All Avalon restyles are proudly made in the U.S.A.

www.avalonrestyle.com

Firestyles for Life

Your Authorized Avalon Dealer Is Located At:

Photos and illustrations are for descriptive purposes only. We reserve the right to improve or change our products without prior notication.

Ember-Fyre™, GreenSmart™ and all other trademarks belong to Travis Industries, Inc. Consult the Owner’s Manual for complete installation requirements.

Hearth Requirements:

A 12” non-combustible hearth extension is required in front of the replace opening..

Fireplace Requirements:

Insert must be placed within a code-conforming masonry or tested and

listed factory-built (metal) wood burning replace. Because the insert uses

a circulation blower, clean the replace, smoke shelf, and chimney prior to

installation. is heater may be placed in a bedroom. Please be aware of the

large amount of heat this appliance produces when determining a location.

Installation Specications

Always refer to and use the Installation Manual for

complete install information.

Fireplace Sizing

Minimum Height: 24 1/4” (616mm)

Minimum Width: 35” (889mm)

Minimum Depth: 16 1/2” (420mm)

Non-Combustible Hearth Depth: 12” (305mm)

e gas and electrical line should be installed prior to installing the heater.

For tight ts (under 28”) see the owner’s manual

See the owner’s manual “Leveling Bolts” for details on leveling the heater.

Sidewall to Insert: 6” (153mm)

Side Facing: 5” (127mm) (non-combustible)

Top Facing: 35 1/2”” (902mm)

12” Mantel: 36.5” (926mm) (combustible or non-combustible)

4” Mantel: 33” (839mm) (combustible or non-combustible)

Extension onto Hearth: 12” (305mm)

*Measured from the base of the insert. NOTE: the non-combustible top facing must extend

35.5” (902mm) above the base of the insert or to the bottom of the mantel (which ever is less)

Listings:

is appliance is listed by INTERTEK Test Labs to ANSI Z21.88 - 2009 report

#G100405040PRT-001. e listing label is attached to the appliance near the gas control valve.

IAS (ICBO) Approval

is appliance is listed by INTERTEK Test Labs - IAS # TL474.

Massachusetts Approval

is product must be installed by a licensed plumber or gas tter when installed within the

Commonwealth of Massachusetts.

Clearances To Combustibles

Children, like most of us, are fascinated by re, and for

families with young children, replaces pose a potential

safety hazard. If you have an infant or toddler consider

installing a re screen; make sure it’s tall enough so

that children can’t climb over it, and that it’s placed

far enough away so that reaching arms can’t touch the

surfaces of the replace. A few precautions such as these

will allow everyone in your home to safely enjoy the

comfort and warmth of your new gas replace insert.

Model 616 GSR

GreenSmart2™ Gas Inserts

GREEN

SMART

Summary of content (4 pages)

PAGE 1
Model 616 GSR GreenSmart2™ Gas Inserts All Avalon firestyles are proudly made in the U.S.A. Installation Specifications Always refer to and use the Installation Manual for complete install information. Fireplace Requirements: Insert must be placed within a code-conforming masonry or tested and listed factory-built (metal) wood burning fireplace. Because the insert uses a circulation blower, clean the fireplace, smoke shelf, and chimney prior to installation. This heater may be placed in a bedroom.
PAGE 2
Model 616 GSR2 (GreenSmart2 with Remote) The 616 GSR2 showcases a fire that is second to none. It boasts a big heat output with a huge fireviewing area. A traditional hearth look is achieved by having the controls laterally located and having the ceramic glass go almost all the way to the hearth. This allows for an increased glass viewing area by almost 20% over traditional gas inserts.
PAGE 3
Model 616 GSR2 (GreenSmart2 with Remote) The 616 showcases a fire that is second to none. It boasts a big heat output with 616 square inches of viewing area. A traditional hearth look is achieved by having our ceramic glass go almost all the way to the bottom of the unit, and hearth. This gas insert converts an existing masonry or metal fireplace into an efficient heater while preserving the charm of a traditional fireplace.
PAGE 4
Model 616 GSR GreenSmart2™ Gas Inserts All Avalon firestyles are proudly made in the U.S.A. Installation Specifications Always refer to and use the Installation Manual for complete install information. Fireplace Requirements: Insert must be placed within a code-conforming masonry or tested and listed factory-built (metal) wood burning fireplace. Because the insert uses a circulation blower, clean the fireplace, smoke shelf, and chimney prior to installation. This heater may be placed in a bedroom.
