User Manual

Configuration Appendix C: MS-9600
ACM-8RF PN 50362:C 03/21/01
39
Mode Select
Alarm Only or Alarm/Trouble Mode
Determine if “alarm only” mode or “alarm/trouble” mode is to be used and set
the Mode Select switch SW4-1 as described in "Mode Select Switch - SW4"
on page 16 and below.
If “alarm only” is selected, relays 1 to 8 will activate when an alarm signal is
received from a zone or point.
Table 14 Alarm Only Setup
If “alarm/trouble” is selected, then relays 1 to 4 will activate when an alarm
signal is received from a zone or point and relays 5 to 8 will activate when a
trouble signal is received from a zone or point.
Table 15 Alarm and Trouble Setup
Receive Only or Receive/Transmit Mode
Determine if “receive only” mode or “receive/transmit” mode is to be used and
set the Mode Select switch SW4-2 as described in "Mode Select Switch - SW4"
on page 16.
Note: Only one EIA-485 device per address may be set for receive/transmit.
Zone or Point
Alarm
Signal
1, 9, 17 etc. or 65, 73, 81 etc. Relay 1
2, 10, 18 etc. or 66, 74, 82 etc. Relay 2
3, 11, 19 etc. or 67, 75, 83 etc. Relay 3
4, 12, 20 etc. or 68, 76, 84 etc. Relay 4
5, 13, 21 etc. or 69, 77, 85 etc. Relay 5
6, 14, 22 etc. or 70, 78, 86 etc. Relay 6
7, 15, 23 etc. or 71, 79, 87 etc. Relay 7
8, 16, 24 etc. or 72, 80, 88 etc. Relay 8
Zone or Point
Alarm
Signal
Zone or Point
Trouble
Signal
1, 9, 17 etc. or 65, 73, 81 etc. Relay 1 5, 13, 21 etc. or 69, 77, 85 etc. Relay 5
2, 10, 18 etc. or 66, 74, 82 etc. Relay 2 6, 14, 22 etc. or 70, 78, 86 etc. Relay 6
3, 11, 19 etc. or 67, 75, 83 etc. Relay 3 7, 15, 23 etc. or 71, 79, 87 etc. Relay 7
4, 12, 20 etc. or 68, 76, 84 etc. Relay 4 8, 16, 24 etc. or 72, 80, 88 etc. Relay 8
