Wall canopy HC60PCIX2 & HC90PCIX2 models Installation instructions and User guide NZ AU
Contents Safety and warnings Installation instructions Getting started quickly Cleaning and maintenance Manufacturer’s warranty Customer care Important! SAVE THESE INSTRUCTIONS The models shown in this User Guide may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please visit our local website listed on the back cover or contact your local Fisher & Paykel dealer.
2 Safety and warnings Important! Please read the entire set of instructions before installing the wall canopy. This wall canopy is not intended for use by young children or infirm persons without supervision. Young children should be supervised to ensure that they do not play with the wall canopy. There must be adequate ventilation of the room when the wall canopy is used at the same time as appliances burning gas or other fuels.
Installation instructions Contents of packaging 1 x wall canopy 2 x chimney flues with bracket 1 x installation instructions 2 x aluminium mesh filters (HC60PCIX2) 3 x aluminium mesh filters (HC90PCIX2) 2 x butterfly flaps 4 x small screws, to secure chimney flue 5 x 8 x 1½” wood screws 1 x washer (5 mm inner diameter) Typical equipment required: Electric drill Screwdriver Duct tape Jig saw Ladder Ducting Tape measure Drill bits Spirit level Fig.
4 Installation instructions Height of wall canopy Where an electric cooktop is installed beneath the wall canopy, the distance between the top of the cooktop and the underside of the range hood must be a minimum of 600 mm and a maximum of 700 mm. Where a gas fuelled cooktop is installed beneath the wall canopy, the distance between the top of the pot rests and the underside of the rangehood must be a minimum of 650 mm and a maximum of 750 mm.
Installation instructions 5 Preparing the wall canopy for installation Before installing the wall canopy, please carefully read through the installation instructions in full. Prior to drilling any holes, check that the area behind the surface to be drilled is clear of any electrical cables or pipes etc. Take care when installing the wall canopy as stainless steel is easily damaged during installation if scratched or knocked by tools.
6 1 2 3 4 Installation instructions Establish the desired height of the rangehood above the benchtop according to the ‘Installation height requirements’ above. Measure this distance from the top of the benchtop and, using a spirit level, draw a light horizontal line on the wall. Make sure that the line can easily be erased or will be hidden after installation. This is where the bottom of the rangehood will sit (Fig.2). Mark the position of the rangehood on the wall.
Installation instructions 5 6 7 Drill holes and secure the rangehood to the wall. Depending on the wall type (concrete, drywall etc) drill/screw appropriate fittings in the two locations just marked. The rangehood should now be able to be hung on these bolts/ screws through the two keyholes in the hood. Create additional means of attachment. Keyholes alone are insufficient means of attachment.
8 Getting started quickly Control panel Fig.
Cleaning and maintenance 9 Caution! Never use abrasive or oil based liquid cleaners. General maintenance The manufacturer is not liable for any damage caused by not following these instructions. The wall canopy should be cleaned regularly using warm water with soap or mild liquid detergents. This ensures that no build-up of grease occurs as these deposits are corrosive. Do not use abrasives or harsh detergents/cleaning fluids.
10 1 2 3 4 Cleaning and maintenance Light bulb replacement (Screw-in 230V/Max 25W) Switch off the power to the wall canopy. Remove the aluminium mesh filters (or charcoal filters if fitted). Unscrew the old bulb, and screw in the new replacement bulb. Refit aluminium mesh, or charcoal filters. Note: replacement bulbs are not covered by warranty.
Manufacturer’s warranty 11 You automatically receive a 2 year Manufacturer’s Warranty with the purchase of this Product covering parts and labour for servicing within the country of purchase. Fisher & Paykel undertakes to: Repair or, at its option, replace without cost to the owner either for material or labour any part of the Product, the serial number of which appears on the Product, which is found to be defective within TWO YEARS of the date of purchase.
12 Customer care Before you call for service or assistance… Check the things you can do yourself. Refer to your User Guide and check: 1 2 Your appliance is correctly installed. You are familiar with its normal operation. If after checking these points you still need assistance, please refer to your nearest Fisher & Paykel Authorised Repairer, or contact us through our local website listed on the back cover. In New Zealand if you need assistance...
www.fisherpaykel.co.nz www.fisherpaykel.com.au Copyright © Fisher & Paykel 2011. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available. NZ AU F&P PN - 791631 B 05.
