3-Panel Tub Kit Install Instructions For missing items do not return to store. Please call 877-941-3662 (Monday – Friday 8:00 a.m. – 5:00 p.m MT ) V.
3-wall Tub Surround Instructions Elite Series Tub Model: FTSK60326031 G D C I B F A B E J Item Description Qty A Back wall panel 1 B C D E F G I J Side wall panel Left wall front mitered trim Left wall top mitered trim Right wall front mitered trim Right wall top mitered trim Back wall top trim Corner shelf with bracket Inside corner reinforcement 2 1 1 1 1 1 1 2 Please inspect packages for damage or missing pieces, and read instructions carefully prior to installation.
Required Tools Helpful Tools Installation Kit Your tub surround kit includes eight cartridges of adhesive and two cartridges of color-tinted 100% silicone. Refer to section 2B of these instructions for adhesive usage guidelines. x8 Construction Adhesive x2 100% Silicone Before Starting ! Consult your local building codes with questions on installation compliance standards.
Install Instructions 1. Installation of Inside Corner Reinforcements (J) A. Flashing Tape Corner Reinforcements go behind the panels in the back vertical corners for added leak protection. This tape has been cut to length, matching the height of the panels of your kit. B. Apply a bead of adhesive onto both walls about 3/4 inch away from the corner. Fold the flashing tape at the center crease with the print side together, then press the tape into the corner using a taping or putty type blade.
! 3. Adhesive Usage Guidlines: • 3 tubes for back panel • 1-2 tubes for each side panel • 1-2 tubes for corner reinforcements, trim, and corner shelf. Installation of Wet/Plumbing Wall Panel (B) NOTE: You will be able to fine tune your panel to a more accurate fit after the holes are cut and your panel can be firmly pushed into the corner. Inside Wall A . Hold side panel as close to plumbing wall as possible.
5. Installation of Back Wall Top Trim (G) NOTE: Trim moldings are shaped like an "L", and the long leg is designed to overlap panels, with the short leg returning back to the sheetrock and hiding the panel edge. Be sure to peel protective masking back from the edges of the panels before adhering the trim moldings. A. Note the height of the shower head. Decide if top trims will be installed above or below shower head/escutcheon, keeping in mind that trims can overlap panels from ½" to 2-1/2".
6. Installation of Side Wall Trims (C,D,E,F) Note: Vertical trim moldings are designed to be installed just outside the tub, running down to the floor, and contour cut to match the tub front shape. Optionally, trims can be cut short to rest on top of the tub. A. Place horizontal left wall top mitered trim (Item D) in place, push into the corner against back wall trim piece, then level it. Mark a level line on the wall on the top side of the molding near the outer end. Set aside this trim piece. B.
. Installation of Corner Shelf (I) NOTE: Corner shelf includes a folding-triangle metal bracket with screw holes which is designed to mount directly to the FlexStone wall panels. Be sure to peel away protective masking from the installation area before securing the bracket. A. Position corner shelf bracket in desired corner at desired height. Use a level to mark level lines in pencil. Adjust the alignment to include a slight forward slope for water runoff. B.
