User Manual

Appendix C: MS-9600 Configuration
42
ACM-8RF PN 50362:C 03/21/01
The following table displays an example of how to set the DIP switches on four
(4) ACM-8RFs to annunciate the points of an annunciator address. Although
this table shows Points M65 to M80 (address 05), by referring to Table 13 on
page 38 it can be determined which ACM-8RF will activate what zone or point,
depending on the address that is set on the rotary switches.
Table 18 SW3 Settings for Alarm/Trouble - Points
Multiple ACM-8RFs
The table below provides DIP switch (SW3) settings for the use of multiple
ACM-8RFs. Only those switches listed in the ON column are placed in the
‘ON’ position. All other switches are to be in the ‘Off’ position.
Table 19 DIP Switch Settings for Multiple ACM-8RFs
ACM-8RF
Alarm Relay
MS-9600 Point
ACM-8RF
Trouble Relay
MS-9600 Point
1st ACM-8RF
SW3-1 = ON
SW3-5 = ON
All others = OFF
Relay 1 Loop1-Address M65 Relay 5 Loop1-Address M65
Relay 2 Loop1-Address M66 Relay 6 Loop1-Address M66
Relay 3 Loop1-Address M67 Relay 7 Loop1-Address M67
Relay 4 Loop1-Address M68 Relay 8 Loop1-Address M68
2nd ACM-8RF
SW3-2 = ON
SW3-5 = ON
All others = OFF
Relay 1 Loop1-Address M69 Relay 5 Loop1-Address M69
Relay 2 Loop1-Address M70 Relay 6 Loop1-Address M70
Relay 3 Loop1-Address M71 Relay 7 Loop1-Address M71
Relay 4 Loop1-Address M72 Relay 8 Loop1-Address M72
3rd ACM-8RF
SW3-3 = ON
SW3-5 = ON
All others = OFF
Relay 1 Loop1-Address M73 Relay 5 Loop1-Address M73
Relay 2 Loop1-Address M74 Relay 6 Loop1-Address M74
Relay 3 Loop1-Address M75 Relay 7 Loop1-Address M75
Relay 4 Loop1-Address M76 Relay 8 Loop1-Address M76
4th ACM-8RF
SW3-4 = ON
SW3-5 = ON
All others = OFF
Relay 1 Loop1-Address M77 Relay 5 Loop1-Address M77
Relay 2 Loop1-Address M78 Relay 6 Loop1-Address M78
Relay 3 Loop1-Address M79 Relay 7 Loop1-Address M79
Relay 4 Loop1-Address M80 Relay 8 Loop1-Address M80
ON ON
1st ACM-8RF 1 & 5 9th ACM-8RF 1 & 7
2nd ACM-8RF 2 & 5 10th ACM-8RF 2 & 7
3rd ACM-8RF 3 & 5 11th ACM-8RF 3 & 7
4th ACM-8RF 4 & 5 12th ACM-8RF 4 & 7
5th ACM-8RF 1 & 6 13th ACM-8RF 1 & 8
6th ACM-8RF 2 & 6 14th ACM-8RF 2 & 8
7th ACM-8RF 3 & 6 15th ACM-8RF 3 & 8
8th ACM-8RF 4 & 6 16th ACM-8RF 4 & 8
