Datasheet

SM- Stabilized Metal Film MELF Resistor
1.2/50us PEAK PULSE
5 pulses at 12-sec interval for 0.5% permanent change
10
100
1000
10000
RESISTANCE VALUE
PEAK VOLTAGE (volt)
1Ω 10Ω 1 0 0Ω 1K Ω 10K Ω 10 0 K Ω 1M Ω
SM207, SM52
SM16, SM204
POWER DERATING CURV
E
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
30 40 50 60 70 80 90 100 110 120 130
AMBIENT TEMPERATURE (
o
C)
RATE
D
LOAD
SURGE POW ER DERATING CURVE
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
0.0001 0.001 0.01 0.1 1 10
Surge Duration
Surge OFF time
Papplicable - Prate
d
P
surge
SINGLE SURGE PERFORMANCE
0.00001s 0.0001s 0.001s 0.01s 0.1s 1s
SURGE DURATION
PEAK POWER (watt)
100
10
1
10us 100us 1ms 10ms 100ms 1s
0.
1
SM207, SM52
SM16, SM204
Notes:
1. Above graph is accurate for NON REPETITIVE applications operating in an ambient
temperature of 70°C or less. For temperatures above 70°C, the graph power must be derated
further linearly down to zero at 125°C.
2. For applicable surge power in continuous-surge applications please see SURGE POWER
DERATING CURVE above.
Aug. 28, 2004
