to an additional narration track for blind and visually impaired viewers of visual media, including television and movies. You can use this feature, only if the broadcaster supports that additional narration track. Note: Audio description sound feature cannot be available in recording or time shifting mode.
General TV Operation Using the Channel List The TV sorts all stored stations in the Channel List. You can edit this channel list, set favourites or set active stations to be listed by using the Channel List options. Configuring Parental Settings To prohibit viewing of certain programmes, channels and menus can be locked by using the parental control system. To display parental lock menu options, the PIN number should be entered. The factory default PIN number is 0000.
CAUTION - 3D Images • Read these safety instructions carefully to prevent damage.and ensure your personal safety. • Consult an optometrist if you experience any diffictulties while watching in 3D with your 3D glasses. • You may experience headaches or fatigue when viewing 3D images with your 3D glasses for too long. • If you experience headaches, fatigue, or dizziness, stop watching immediately.
3D Mode Viewing Distance Press the MENU button and select the Picture icon using the “ ” or “ ” buttons and press OK. Use “ ” or “ ” to select 3D settings and press OK to view. • 3D feature enables you to view 3D content using the supplied 3D glasses. • To enable and customize 3D mode on the TV, perform the following: • Press MENU button on the remote control and select Picture by using “ ” or “ ” button. Press OK button to view Picture Settings.
3D Viewing Information - continued • Connect your PC to your modem/router. This can be a wired or wireless connection.
IP Address If an active connection is available, the IP address will be displayed on this section. If you want to configure an IP address preferences, press the GREEN button and switch to the advanced mode. Configuring Wired Network Settings in Advanced Mode After pressing the GREEN button, the “Advanced mode” will be available. While in Advanced Mode, press the RED button to edit settings. When finished, press OK to save, Press RETURN/BACK to cancel.
Wait until the IP address is shown on the screen. Connectivity Troubleshooting This means that the connection is now established. To disconnect from a wireless network press OK. Wireless Network Not Available You can navigate between menu tabs by pressing left/ right buttons. The help bar on the bottom of the dialog shows features that you may use. Press the BLUE button to check your internet connection speed.
DLNA Internet Portal DLNA support is only available in the Media Browser folder mode. To enable folder mode, go to the Settings tab in the main media browser screen and press OK. In the settings options, highlight View Style and change to Folder using the Left or Right buttons. Select the desired media type and press OK. If sharing configurations are set properly, an OSD message will be displayed after selecting the desired media type. Select OK to display the selected network or USB memory content.
iPlayer Application You can access BBC iPlayer using your TV. To do this, an active internet connection is required. (See connecting to a Wired/Wireless Network section to connect your TV to internet). After the connection is established, you can select BBC iPlayer among the portal options. (See Internet Portal) Press the OK button on your remote control to start the BBC iPlayer application. Note: Broadband internet connection (minumum 2mbps) is required for high quality viewing.
Internet Browser To use the internet browser, please select the internet browser logo from the portal section. Refresh Home Page Address Bar Add History Bookmarks Zoom Previous Next Settings Remote control shortcuts (Zoom in-out/Back/Home) Quick Access • To navigate the web browser, use the arrow buttons on the remote control. Press OK to continue. pages and these will take you to the appropriate pages.
Getting Started with Skype Make voice calls and video calls with Skype on your TV. Select the Skype app from the portal section to start a conversation. Follow the on screen instructions to see how to operate related features. NOTE • Connect your supported webcam directly to the USB port on your TV. • If the camera is not working properly, switch off and unplug the TV. Connect your camera again and turn the TV on. • As soon as the TV is turned off, Skype disconnects.
Sign In & Sign Up Now To use the Skype application, you need a Skype account. You can create a Skype account, using this app, in the ‘Sign In & Sign Up Now’ menu if you don’t already have one. If you already have a Skype account, enter your name and password correctly. Select Sign In and press OK. If you have a Skype account and you forgot your password, press the Red button to view the “reset password” screen. After successfully logging in to your account, the contact list will be displayed on screen.
Adding a contact By pressing the button select the “Search Contacts” option. Enter the full name, skype name or email address of the contact you want to find and add. Use the remote control or virtual keyboard to enter a keyword. Recent history Incoming call Outgoing call Missed call Icon meaning Your Skype history can be seen in this section. To view recent history options, use the p+ and p- buttons. To delete a conversation, press the Red button.
Actions Account Name, mood message and profile picture. Online status Select a Menu by pressing the button. Your contact list (Press Ok to use video&voice call) Help bar Select a person from the contact list screen and press OK. Choose an action from the list and then press OK to start the selected process. Voice and video call is ready for your use. If available you will see the thumbnail view of yours and the other person’s camera feed.
Incoming call The incoming call dialog is shown when you are logged into Skype and when other users initiate a Skype call. A small dialog box will appear in the lower right corner of the TV screen whether the user watches TV or is browsing through Skype. Use the remote control button and choose your action. Dialing Phones The option to call phones is available if you have Skype Credit. Please buy credit first. Afterwards, select a country then enter a phone number which you want to call.
Software Upgrade Your TV is capable of finding and updating automatically via the Aerial/Cable signal or over the Internet. Software upgrade search via user interface Simply navigate on your main menu. Choose Settings and select Other Settings menu. In Other Settings menu navigate on to the Software for Upgrade item and press OK button to check for a new software upgrade. Note : Internet connection is needed. If an internet connection is not available, try to upgrade via broadcast.
• The Select Installation Type screen is displayed. It is possible to choose between Typical, meaning standard installation, or Custom installation. User defined installation allows you to determine languages to be installed and to choose the installation path. 7. Use Typical installation and click the Next button. • The Prerequisites screen is displayed. The Nero MediaHome installation wizard checks the availability of required third-party software on your PC.
PC Input Typical Display Modes The following table is an illustration of some of the typical video display modes. Your TV may not support all resolutions. Your TV supports up to 1920x1200.
Supported File Formats for USB Mode Media Movie Extension Format Notes Video Audio dat, mpg, mpeg Mpeg1,2 MPEG1/2 Layer 1/2/3, AAC/HEAAC, AC3/EAC3, LPCM/ADPCM 1080P@ 30fps 50Mbit/sec dat, mpg, mpeg MPEG2 ,H.264, VC1, AVS, MVC MPEG1/2 Layer 1/2/3, AAC/HEAAC, AC3/EAC3, LPCM/ADPCM H.264:1080Px2@25fps 1080P@ 50fps MVC: 1080P@ 24fps Other: 1080P@ 30fps” 50Mbit/sec .vob MPEG2 MPEG1/2 Layer 1/2/3, AC3, LPCM 1080P@ 30fps 50Mbit/sec .mkv MPEG1,2,4, XviD, MPEG1/2 Layer 1/2/3, AAC/HEAAC, H.
Important Instruction For your own safety read following instruction carefully before attempting to connect this unit to the mains supply.
A Product Fiche B Commercial Brand: FINLUX C Product No. 10087582 D Model No. 47F9076-T E Energy efficiency class A F J Visible screen size (diagonal, approx.
