Setting the DIP Switches
The DIP switch (SW3), in combination with the Rotary Switches, is used to
determine which FACP activations will trigger relays on the ACM-8RF.
As described previously, the selection of “Alarm Only” or “Alarm/Trouble”
will determine how each module controls its relays. The difference between
these two settings is described below.
Alarm Only Activation
When “Alarm Only” is selected all relays respond to alarm signals.
The following table displays a dual example (zones & modules) of how to set
the DIP switches on two (2) ACM-8RFs to annunciate the zones or points of
an annunciator address. Although this table shows System Points & Zones 1
to 8 (address 01) and Loop 1, Points M65 to M80 (address 05), by referring to
Table 13 on page 38 it can be determined which ACM-8RF will activate what
zone or point, depending on the address that is set on the rotary switches.
Table 16 SW3 Settings for Alarm Only
Note: If the System Points (system alarm) is not required, up to seven (7) ACM-8RFs
may be used to allow activation of FACP zones 1 through 56. When using this
configuration do not use the DIP Switch settings for the 1st ACM-8RF.
ACM-8RF
Relay
MS-9600 Zone
1
or Point
2
1. As per Table 13 the Rotary Switches (SW1 & SW2) are set to address ‘01’ for
System Points and Zones 1 to 56.
2. As per Table 13 the Rotary Switches (SW1 & SW2) are set to address ‘05’ for
Loop 1, Address M65 to M128.
1st ACM-8RF
SW3-1 = ON
SW3-5 = ON
All others = OFF
Relay 1 System Alarm or Loop 1, Address M65
Relay 2 Not Used or Loop 1, Address M66
Relay 3 Not Used or Loop 1, Address M67
Relay 4 Not Used or Loop 1, Address M68
Relay 5 Not Used or Loop 1, Address M69
Relay 6 Not Used or Loop 1, Address M70
Relay 7 Not Used or Loop 1, Address M71
Relay 8 Not Used or Loop 1, Address M72
2nd ACM-8RF
SW3-2 = ON
SW3-5 = ON
All others = OFF
Relay 1 Zone 1 or Loop 1, Address M73
Relay 2 Zone 2 or Loop 1, Address M74
Relay 3 Zone 3 or Loop 1, Address M75
Relay 4 Zone 4 or Loop 1, Address M76
Relay 5 Zone 5 or Loop 1, Address M77
Relay 6 Zone 6 or Loop 1, Address M78
Relay 7 Zone 7 or Loop 1, Address M79
Relay 8 Zone 8 or Loop 1, Address M80
