Datasheet

BD135
BD137/BD139
NPN SILICON TRANSISTORS
■ SGS-THOMSON PREFERRED SALESTYPES
DESCRIPTION
The BD135, BD137 and BD139 are silicon
epitaxial planar NPN transistors in Jedec SOT-32
plastic package, designed for audio amplifiers
and drivers utilizing complementary or quasi
compementary circuits.
The complementary PNP types are the BD136
BD138 and BD140.
INTERNAL SCHEMATIC DIAGRAM
June 1997
3
2
1
SOT-32
ABSOLUTE MAXIMUM RATINGS
Symbol Parameter Value Unit
BD135 BD137 BD139
V
CBO
Collector-Base Voltage (I
E
=0) 456080V
V
CEO
Collector-Emitter Voltage (I
B
=0) 456080V
V
EBO
Emitter-Base Voltage (I
C
=0) 5 V
I
C
Collector Current 1.5 A
I
CM
Collector Peak Current 3 A
I
B
Base Current 0.5 A
P
tot
Total Dissipation at T
c
≤ 25
o
C12.5W
P
tot
Total Dissipation at T
amb
≤ 25
o
C1.25W
T
stg
Storage Temperature -65 to 150
o
C
T
j
Max. Operating Junction Temperature 150
o
C
1/4
