FireFinder XLS

6300

s Industry, Inc.

Building Technologies Division

CatalogSheet

FireSafety&Security Products

FireFinder XLS

FireFinder XLS Fire Alarm Control Panel

System Overview

FireFinder XLS is a microprocessor-based, advanced

life-safety system that has a 6" display and large, lighted

buttons – making it the most intuitive fire-alarm user

interface in the industry. Its use of the unique multiprocessor

"Network" design, along with its ability to utilize analog and

conventional detection devices, makes it an extremely

flexible and configurable life-safety system.

XLS is ideally suited for commercial, institutional and

industrial fire detection and notification applications.

XLS complies with the requirements of NFPA

Standard 72, and is listed by Underwriters Laboratories

under their standard

UL 864.

Underwriter's Laboratories of Canada also lists the XLS for fire

applications under

ULC-S527. XLS is approved by Factory

Mutual; as well as CSFM and NYMEA for use in those specific

locales. In addition to the standard fire applications, XLS is

listed by Underwriters Laboratories under the category UUKL for

smoke control. XLS can be used as a listed Fireman's Smoke

Control Station in high-rise office buildings, malls and other

large structures.

XLS is listed by

UL Listed and FM Approved for Sinorix

clean-agent systems and pre-action or deluge sprinkler systems,

which include foam or water applications. XLS follows the

releasing requirements,

specified in NFPA 13 and 2001.

• Standard 2500 addressable, point-

capacity system

• Ability to network with other FireFinder

XLS systems

• Powerful, easy-to-use programming

capabilities

• Fully field programmable, via Windows®

laptop PC

• 6" Backlit LCD display

• User-friendly system interface

• Touch screen for maintenance operations

and function keys

• Global annunciation and control

capability

• Multi-language display

• Universal AC power input:

120VAC, 50/60Hz

• Support of 220/240VAC, via step-down

transformer

• 12 amps of system power

(expandable to 48 amps)

• Numerous Relays: Alarm, Trouble,

Programmable, etc.

• SureWire addressable-loop technology

• Polarity-insensitive detection circuits

(patented)

• Useful diagnostic LEDs on all cards

• Supports FirePrint application-specific

detection

• Intelligent / analog detection circuits:

Class A or Class B

• Detector Sensitivity Readout / Printout,

per NFPA 72

• Supervised remote printer

• 32-character custom messages

• Thermal strip printer

• Security-device monitoring ( UL 1076 Listed)

• Sprinkler Supervision

• Seismic Certified

• UUKL Listed for smoke control

• UL 864 9

Edition Listed & ULC Listed;

FM, CSFM & NYMEA Approved

• Multiple command stations

• Menu-driven operator commands

• 5000-event, history-logging capability

with on-line & off-line reports

• User help screens

• Multiple levels of password protection

• Automatic environmental compensation

for smoke detectors

• Alarm verification by Device or Zone

• Logic-controlled output functions

• Time-based-controlled output functions

• Holiday schedule

• City tie / leased line

• Coded outputs

• 200 notification-appliance-circuits

(NACs) capacity

• Up to 3.0 amps (24VDC) per NAC

• Built-in strobe synchronization protocol

• Supports pre-action, deluge and agent

releasing

• Voice evacuation system (optional)

• Modular assembly

• NEC 760 power-limited circuits

(

UL 864 Compliant)

• Intelligent interface to building /

process

management systems

• Degrade-mode operation

Summary of content (12 pages)

PAGE 1
s Catalog Sheet Fire Safety & Security Products FireFinder XLS FireFinder XLS Fire Alarm Control Panel • • • • • • • • • • • • • • • • • • Standard 2500 addressable, pointcapacity system Ability to network with other FireFinder XLS systems Powerful, easy-to-use programming capabilities Fully field programmable, via Windows® laptop PC 6" Backlit LCD display User-friendly system interface Touch screen for maintenance operations and function keys Global annunciation and control capability Multi-language dis
PAGE 2
System Overview ─ (continued) The FireFinder XLS system has been seismic qualified in accordance with: International Building Code, 2006 Edition California Building Code, 2007 Edition ASCE Standard 7, 2005 Edition OSHPD CAN 2-1708A.5, Rev. 3 ICC-ES AC 156, Effective 1/1/2007 FireFinder XLS is also OSHPD preapproved under: OSP-0057-10.
PAGE 3
NIC-C Network Interface Card ZIC-4A Zone Indicating Card ZIC-4A Zone Indicating Card NIC-C The Zone Indicating Card (Model ZIC-4A) provides four (4) fully supervised, programmable output circuits for use on the FireFinder XLS Fire Alarm Control Panel. Model ZIC4A supplies four (4) Class B (Style Y) or Class A (Style Z) type output circuits, power limited to 3.0 amps maximum per circuit.
PAGE 4
Model HLIM does not occupy a device address on the Model DLC circuit, and does not require programming. Up to 15 Model HLIM modules may be installed on each Model DLC loop. SIM-16 Supervised Input Module SIM-16 Supervised Input Module HCP Control Point Module HCP Model HCP provides an intelligent control point for the FireFinder XLS Control Panel. Model HCP can be programmed as an independent, remotely located telephone zone, speaker zone or notification appliance circuit.
PAGE 5
All cards plugged into the CC-5 / CC-2 card cage communicate with other FireFinder-XLS modules via a common data bus. Connectors are provided on the left and right side of the CC-5 to connect a 60-pin cable for communications with the FireFinder-XLS' operator interface, power supplies and amplifiers modules. Field wiring to devices and circuits terminates on the Models CC-5 / CC-2 card cages.
PAGE 6
PSC-12 Power Supply Charger Module PSX-12 Power Supply Extender PSC-12 Power Supply Charger Module PSX-12 Power Supply Extender The Power Supply Charger Module (Model PSC-12) is a high-current power supply that provides the FireFinder XLS primary-regulated 24VDC power to operate. Model PSC-12 is rated at 12Amps (Alarm) / 5Amps (Standby), and has a built-in battery charger, capable of charging up to 100 AH batteries.
PAGE 7
System-Status Display SSD Series System-Status Display The System Status Display (SSD Series Models) is a remote LED / LCD display that shows the local status of a FireFinder XLS system. An LED illuminates when Alarm, Supervisory, Trouble, and Security events occur on the system. A (4) four-line liquid-crystal display (LCD) will give details of the event in alphanumeric form. The display can be toggled to display additional events. Optional remote system control capabilities are available.
PAGE 8
Enclosure Trim Kits Trim kits are available for all system enclosures for semiflush mounting applications. Model CAB1-TK (for black enclosures) and the Model CAB1R-TK (for red enclosures) fit inside the Models CAB1 and CAB1-R enclosures. Similarly, Models CAB2-TK and CAB-2R-TK fit inside the Model CAB-2 enclosure, while Models CAB3-TK and CAB3RTK fit the Model CAB-3 enclosure.
PAGE 9
ID-MP Inner Door Mounting Plate The Inner Door Mounting Plate (Model ID-MP) is mounted on the inner door of any given model CAB enclosure. Model ID-MP plates are used to mount switch-control modules (Model SCM-8); LED control modules (Model LCM-8), or fan-control modules (Model FCM-6). Four (4) mounting plates are included in each Model IDMP.
PAGE 10
Remote System Enclosures Models REMBOX2 and REMBOX4 are FireFinder XLS system enclosures that are used for remotely mounting innerdoor modules like the Model PMI interface, switch modules, Model LVM live voice modules, and Model FMT firefighters master telephone modules. Models REMBOX2 and REMBOX4 are thinner than the regular CAB series of enclosures – just 5" (12.7cm.) deep overall, and are perfect for mounting in places where space is limited (e.g.
PAGE 11
Details for Ordering s Industry, Inc.
PAGE 12
Notice: This marketing catalog sheet is not intended to be used for system design or installation purposes. For the most up-to-date information, refer to each product’s installation instructions. s Industry, Inc. Building Technologies Division Fire Safety 8 Fernwood Road Florham Park, NJ 07932 Tel: (973) 593-2600 FAX: (908) 547-6877 URL: www.SBT.Siemens.com/FIS (SII‐FS) Printed in U.S.A.
