Multimedia Projector MODEL PLC-XF10N MOD PLC-XF10NL (Without Lens) Owner's Manual
INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the owner's manual, may cause harmful interference to radio communications.
IMPORTANT SAFETY INSTRUCTIONS All the safety and operating instructions should be read before the product is operated. Unplug this projector from wall outlet and refer servicing to qualified service personnel under the following conditions: Read all of the instructions given here and retain them for later use. Unplug this projector from AC power supply before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. a. b. c. d. When the power cord or plug is damaged or frayed.
TABLE OF CONTENTS PAGE PAGE FEATURES AND DESIGN 5 INTRODUCTION 5 COMPATIBILITY IMAGE RESOLUTION 5 5 AUTOMATIC MULTISCANNING SYSTEM SCREEN MODE MULTILANGUAGE UNPACKING THE PROJECTOR TRADEMARKS 5 5 5 5 5 INSTALLATION NAME OF EACH PART OF THE PROJECTOR SETTING-UP THE PROJECTOR MOVING THE PROJECTOR POWER REQUIREMENTS CONNECTING THE PROJECTOR TERMINAL OF THE PROJECTOR CONNECTING THE COMPUTER CONNECTING THE VIDEO EQUIPMENT BEFORE OPERATION CONTROLS AND INDICATOR OPERATION OF THE REMOTE CONTROL WIRELES
FEATURES AND DESIGN INTRODUCTION The multimedia projector that combines powerful and sophisticated features with easy-to-use, intuitive controls. Built-in multimedia features include audio, a palette of 16.77 million colors and active matrix liquid crystal display (LCD) technology. The projector is ideal for high-performance business, training and imaging applications that demand exceptional color quality.
EXHAUST VENT CAUTION HOT AIR! Air blown from the exhaust vent is hot. Observe the following when handling your projector or choosing a location to install it. ● Keep heat-sensitive objects away from the exhaust port. ● If you set the projector on top of a metallic surface, the surface will become hot because of the hot air exhaust. Be careful when handling. ● Do not touch the cabinet near to the exhaust vent area, and especially screws and metallic parts.
POSITIONING: ● This projector is basically designed to project on a flat projection surface. ● This projector can be focused from 4.9' (1.5 m) ~ 80.7' (24.6 m). ● Refer to the figure below as an example when positioning the projector to the screen. THIS PROJECTOR SHOULD BE SET IN THE WAY INDICATED. NEVER HANG THE PROJECTOR, OR FALL DOWN ON ITS SIDE. IT MAY RESULT IN FIRE HAZARD. ROOM LIGHT Maximum Zoom Minimum Zoom The projector should be placed in a room with limited light.
Use the carry handle when moving the projector. Replace the lens cover and rotate the adjustable feet fully clockwise. CAUTION IN CARRYING OR TRANSPORTING THE PROJECTOR ● Do not drop or give a shock to the projector, otherwise damage or malfunction may result. ● When carrying the projector, use a Sanyo recommended Carrying Case. ● Do not transport the projector by using a courier or transport service in an unsuitable transport case. This may cause damage to the projector.
INSTALLATION POWER REQUIREMENTS Your projector uses nominal input voltages of 100-120 VAC. The projector automatically selects the correct input voltage. The projector is designed to work with single-phase power systems having a grounded neutral conductor. To reduce the risk of electrical shock, do not plug into any other type of power system. Consult your authorized dealer or service station if you are not sure what type of power is supplied to your building.
CONNECTING THE PROJECTOR TERMINAL OF THE PROJECTOR 9 8 10 USB 1 11 USB 2 6 CONTROL PORT 1 AUDIO 1 R CONTROL PORT 2 13 SERIAL PORT 12 L 2 ANALOG DIGITAL (MONO) AUDIO 2 R R/C JACK 1 5 L (MONO) R G B AUDIO OUT R ANALOG RGB L H V COMPUTER OUT COMPUTER IN-2 COMPUTER IN-1 SIDE OF THE PROJECTOR (CONNECT THE COMPUTER) 3 4 7 1 COMPUTER INPUT-1 TERMINAL (ANALOG HDB 15-PIN) Used to connect a computer to the projector.
CONNECTING THE PROJECTOR SIDE OF THE PROJECTOR (CONNECT THE VIDEO EQUIPMENT) 15 16 VIDEO IN-1 14 18 VIDEO/Y C/Cb(B-Y) Cr(R-Y) S-VIDEO AUDIO R L (MONO) 19 20 MONITOR OUT VIDEO IN-2 17 VIDEO/Y C/Cb(B-Y) Cr(R-Y) S-VIDEO AUDIO R L (MONO) 22 VIDEO/Y C/Cb(B-Y) Cr(R-Y) S-VIDEO AUDIO R L 21 14 VIDEO INPUT JACKS-1 (BNC TYPE x 3) Used to connect a video source to the projector. 19 AUDIO INPUT JACKS-2 (R and L) Used to connect an audio source to the projector.
CONNECTING THE PROJECTOR CONNECTING THE COMPUTER CONNECTING TO THE COMPUTER INPUT 1 TERMINAL (ANALOG HDB 15-PIN) Personal computers can be connected to the HDB15-pin (VGA) terminal on the projector. ● Connect the computer to these terminals using the VGA cable and VGA/MAC adapter (provided). CAUTION: For projectors, the VGA cable provided is designed to reduce RFI (Radio Frequency Interference) emissions.
CONNECTING THE PROJECTOR CONNECTING TO THE MONITOR OUTPUT TERMINAL (ANALOG HDB 15-PIN) This terminal output the information of the selected computer source being viewed on the screen (Computer 1 or Computer 2). When video source ("Video 1" or "Video 2") is selected, this terminal outputs Computer 1 input information. An external monitor can be connected to the HDB15-pin (VGA) terminal on the projector. ● Connect the monitor to this terminal using the VGA cable (not provided).
CONTROL PORT 1 AUDIO 1 R USB 2 CONTROL PORT 2 14 SERIAL PORT L DIGITAL ANALOG (MONO) AUDIO 2 R R/C JACK L (MONO) R G B AUDIO OUT R L ANALOG RGB H V COMPUTER OUT COMPUTER IN-2 COMPUTER IN-1 USB 1
CONNECTING THE PROJECTOR CONNECTING AN IBM-COMPATIBLE DESKTOP COMPUTER (DIGITAL INPUT CONNECTION) NOTE: This connection need optionally sold Graphic Accelerator Board. For this information, contact to your authorized dealer. Before using with digital connection, install (Plug in) Graphic Accelerator Board into PCI bus slot of the computer and set up the computer following instructions in the Graphic Accelerator Board package.
CONNECTING THE PROJECTOR CONNECTING AN IBM-COMPATIBLE LAPTOP COMPUTER COMPUTER VGA CABLE (PROVIDED) COMPUTER OUTPUT (DB15-PIN TYPE) AUDIO CABLE (NOT PROVIDED) R SERIAL PORT INPUT COMPUTER AUDIO OUTPUT PS/2 PORT INPUT L USB 1 R CONTROL PORT 1 AUDIO 1 R MOUSE CABLE FOR PS/2 PORT (PROVIDED) USB 2 CONTROL PORT 2 MOUSE CABLE FOR SERIAL PORT (PROVIDED) R/C JACK SERIAL PORT OUTPUT SERIAL PORT CABLE (NOT PROVIDED) SERIAL PORT L ANALOG L DIGITAL (MONO) AUDIO 2 R CONTROL PORT OUTPUT 1 COMPUT
Before using with digital connection, install (Plug in) Graphic Accelerator PC card into card bus slot of the computer and set up the computer following instructions in the Graphic Accelerator PC card package. COMPUTER DIGITAL FLAT PANEL CABLE (NOT PROVIDED) PpackakTJTj445s-4.
CONNECTING THE PROJECTOR CONNECTING A MACINTOSH DESKTOP COMPUTER COMPUTER MONITOR CABLE (NOT PROVIDED) BNC CABLE x 5 (NOT PROVIDED) COMPUTER OUTPUT (BNC TYPE x 5) ADB PORT INPUT VGA CABLE (PROVIDED) R COMPUTER AUDIO OUTPUT L AUDIO CABLE (NOT PROVIDED) R COMPUTER AUDIO OUTPUT1 or 2 USB 1 L CONTROL PORT 1 AUDIO 1 R USB 2 CONTROL PORT 2 MOUSE CABLE FOR ADB PORT (PROVIDED) SERIAL PORT L L DIGITAL ANALOG (MONO) AUDIO 2 R R/C JACK COMPUTER INPUT 1 (ANALOG) (MONO) R G B H V AUDIO OUT
CONNECTING THE PROJECTOR CONNECTING A MACINTOSH POWERBOOK COMPUTER NOTE: The Macintosh PowerBook requires the use of the PowerBook Video Adapter shipped with the PowerBook.
CONNECTING THE PROJECTOR CONNECTING THE VIDEO EQUIPMENT CONNECTING TO THE VIDEO INPUT JACKS (1 and 2) BNC TYPE x 3 Connect to the video outputs of a VCR, video disc player, DVD player, video camera, satellite TV tuner or other AV equipment. Connect video output from AV equipment to these jacks using the BNC cables. The video input can be connected 3 types of signals; “COMPOSITE VIDEO", "Y/C SEPARATE VIDEO" and COMPONENT VIDEO {Y, Cb (B-Y), Cr (R-Y)}.
CONNECTING THE PROJECTOR CONNECTING THE VIDEO EQUIPMENT VIDEO EQUIPMENT Video Cassette Recorder Y OUTPUT (BNC) C Cb (B-Y) OUTPUT OUTPUT (BNC) (BNC) MONITOR OUT VIDEO IN-2 VIDEO IN-1 VIDEO OUTPUT (BNC) DVD Player Video Disc Player VIDEO INPUT (BNC) Y C INPUT INPUT (BNC) (BNC) VIDEO/Y Cr (R-Y) OUTPUT (BNC) C/Cb(B-Y) Cr(R-Y) Satellite TV Tuner S-VIDEO OUTPUT S-VIDEO Video Camera AUDIO OUTPUT AUDIO R VIDEO/Y C/Cb(B-Y) Cr(R-Y) S-VIDEO Cb (B-Y) INPUT (BNC) C/Cb(B-Y) Cr(R-Y) S-VIDEO L
FRONT INDICATORS TOP CONTROLS FRONT INDICATORS TOP CONTROLS 7 6 VOLUME ZOOM 8 9 FOCUS LENS SHIFT ON-OFF 5 14 MODE MENU 10 AUTO IMAGE NORMAL SELECT 11 12 22 13 15
BEFORE OPERATION 1 LAMP REPLACEMENT INDICATOR Light is orange when the Lamp life draws to an end. 2 TEMPERATURE WARNING INDICATOR Flashes red when internal projector temperature is too high. 3 READY INDICATOR Light is green when projector lamp is ready to be turned on. 4 LAMP POWER INDICATOR Light is dim when the projector is on. Light is brightened when the projector is in stand-by mode. 5 VOLUME BUTTONS Used to adjust volume. 6 ZOOM BUTTONS Used to operate power zoom lens.
BEFORE OPERATION OPERATION OF THE REMOTE CONTROL LASER POINTER button This remote control emits a laser beam light as the Laser Pointer from the Laser Light Window. When the LASER POINTER button is pressed, laser light goes on: when the button is released, light goes off. Laser light is emitted with the RED light indicating that the laser beam is being emitted. The laser emitted is a class laser; therefore, do not look into the laser light window or shine the laser beam on yourself or other people.
BEFORE OPERATION 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 COMPUTER SELECT BUTTON Used to select computer mode. (Computer 1 or Computer 2 Input) VIDEO SELECT BUTTON Used to select video mode. (Video 1 or Video 2 Input) POWER ON/OFF BUTTON Used to turn the projector on or off. VOLUME BUTTONS Used to adjust volume. ZOOM BUTTON Used to select power zoom lens adjust. P-TIMER BUTTON Used to operate the P-TIMER function. FOCUS BUTTON Used to select focus adjust.
BEFORE OPERATION Remote Control Battery Installation 1 2 Remove the battery compartment lid. Slide the batteries into the compartment. 3 Replace the compartment lid. Note : For correct polarity (+ and terminal), be sure the battery terminals are in contact with the pins in the compartment. Using the Remote Control Unit Point the remote control toward the projector (Receiver window) whenever pressing the buttons. Maximum operating range for the remote control is about 16.
BEFORE OPERATION WIRELESS/WIRED REMOTE CONTROL UNIT 1 2 3 4 5 WIRED REMOTE JACK When using the wired remote control, connect the remote cable to this jack. 1 COMPUTER SELECT BUTTON Used to select computer mode. (Computer 1 or Computer 2 Input) 3 VIDEO SELECT BUTTON Used to select video mode. (Video 1 or Video 2 Input) 2 POWER ON/OFF BUTTON Used to turn projector on or off. 5 6 9 COMPUTER VIDEO VOLUME BUTTONS Used to adjust volume.
BEFORE OPERATION Remote Control Battery Installation 1 Remove the battery compartment lid. 2 3 Slide the batteries into the compartment. Replace the compartment lid. Note : For correct polarity (+ and terminal), be sure the battery terminals are in contact with the pins in the compartment. OPEN OPEN The remote control unit can be used as wireless or wired remote control.
BEFORE OPERATION CONTROL THE PROJECTOR The projector has two types of operation: DIRECT OPERATION and MENU OPERATION. DIRECT OPERATION allows you to operate the projector by using one button without showing the MENU. In MENU OPERATION mode, you display menus where you can adjust the projector's settings. Follow the instruction for each control.
BEFORE OPERATION MENU OPERATION ADJUST ITEM MODE SELECT TOP CONTROL OF THE PROJECTOR MENU POINT LEFT/RIGHT SELECT POINT UP/DOWN SELECT WIRELESS/WIRED REMOTE CONTROL MENU POINT LEFT/RIGHT SELECT POINT UP/DOWN SELECT WIRELESS REMOTE CONTROL MENU POINT (LEFT/RIGHT) SELECT (REAR CLICK) POINT (UP/DOWN) SELECT (REAR CLICK) 1. COMPUTER/VIDEO MODE ADJUST ITEM SOUND SOUND VOLUME TREBLE BASS BUILT-IN SP.
BEFORE OPERATION 3.
BASIC OPERATION TURNING ON/OFF THE PROJECTOR TO TURN ON THE PROJECTOR Connect the projector to a source (Computer, VCR, Video Camera, Video Disc Player, etc.) using the appropriate terminals on the side of the projector (See "CONNECTING THE PROJECTOR" section on pages 10-21). Connect the projector's AC power cord into a wall outlet and turn the MAIN ON/OFF switch (located on the side of the projector) to the ON position. The LAMP POWER indicator will light RED, the READY indicator will light GREEN.
BASIC OPERATION DIRECT OPERATION MODE SELECT Press the MODE button on the projector or the COMPUTER and VIDEO button on the remote control unit to select Computer 1, Computer 2, Video 1 or Video 2 Input. The "Computer 1", "Computer 2", "Video 1" or "Video 2" display will appear on the screen for a few seconds.
BASIC OPERATION DIGITAL ZOOM FUNCTION Press the D. ZOOM button on the wireless remote control unit. The "D.zoom" and the magnifying-glass icon is displayed to indicate Digital zoom mode. Digital zoom mode can be adjust the image size or pan the image. To expand the image size, press SELECT (REAR CLICK) button. The image is magnified by degrees (Expand function). To compress the image size, press FRONT CLICK button. The size of image is reduced by degrees (Compress function).
BASIC OPERATION MENU OPERATION In MENU OPERATION mode, you can adjust the projector. You can use the TOP CONTROL OF THE PROJECTOR or the REMOTE CONTROL UNIT. WIRELESS REMOTE CONTROL UNIT TOP CONTROL OF THE PROJECTOR POINT UP BUTTON MENU BUTTON MENU TER COMPU POINT RIGHT BUTTON NORMAL E VOLUM SELECT MUTE POINT DOWN BUTTON WIRELESS/WIRED REMOTE CONTROL UNIT MENU BUTTON POINT LEFT BUTTON ON-O P-TIMER FOCUS FREEZE NO SHOW/ FF LENS SHIFT CURS OR MENU IMAGE NORMAL ER D.
BASIC OPERATION SOUND ADJUSTMENT You can adjust the sound volume, treble, bass levels and Built-in SP., Sound Mute ON/OFF switch in the MENU display. 1. Press the MENU BUTTON and the MAIN MENU DISPLAY dialog box will appear. 2. Press the POINT LEFT/RIGHT BUTTON(s) to select SOUND and press the SELECT (REAR CLICK) BUTTON. Another dialog box SOUND ADJUST DISPLAY will appear. 3. Press the POINT DOWN BUTTON and a red arrow will appear. 4.
VIDEO MODE COLOR SYSTEM SELECT This projector is compatible with the six major broadcast video standards: PAL, SECAM, NTSC, NTSC 4.43, PAL-M and PAL-N (COLOR SYSTEMs). When the color system is set to "Auto position", this projector can detect one of 4 systems (PAL, SECAM, NTSC or NTSC 4.43) automatically. However, if the video signal is not strong enough to detect the video format, the projector may not reproduce the proper video image.
VIDEO MODE PICTURE IMAGE ADJUSTMENT Picture adjustments have been preset at the factory. If you want to change the setting, operate the projector as follows. 1. Press MENU BUTTON and the MAIN MENU DISPLAY dialog box will appear. 2. Press the POINT LEFT/RIGHT BUTTON(s) to select IMAGE and press the SELECT (REAR CLICK) BUTTON. Another dialog box IMAGE ADJUST DISPLAY will appear. This shows the current picture settings. 3.
VIDEO MODE PICTURE SCREEN ADJUSTMENT This projector has the Wide function, which enables you to view a wider video image. WIDE function This projector is able to project not only a normal video image (with 4 x 3 aspect ratio), but also a wider video image by compressing 4 x 3 image. This feature enable you to enjoy watching pictures like cinema images. You can switch either to WIDE or to REGULAR screen mode. 1. Press the MENU BUTTON and the MAIN MENU DISPLAY dialog box will appear. 2.
COMPUTER MODE COMPUTER SYSTEM SELECT This projector is adjustable to different types of computer display signals based on VGA, SVGA, XGA or SXGA (See "COMPATIBLE COMPUTER SPECIFICATIONS" on the next page). If you set MODE SELECT to "COMPUTER", the projector will automatically process the incoming signal and project the proper image without any special setting. Although this will work in most cases, you may be required to manually set the projector for some computer signals.
COMPUTER MODE COMPATIBLE COMPUTER SPECIFICATIONS ON-SCREEN RESOLUTION DISPLAY H-Freq. (kHz) V-Freq. (Hz) ON-SCREEN RESOLUTION DISPLAY H-Freq. (kHz) V-Freq. (Hz) VGA1 640 x 480 31.47 59.88 XGA14 1024 x 768 47.00 58.30 VGA2 720 x 400 31.47 70.09 XGA15 1024 x 768 58.03 72.00 VGA3 640 x 400 31.47 70.09 MAC19 1024 x 768 60.24 75.08 VGA4 640 x 480 37.86 74.38 SXGA1 1152 x 864 64.20 70.40 VGA5 640 x 480 37.86 72.81 SXGA2 1280 x 1024 62.50 58.60 VGA6 640 x 480 37.
COMPUTER MODE PICTURE IMAGE ADJUSTMENT Picture adjustments have been preset at the factory. If you want to change the setting, operate the projector as follows. 1. Press the MENU BUTTON and the MAIN MENU DISPLAY dialog box will appear. 2. Press the POINT LEFT/RIGHT BUTTON(s) to select IMAGE and press the SELECT (REAR CLICK) BUTTON. Another dialog box IMAGE ADJUST DISPLAY will appear. This shows the current picture settings. 3.
COMPUTER MODE PICTURE POSITION ADJUSTMENT 1. Press the MENU BUTTON and the MAIN MENU DISPLAY dialog box will appear. 2. Press the POINT LEFT/RIGHT BUTTON(s) to select POSITION and press the SELECT (REAR CLICK) BUTTON. Another dialog box POSITION SETTING DISPLAY will appear. 3. Press the POINT DOWN BUTTON and a red arrow will appear. 4.
COMPUTER MODE PC ADJUSTMENT NOTE: This function will be skipped when the incoming signal is digital. This projector can automatically detect most display signals from most personal computers currently distributed. However, some computers adopt a special signal format which is different from the standard one and the projector cannot detect it. If this happens, the projector cannot reproduce a proper image.
COMPUTER MODE 6. Another dialog box "PC ADJUSTMENT DISPLAY 1" will appear and the parameter data for the Mode you have selected is shown in this dialog box. 7. The parameters will be filled with the data determined by the projector according to the present signal input. 8. The function of the parameters and their values are summarized in the table as below. 9. Move the arrow to an item that you want to adjust by pressing the POINT UP/DOWN BUTTON(s). 10.
COMPUTER MODE 17. Another dialog box "PC ADJUSTMENT DISPLAY 2" will appear and the parameter data for the Mode you have selected is shown in this dialog box. 18. Move the arrow to an item that you want to adjust by pressing the POINT UP/DOWN BUTTON(s). 19. To increase the level, point the arrow to ▲ and then press the SELECT (REAR CLICK) BUTTON. To decrease the level, point the arrow to ▼ and then press the SELECT (REAR CLICK) BUTTON. 20.
COMPUTER MODE PICTURE SCREEN ADJUSTMENT This projector can adjust the image size and pan the image with PICTURE SCREEN ADJUSTMENT. 1. Press MENU BUTTON and MAIN MENU DISPLAY dialog box will appear. 2. Press POINT LEFT/RIGHT BUTTON(s) to select SCREEN and press the SELECT (REAR CLICK) BUTTON. Another dialog box SCREEN ADJUST DISPLAY will appear. 3. Press POINT DOWN BUTTON and a red arrow will appear. MAIN MENU DISPLAY SCREEN ADJUST DISPLAY 4.
OTHER FUNCTION SETTING This projector has other functions setting: Blue back, Display, Reverse T/B, Reverse R/L, Split wipe, Power management, USB, Remote control and Lamp age. BLUE BACK (On or Off) When this function is in the "On" position, the projector will project a blue image without video noise on the screen when the video source is unplugged or turned off. DISPLAY (On or Off) When this function is in the "On" position, on-screen displays always appear when adjustments are made.
OTHER FUNCTION SETTING REMOTE CONTROL CODE CHANGE (Mode 1 or Mode 2) This projector can be operated with two different code, one is factory-set normal code (MODE 1) and the other one is extended code (MODE 2). This is used to prevent the remote control operation mixture (jam) when two projector and several remote control video equipments are system-up and used together. When you change the code MODE 2, you must change both projector and Remote Control Unit.
OTHER FUNCTION SETTING LAMP AGE The Lamp age function is designed to reset the lamp replacement monitor timer. When replacing the lamp, reset the lamp replacement monitor timer by using this function. NOTE: Do not reset the LAMP REPLACEMENT MONITOR TIMER, except after the lamp is replaced. 1. Press the MENU BUTTON and the MAIN MENU DISPLAY dialog box will appear. 2. Press the POINT LEFT/RIGHT BUTTON(s) to select SETTING and press the SELECT (REAR CLICK) BUTTON.
APPENDIX MAINTENANCE TEMPERATURE WARNING INDICATOR The TEMPERATURE WARNING INDICATOR flashes red when the internal temperature of the projector exceeds the normal temperature. Possible causes for the temperature warning may be : 1. Ventilation slots of the projector are blocked. In such an event, reposition the projector so that ventilation slots are not obstructed. 2. Air filter is clogged with dust particles.
APPENDIX LAMP REPLACEMENT WHEN THE PROJECTION LAMP OF THIS PROJECTOR DRAWS TO AN END, THE LAMP REPLACEMENT INDICATOR LIGHTS YELLOW AND THE WARNING MESSAGE "LAMP REPLACEMENT" APPEARS AS THE RIGHT FIGURE. WHEN THE WARNING MESSAGE IS DISPLAYED, THE PROJECTION LAMP SHOULD BE REPLACED. To terminate the warning message. Replace the Projection Lamp and reset the LAMP REPLACEMENT MONITOR TIMER (See "LAMP AGE" section on page 52.), and the warning message is terminated. To erase the warning message in a moment.
APPENDIX CLEANING THE LENS Follow these steps to clean the projection lens: 1. Apply a non-abrasive camera lens cleaner to a soft, dry cleaning cloth. Avoid using an excessive amount of cleaner. Abrasive cleaners, solvents or other harsh chemicals might scratch the lens. 2. Lightly wipe the cleaning cloth over the lens. 3. When you don't use the projector, replace the lens cover. TROUBLESHOOTING Before calling your dealer or service station for assistance, check the matters below once again. 1.
APPENDIX Problem: Picture is T/B inverted. Try these Solutions: Check Reverse T/B feature. (See "OTHER FUNCTION SETTING" section on pages 50 ~ 51). Picture is L/R Reversed. Check Reverse L/R feature. (See "OTHER FUNCTION SETTING" section on pages 50 ~ 51). Some displays are not seen during the operation. Check Display feature. (See "OTHER FUNCTION SETTING" section on pages 50 ~ 51). No sound. ● ● ● ● Check audio cable connection from audio input source. Adjust audio source.
APPENDIX TECHNICAL SPECIFICATIONS Projector Type Multi-media Projector Dimensions (W x H x D) 15.4" (390 mm) x 9.6" (245 mm) x 23" (585 mm) Net Weight 39.2 Ibs (17.8 kg) LCD Panel System 1.8" TFT Active Matrix type x 3 panels Number of Pixels 2,359,296 {786,432 (1,024 x 768) x 3} Color System 6 color system (PAL, SECAM, NTSC, NTSC4.43, PAL-M and PAL-N) Scanning Frequency H-sync. 15 ~ 100 KHz, V-sync.
SANYO INDUSTRIAL VIDEO LCD PROJECTOR LIMITED WARRANTY OBLIGATIONS In order to obtain warranty service, the product must be delivered to and picked up from an Authorized Sanyo Factory Service Center at the user's expense, unless specifically stated otherwise in this warranty. The names and addresses of Authorized Sanyo Service Centers may be obtained by calling the toll-free number listed below.
