Hart Scientific 1529 Chub-E4 Thermometer Readout User’s Guide Rev.
Fluke Corporation, Hart Scientific Division 799 E. Utah Valley Drive • American Fork, UT 84003-9775 • USA Phone: +1.801.763.1600 • Telefax: +1.801.763.1010 E-mail: support@hartscientific.com www.hartscientific.com Subject to change without notice. • Copyright © 2005 • Printed in USA Rev.
Table of Contents 1 Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1.1 1.2 Symbols Used . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . 2 1.2.1 1.2.2 1.3 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Authorized Service Centers. . . . . . . . . . . . . . . . . . . . . .
6.5 DC Power Source . . . . . . . . . . . . . . . . . . . . . . . . . . 25 6.6 6.7 Power On Self-Test . . . . . . . . . . . . . . . . . . . . . . . . . 25 Display Backlight and Contrast . . . . . . . . . . . . . . . . . . . 25 6.8 Taking Measurements . . . . . . . . . . . . . . . . . . . . . . . . 25 6.8.1 6.8.2 6.8.3 6.9 6.10 Connecting the Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Enabling the Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.4.2.4 7.4.2.5 7.4.3 7.4.4 7.4.5 7.5 Print Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Delete Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Log Stats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 Data Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67 Default Labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68 System Menu . . . . . . . .
8.4.3.8 8.4.3.9 8.4.4 Probe Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95 8.4.4.1 8.4.4.2 8.4.4.3 8.4.4.4 8.4.4.5 8.4.4.6 8.4.4.7 8.4.4.8 8.4.4.9 8.4.4.10 8.4.4.11 8.4.5 DISPlay:RESolution? [MIN|MAX|DEF] . . . . . . . . . . DISPlay:RESolution |AUT|MIN|MAX|DEF . . . . DISPlay:LAMP? [MIN|MAX|DEF] . . . . . . . . . . . . DISPlay:LAMP ||MIN|MAX|DEF. . . . . . DISPlay:DECimal:FORMat? [MIN|MAX|DEF] . . . . . . DISPlay:DECimal:FORMat |MIN|MAX|DEF . . .
8.4.8 System Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111 8.4.8.1 8.4.8.2 8.4.8.3 8.4.8.4 8.4.8.5 8.4.8.6 8.4.8.7 8.4.8.8 8.4.8.9 8.4.8.10 8.4.9 *IDN? . . . . . . . . . . . . *OPT? . . . . . . . . . . . . *RST. . . . . . . . . . . . . SYSTem:BOOT:VERSion? . SYSTem:CODE:VERSion? . SYSTem:ERRor? . . . . . . SYSTem:SNUMber? . . . . SYSTem:VERSion? . . . . . UNIT:TEMPerature? . . . . UNIT:TEMPerature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
.4.12.16 8.4.12.17 8.4.12.18 8.4.12.19 8.4.12.20 8.4.13 8.4.14 8.4.15 8.4.16 8.4.17 STATus:OPERation:ENABle |MIN|MAX|DEF . . STATus:QUEStionable? . . . . . . . . . . . . . . . . . . STATus:QUEStionable:CONDition? . . . . . . . . . . . STATus:QUEStionable:ENABle? [MIN|MAX|DEF] . . . STATus:QUEStionable:ENABle |MIN|MAX|DEF Statistical Calculation Types. . . . Field Types. . . . . . . . . . . . . Conversion Types and Parameters . Port Numbers . . . . . . . . . . . Date and Time Formats . . . . .
Figures Figure 1 Figure 2 Figure 3 Figure 4 Figure 5 Figure 6 Figure 7 Figure 8 Figure 9 Figure 10 Figure 11 Figure 12 Figure 13 Figure 14 Figure 15 Figure 16 Figure 17 Figure 18 Figure 19 Figure 20 Figure 21 Figure 22 Figure 23 Figure 24 Figure 25 Figure 26 Figure 27 Figure 28 Figure 29 Figure 30 Figure 31 Figure 32 Figure 33 Figure 34 Figure 35 Figure 36 Figure 37 Figure 38 Figure 39 Figure 40 Using the Clamp-on Ferrites . . . . Front Panel . . . . . . . . . . . . . Back Panel . . . . . . . . . . . . .
Figure 41 Figure 42 Figure 43 Figure 44 Figure 45 Figure 46 Figure 47 Figure 48 Figure 49 Figure 50 viii Default Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69 System Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 Comm Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 Date Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73 Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tables Table1 Table 2 Table 3 Table 4 Table 5 Table 6 Table 7 Table 8 Table 9 Table 10 Table 11 Table 12 Table 13 Table 14 International Electrical Symbols . . . . . . . . . . . . . . . . . . . . . 1 Conversion Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Alphabetical List of Commands . . . . . . . . . . . . . . . . . . . . . 81 Statistical Calculation Types . . . . . . . . . . . . . . . . . . . . . . 126 Field Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 Before You Start Symbols Used 1 1.1 Before You Start Symbols Used Table 1 lists the symbols that may be used on the instrument or in this manual Table1 International Electrical Symbols and the meaning of each symbol.
1529 Chub-E4 Thermometer Readout User’s Guide Symbol Description On Canadian Standards Association OVERVOLTAGE (Installation) CATEGORY II, Pollution Degree 2 per IEC1010-1 refers to the level of Impulse Withstand Voltage protection provided. Equipment of OVERVOLTAGE CATEGORY II is energy-consuming equipment to be supplied from the fixed installation. Examples include household, office, and laboratory appliances.
1 Before You Start Safety Information provided with the instrument or equivalent adapter recommended by the manufacturer of this instrument. • The AC adapter has circuits with high voltage inside that could present danger of electrical shock or fire if exposed. If the AC adapter is damaged in any way or becomes hot, discontinue its use immediately, disconnect it from any AC supply, and have it replaced. Do not attempt to open, repair, or continue using a damaged or defective AC adapter.
29 Chub-E4 Thermometer Readout User’s Guide • Keep the probe wires clean and away from fluids. 1.3 Authorized Service Centers Please contact one of the following authorized Service Centers to coordinate service on your Hart product: Fluke Corporation, Hart Scientific Division 799 E. Utah Valley Drive American Fork, UT 84003-9775 USA Phone: +1.801.763.1600 Telefax: +1.801.763.1010 E-mail: support@hartscientific.com Fluke Nederland B.V.
1 Before You Start Authorized Service Centers Fluke South East Asia Pte Ltd. Fluke ASEAN Regional Office Service Center 60 Alexandra Terrace #03-16 The Comtech (Lobby D) 118502 SINGAPORE Phone: +65 6799-5588 Telefax: +65 6799-5588 E-mail: antng@singa.fluke.
2 Introduction 2 Introduction The Hart 1529 is a low-cost, high-accuracy, digital thermometer readout designed to be used with 25 and 100Ω PRTs, thermistors, and thermocouples. Its unique combination of features makes it suitable for a wide variety of applications from laboratory measurement to industrial processes.
3 Specifications and Environmental Conditions Specifications 3 3.
1529 Chub-E4 Thermometer Readout User’s Guide PRT Thermistor Thermocouple Probe Connection Patented DWF connectors accepts spade lug, bare-wire, or banana plug terminations Universal receptacle accepts miniature and standard connectors Communications RS-232 and IR ports included, IEEE-488 (GPIB) optional AC Power 100 to 240 VAC, 50-60 Hz, 0.4A DC Power 12 to 16 VDC, 0.5 A (battery charges during operation from 14.5 to 16 VDC, 1.
3 Specifications and Environmental Conditions Warranty 3.3 Warranty Fluke Corporation, Hart Scientific Division (Hart) warrants this product to be free from defects in material and workmanship under normal use and service for a period as stated in our current product catalog from the date of shipment.
4 Quick Start Unpacking 4 Quick Start This section briefly explains the basics of setting up and operating your 1529 Thermometer Readout. 4.1 Unpacking Carefully unpack the 1529 thermometer readout. Verify that the following items are present: • 1529 Thermometer Readout (The battery inside the 1529 is completely charged when shipped. Initial charging is not required.
1529 Chub-E4 Thermometer Readout User’s Guide 4.4.1 Using the Clamp-on Ferrites Clamp-on ferrites are provided with this product for the use of improving its electromagnetic (EM) immunity in environments of excessive EM interference. During EMC testing we found that ferrites clamped around the probe cables and power cord reduced the risk that EM interference affects measurements.
4 Quick Start Measure Temperature Enter button to continue initialization. If an error message is displayed on power up see Section 11.1, Troubleshooting. 4.7 Measure Temperature After initialization, the temperature measurements for the configured channels are displayed. The appropriate sensor type must be selected and coefficients entered for the measurements to be accurate (see Section 7.2.1, Edit Probe). Place the sensors of the probe into the object(s) you want to measure.
5 Parts and Controls Front Panel Buttons 5 Parts and Controls The functions of the various features of the 1529 are described below. 5.1 Front Panel Buttons The front panel buttons Enter/Menu, Unit, Contrast, and Exit are used to select and alter the functions of the thermometer readout (see Figure 2). 24.159C 24.142C 1 3 4 1 TYP: CVD 1 SER: 145-560 1 –T1: 0.0000 C ALOG: OFF 0% 1529 24.634C 24.015C 2 1 AVE: 24.1530 C 1 STD: 0.0038 C 1 SPR: 0.
1529 Chub-E4 Thermometer Readout User’s Guide FLUKE CORPORATION HART SCIENTIFIC DIVISION www.hartscientifc.com + – CHANNEL CONFIGURATION CH1 CH2 CH3 CH4 1 AMP 14.
5 Parts and Controls Back Panel 5.2 Back Panel The back panel consists of the power switch, AC adapter connector, charging indicator, IR port, RS-232 port connector, IEEE-488 port connector (optional), serial label, and probe connectors. The 1529 thermometer readout can be configured in three different ways. The configuration affects the probe connectors on the back panel. The Model 1529 is configured with one PRT/thermistor input module of two channels and one thermocouple input module of two channels.
1529 Chub-E4 Thermometer Readout User’s Guide • 2380 Small Thermocouple Connector Kit • 2381 Large Thermocouple Connector Kit • 2374 I/R Dongle • 2385 HP-IR Printer • 2386 HP-IR Printer Adapter • 2387 HP-IR Printer Paper 20
6 General Operation Display 6 General Operation This section explains basic operation of the 1529 thermometer readout. Detailed operation of the 1529 is explained in Sections 7 and 8. Section 7 explains the menu structure and the functions available in the menu structure and Section 8 explains the communications interface for operating the 1529 remotely. 6.1 Display The 1529 display consists of two parts. The top portion of the display is used for displaying the measurements from one to four inputs.
1529 Chub-E4 Thermometer Readout User’s Guide is fully charged. Only charge the battery when ambient temperature is between 16°C and 30°C (61°F and 86°F) It normally takes about three hours to fully charge the battery. The instrument can be operated while the battery is being charged. The charging indicator on the back panel is green when the battery is fully charged and amber when being charged using the AC adapter. The battery may self-discharge over several months, especially if the temperature is warm.
6 General Operation Probe Input Modules All possible configurations are shown in Figure 3 on page 18. 6.4.1 Connecting a PRT or Thermistor Probe PRT and thermistor probes are attached to the resistance input module via Hart Scientific mini-DWF connectors. These patented connectors accept bare wire, spade, or mini banana plug terminations. The connectors are color coded for ease in connecting lead-wires. When using 2- and 3-wire sensors, the accuracy of the 1529 is reduced as stated in the specifications.
1529 Chub-E4 Thermometer Readout User’s Guide Channel 1 Channel 2 Shield Connecting 4-wire probes Channel 1 Channel 2 Connecting 3-wire probes Channel 1 Channel 2 Connecting 2-wire probes Figure 5 Probe Connection Wiring Diagram 24
6 General Operation DC Power Source 6.5 DC Power Source Caution: For CE compliance and for performance, use only the AC adapter shipped with the instrument by Hart Scientific. If the AC adapter needs to be replaced, contact a Hart Authorized Service Center (see Section 1.3). The DC power source provides power to charge the battery. It can also be used to power the 1529 while the battery is being charged. The AC adapter provided with the 1529 is intended for these purposes.
1529 Chub-E4 Thermometer Readout User’s Guide 6.8.2 Enabling the Channel Channels are set first by selecting either simultaneous or scan mode in the CHANNEL menu CHANNEL MODE function. Simultaneous mode shows one to four channels in the upper display simultaneously. Scan mode shows one channel at a time (in large digit format) scanning through one to four channels depending on the channels that are enabled.
6 General Operation Data Logging 6.10 Data Logging Data can be logged either on demand or automatically at a user-selected interval. When data is logged, readings are stored to the instrument's memory and assigned a label for easy recall and organization of data. Up to 100-demand log and 8,160 auto log readings can be stored. When data is being logged, the left bottom corner of the main display shows a strip-recorder indicator.
7 Menu Functions Channel Menu 7 Menu Functions Selecting the Enter/Menu button from the front panel accesses the main menu of the 1529 thermometer readout. The main menu consists of the submenus: CHANNEL, PROBE, FIELDS, LOGGING, and SYSTEM. Each submenu has its own set of functions. The Enter/Menu button is used to select and save menu choices. The Unit LR buttons are used to scroll forward or backward through the functions.
1529 Chub-E4 Thermometer Readout User’s Guide and DISPLAY OPTIONS/AUTO-CAL. (The DISPLAY OPTIONS changes to AUTO-CAL when the measure period is less than 1 second.) 1 3 24.159C 24.142C 2 4 24.634C 24.015C MEASUREMENT CONTROL FUNCTIONS ENABLE CHANNEL MEASURE PERIOD 1529 CHANNEL MODE MOVING AVERAGE DISPLAY OPTIONS CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 8 Channel Menu 7.1.
7 Menu Functions Channel Menu The LR buttons are used to select the period between measurements. Press the Enter button to save the new setting. Press the Exit button to cancel and to exit to the menu. When the measure period is set to less than 1 second (i.e. 0.1, 0.2, 0.5 seconds) the 1529 enters the Fast Measurement Mode. The menu buttons may seem to be sluggish in this mode as the processor is making faster measurements. When in the Fast Measurement Mode, the following changes occur at 0.1, 0.2, and 0.
1529 Chub-E4 Thermometer Readout User’s Guide Press ENTER to continue … Press the Enter button to confirm and to continue. The display is remains unchanged and all enabled channels remain enabled channels. Press the Exit button to cancel. When the measure period is reset to 1 second or greater, the following message is displayed indicating that the 1529 is returning to normal operation. FULL ACCURACY. The DISPLAY FUNCTIONS function of the CHANNEL menu reappears and the CHANNEL MODE function is available.
7 Menu Functions Channel Menu hold the Exit button to cancel to the main display or press the EXIT button to cancel and to move to the next parameter. 7.1.3 Channel Mode The CHANNEL MODE function sets the channel display mode. When this function is selected, the bottom portion of the display shows the current scan mode and allows the setting to be changed. 1 3 24.159C 24.142C 2 4 24.634C 24.
1529 Chub-E4 Thermometer Readout User’s Guide proving resolution. When this function is selected, the bottom portion of the display shows the averaging setting and allows the setting to be changed. Select the number of raw measurements to be averaged to produce the displayed measurement. The range is from 1 to 10. The factory default is 1. The measurements are averaged together until the selected number of measurements to average has been reached.
7 Menu Functions Probe Menu of the display shows the current display settings. This function is the same as the FIELDS menu DISPLAY OPTIONS function. 1 3 24.159C 24.142C RESOL: DECIMAL: LAMP: 2 4 24.634C 24.015C 3 . OFF 1529 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 12 Display Options The RESOL parameter determines the number of decimal places (0 through 4 or AUTO) to be displayed for the temperature measurements.
1529 Chub-E4 Thermometer Readout User’s Guide testing conversion settings, viewing and printing probe parameters, and clearing the default probe. The functions that appear in this menu are EDIT PROBE, COPY PROBE, TEST PROBE, PRINT PROBE, and DEFAULT PROBE. 1 3 24.159C 24.142C 2 4 24.634C 24.015C PROBE CHARACTERIZATION FUNCTIONS COPY PROBE EDIT PROBE 1529 PRINT PROBE TEST PROBE DEFAULT PROBE CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 13 Probe Menu 7.2.
7 Menu Functions Probe Menu channel, the probe serial number and the conversion type. The characterization coefficients and parameters are displayed after the conversion type is selected. 1 3 24.159C 24.142C PROBE: SERIAL: TYPE: 4 URANGE: 100Ω WIRES: 4 RO: 100.0000 DAL: 0.003850000 CHAN-1 145-560 CVD 1529 24.634C 24.
1529 Chub-E4 Thermometer Readout User’s Guide the next parameter. On the last parameter, press the Exit button to exit to the menu. Table 2 Conversion Types 7.2.1.
7 Menu Functions Probe Menu The RANGE parameter is used to select the appropriate resistance range. For 25 ohm and 100 ohm PRTs select 100 ohms and for 1000 ohm PRTs select 10K ohms. The WIRES parameter sets the appropriate number of lead wires from the sensor. This parameter can be set to 2-, 3-, or 4-wires. See Figure 5 on page 24 for the wiring configuration. The following table shows which parameter to set for each of the coefficients that may appear on the certificate.
1529 Chub-E4 Thermometer Readout User’s Guide and to save the new settings. Use the LR buttons to change each digit of the settings. Press and hold the Exit button to cancel to the main display or press the EXIT button to cancel and to move to the next parameter. On the last parameter, press the Exit button to exit the menu. 7.2.1.3 PT-100 Conversion The parameters for the PT-100 conversion are R0 (R0), ALPHA (α), DELTA (δ), and BETA (β).
7 Menu Functions Probe Menu The A, B, and C coefficients can be converted to α, δ, and β coefficients using the following formulas: α = A + 100 B δ=− 100 A +1 100 B β=− 10 8 C A + 100 B When the CVD conversion type is selected, the R0, ALPHA, DELTA, and BETA coefficients are displayed on the right portion of the bottom of the display. Use the UD buttons to scroll through the coefficients. Use the Enter button to edit and save the new setting.
1529 Chub-E4 Thermometer Readout User’s Guide When the Thermistor T(R) conversion type is selected, the coefficients are displayed on the right portion of the bottom of the display. Use the UD buttons to scroll through the coefficients. Use the Enter button to edit and save the new setting. Press and hold the Exit button to cancel to the main display or press the EXIT button to cancel and to move to the next parameter. On the last parameter, press the Exit button to exit to the menu. 7.2.1.
7 Menu Functions Probe Menu 7.2.1.10 Standard Thermocouple Conversions Standard thermocouple conversions include types B, E, J, K, N, R, S, T, and Au-Pt. Voltage is converted to temperature using standard reference functions. (For additional information consult the publication NIST Monograph 175.) You can specify internal or external reference junction compensation (RJC) with the RJC parameter. (See Table 9 on page 129.
1529 Chub-E4 Thermometer Readout User’s Guide 7.2.2 Copy Probe The COPY PROBE function allows you to copy a set of probe parameters from one channel or memory location to another. The parameters are copied from the user selected source channel or memory location into the current channel. The COPY PROBE function can be password protected to restrict access. See Section 7.5.3, Password, for more information. If this function is password protected, the user is prompted to enter the password to gain access.
7 Menu Functions Probe Menu the display shows the probe channel or memory location, the probe serial number, and the conversion type. 1 3 24.159C 24.142C PROBE: SERIAL: TYPE: 2 4 24.634C 24.015C CHAN1 145-560 CVD 1529 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 16 Test Probe Use the LR buttons to select the channel or memory location. After the channel is selected, press the Enter button to test the temperature calculation for the probe.
1529 Chub-E4 Thermometer Readout User’s Guide this function is selected, the bottom portion of the display shows the probe channel. 24.159C 24.142C 1 3 PROBE: PORT: 2 4 24.634C 24.015C CHAN1 SERIAL 1529 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 17 Print Probe Use the LR buttons to select the channel, memory location, or ALL. Use the UD buttons to scroll between parameters. Press the Enter button to continue and to send the data to the selected port.
7 Menu Functions Fields Menu selected channel, memory location, or ALL to the factory defaults. When this function is selected, the bottom portion of the display shows the probe channel. 24.159C 24.142C 1 3 PROBE: 2 4 24.634C 24.015C CHAN1 1529 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 18 Default Probe Use the LR buttons to select the channel, memory location, or ALL. Press the Enter button to reset the probe coefficients.
1529 Chub-E4 Thermometer Readout User’s Guide functions that appear in this menu are CLEAR STATS, SELECT FIELDS, EDIT FIELDS, DEFAULT FIELDS, and DISPLAY OPTIONS. 1 3 24.159C 24.142C 24.634C 24.015C 2 4 DISPLAY CONFIGURATION FUNCTIONS SELECT FIELDS CLEAR STATS 1529 EDIT FIELDS DEFAULT FIELDS DISPLAY OPTIONS CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 20 Fields Menu 7.3.
7 Menu Functions Fields Menu Press the Enter button to clear the statistical data. Press the Exit button to abort clearing the statistical data and to exit to the menu. 7.3.2 Select Fields The SELECT FIELDS function allows you to select a display set (1 through 9) to use for displaying information provided by the instrument. A display set can be customized to display up to eight different fields. See the table of Field Types below.
1529 Chub-E4 Thermometer Readout User’s Guide Keyword Field Type AVE Average BATT Battery Percent Remaining DATE Date INP Input in ohms, K ohms, or mV MAX Maximum MEAS Number of Seconds Until Next Measurement MIN Minimum REF Reference (see below) SER Probe Serial Number SPR Spread STD Standard Deviation STN Count -T1, -T2, -T3, -T4 Delta TEM Temperature TIME Time TYP Conversion Type ALOG Indicating of auto logging is on or off ---- Blank Note: When the field type refer
7 Menu Functions Fields Menu 7.3.3 Edit Fields The EDIT FIELDS function allows editing of the display fields for a given display set (1 through 9). You can choose to display one to eight fields. The available fields and their corresponding keywords are given in the Field Types table above. When this function is selected, the bottom portion of the display allows you to select the display set to edit. 1 3 24.159C 24.142C DISPLAY: 4 24.634C 24.
1529 Chub-E4 Thermometer Readout User’s Guide factory defaults. When this function is selected, the bottom portion of the display instructs you to press Enter to revert to the default display set. 1 3 24.159C 24.142C 2 4 24.634C 24.015C REVERT TO DEFAULT DISPLAY SETUP. Press ENTER to continue...: 1529 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 23 Default Fields Press the Enter button to revert to the default display setup. Press the Exit button to exit to the menu. 7.
7 Menu Functions Logging Menu bottom portion of the display shows the current display settings. This function is the same as the CHANNEL MODE menu DISPLAY OPTIONS function. 1 3 24.159C 24.142C RESOL: DECIMAL: LAMP: 2 4 24.634C 24.015C 3 . OFF 1529 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 24 Display Options The RESOL parameter determines the number of decimal places (0 through 4 or AUTO) to be displayed for the temperature measurements.
1529 Chub-E4 Thermometer Readout User’s Guide this menu are DEMAND LOG, AUTO LOG, LOG STATS, DATA LABELS, and DEFAULT LABELS. 1 3 24.159C 24.142C 2 4 24.634C 24.015C DATA RECORDING FUNCTIONS AUTO LOG DEMAND LOG 1529 DATA LABELS LOG STATS DEFAULT LABELS CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 25 Logging Menu 7.4.1 Demand Log The DEMAND LOG submenu allows measurements to be logged on demand, one reading at a time.
7 Menu Functions Logging Menu mand logging submenu which consists of the functions: STORE READING, LOG HISTORY, VIEW DATA, PRINT DATA, and DELETE DATA. 1 3 24.159C 24.142C 2 4 24.634C 24.015C DEMAND LOGGING FUNCTIONS LOG HISTORY STORE READING 1529 PRINT DATA VIEW DATA DELETE DATA CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 26 Demand Log Submenu 7.4.1.1 Store Reading The STORE READING function stores the current measurements for all displayed channels.
1529 Chub-E4 Thermometer Readout User’s Guide current resolution setting), and the units as they are stored into memory. The right side of the bottom display shows the current label. 24.159C 24.142C 1 3 CH CH CH CH 1 2 3 4 24.150 29.634 24.010 23.989 1529 C C C C 24.634C 24.
7 Menu Functions Logging Menu When this function is selected, the bottom portion of the display shows the demand log history data. 1 3 01: 02: 03: 04: 24.159C 24.142C DATA_01 DATA_01 DATA_01 DATA_01 1529 11:39:04 11:39:04 11:39:04 11:39:04 2 4 24.634C 24.015C 10-12-00 10-12-00 10-12-00 10-12-00 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 28 Log History Press the UD buttons to scroll up and down through the stored readings sequentially one at a time.
1529 Chub-E4 Thermometer Readout User’s Guide HISTORY function. When this function is selected, the bottom portion of the display shows the demand log data. 1 3 01: 02: 03: 04: 24.159C 24.142C DATA_01 DATA_01 DATA_01 DATA_01 1529 1 2 3 4 2 4 24.156 29.629 24.086 24.048 24.634C 24.
7 Menu Functions Logging Menu and the port. Select ALL DATA to print all demand log entries, or select a specific label to print only the demand log data for that label. 24.159C 24.142C 1 3 LABEL: PORT: 2 4 24.634C 24.015C ALL DATA SERIAL 1529 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 30 Print Data Use the LR buttons to select the parameter settings. Use the UD buttons to scroll between parameters. Press the Enter button to continue.
1529 Chub-E4 Thermometer Readout User’s Guide bered. Select ALL DATA to delete all demand log readings or select a specific label to delete only the demand log data for that label. 1 3 24.159C 24.142C DELETE: 2 4 24.634C 24.015C ALL DATA 1529 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 31 Delete Data Use the LR buttons to select the label of the data you want to delete. Press the Enter button to continue and delete the data.
7 Menu Functions Logging Menu AUTO LOG submenu and consists of the functions: LOGGING OPTIONS, START STOP, VIEW DATA, PRINT DATA, and DELETE DATA. 1 3 24.159C 24.142C 2 4 24.634C 24.015C AUTOMATIC LOGGING FUNCTIONS START STOP LOGGING OPTIONS 1529 PRINT DATA VIEW DATA DELETE DATA CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 33 Auto Log Submenu 7.4.2.1 Logging Options The LOGGING OPTIONS function allows the user to define the logging parameters.
1529 Chub-E4 Thermometer Readout User’s Guide The LOG PER parameter is for selecting the interval between measurements. You may select between 0.1, 0.2, 0.5, 1, 2, 5, 10, and 30 seconds, 1, 2, 5, 10, and 30 minutes or 1 hour. The LOG PER must be set to a value less than or equal to the measurement period. The 1529 will not log readings faster than the measurement period. The measurement period is set in the MEASURE PERIOD function of the CHANNEL menu and is the rate at which readings are taken.
7 Menu Functions Logging Menu Note: The log is not started or stopped until the Enter button is pressed to confirm the user action. 24.159C 24.142C 1 3 24.634C 24.015C 2 4 START RECORDING DATA. Press ENTER to continue... 1529 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 35 Start Stop After a log session is started, the bottom portion of the display shows the log statistics. These statistics can also be viewed from the LOG STATS function of the LOGGING menu. 1 3 24.
1529 Chub-E4 Thermometer Readout User’s Guide readings currently stored in the demand or auto log memory. The COUNT parameter shows the number of auto log readings remaining during the current log session. Press the Enter or Exit button to exit this display and to return to the AUTO LOG menu. Only those channels that are enabled during the log session are logged. Although you may enable and disable channels during a log session we do not recommend this practice.
7 Menu Functions Logging Menu Subsequent entries in the log consist of the reading number, channel, measurement value, units, and the time of each entry. Press the LR buttons to jump 100 readings at a time. Hold the UD buttons down to advance quickly through the data. Press and hold the L button to view the top reading, and the R button to view the bottom reading. Press the Enter or Exit button to return to the AUTO LOG menu. 7.4.2.
1529 Chub-E4 Thermometer Readout User’s Guide Select ALL DATA to delete all auto log readings or select a specific label to delete only the auto log entries for that label. 1 3 24.159C 24.142C DELETE: 2 4 24.634C 24.015C ALL DATA 1529 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 38 Delete Data Use the LR buttons to select the label of the data you want to delete. Press the Enter button to continue and to delete the data.
7 Menu Functions Logging Menu both the demand and auto logs. When this function is selected, the bottom portion of the display shows the logging statistics. 24.159C 24.142C 1 3 DEMAND LOG AUTO LOG COUNT: 6655 FILLED: 18.5% FREE: 6654, 1506 FILLED: 4.0% FREE: 95, 4 1529 24.634C 24.015C 2 4 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 39 Log Stats The left side displays demand log statistics and the right side displays the auto log statistics.
1529 Chub-E4 Thermometer Readout User’s Guide digits. These labels are used to identify logged data when using the demand and auto log functions. 24.159C 24.142C 1 3 SELECT: 2 4 24.634C 24.015C DATA_01 1529 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 40 Data Labels Press the LR buttons to select the label to edit. By default the labels are set to DATA_01, DATA_02, … at the factory. Press the Enter button to begin editing the label.
7 Menu Functions System Menu this function is selected, the bottom portion of the display instructs the user to press the Enter button to reset the data labels to their default settings. 1 3 24.159C 24.142C 2 4 24.634C 24.015C RESET DATA LABELS TO DEFAULTS. Press ENTER to continue... 1529 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 41 Default Labels To exit without resetting the labels, press the Exit button. 7.
1529 Chub-E4 Thermometer Readout User’s Guide appear in this menu are COMM SETUP, DATE TIME, PASSWORD, CALIBRATION, and SYSTEM RESET. 1 3 24.159C 24.142C 2 4 24.634C 24.015C 1529 HART 0.50 SERNUM DATE TIME COMM SETUP 1529 CALIBRATION PASSWORD SYSTEM RESET CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 42 System Menu 7.5.1 Comm Setup The COMM SETUP function is used to setup the communication parameters for the installed ports.
7 Menu Functions System Menu sages stored in the error queue on the display. Once an error has been viewed, it is removed from the error queue. 24.159C 24.142C 1 3 PORT: 2 4 24.634C 24.015C SERIAL 1529 CHUB E-4 THERMOMETER READOUT ENTER / MENU UNIT CONTRAST EXIT Figure 43 Comm Setup Press the LR buttons to select the port to setup. Press the Enter button to display the port parameters. 7.5.1.
1529 Chub-E4 Thermometer Readout User’s Guide The ECHO parameter allows the user to set the echo (duplex) mode. Selecting ON enables echoing so that all characters received on the serial port are echoed back over the serial port. This mode is useful when using terminal emulation software on a computer to communicate with the instrument. Selecting OFF disables echoing. This mode is commonly used when using control software on the computer. Press the LR buttons to select the parameter setting.
7 Menu Functions System Menu The GPIB parameter allows the user to enable or disable the IEEE-488 port. The ADDR parameter allows the user to specify the address of this instrument on the IEEE-488 bus. The default address is 22 and the range is 1 to 30. The TERM parameter allows the user to select the termination character transmitted after each transmission. The default termination character is linefeed (LF). 7.5.
1529 Chub-E4 Thermometer Readout User’s Guide The D FORM parameter allows the user to set the date format used when display the date. The choices are M-D-YY, M-D-YYYY, D/M/YY, and D/M/YYYY. Press the LR buttons to change the parameter setting. Use the UD buttons to scroll between the parameters. Press the Enter button to save the new setting. Press the Exit button to exit to the menu. 7.5.
7 Menu Functions System Menu of the display. The password-protected parameters are PASSWRD and PRB SEC. The PASSWRD parameter allows the user to change the password. Press the Enter button to edit the PASSWRD parameter. Press the LR buttons to highlight the digit to change. Use the UD buttons to scroll through the numbers 0-9. Press the Enter button to save the new setting. Press the Exit button to cancel and to move to the next parameter or to exit to the menu.
1529 Chub-E4 Thermometer Readout User’s Guide By default the password is set to ‘1529’ when the instrument ships from the factory. We recommend that the user change the default password to protect the password-protected settings. Note: Keep your password in a secure location and do not forget it. To enter the password, press the Enter button. Press the LR buttons to highlight the digit to change. Use the UD buttons to scroll through the numbers 0-9. Press the Enter button to save the new setting.
7 Menu Functions System Menu The C0K, C10K, and C100K parameters apply to the thermistor probe types and 10KΩ resistance range. Use these parameters to adjust the measurement at 0K,10K, and 100KΩ respectively. These values are in Kohms. The DATE parameter is the date the current calibration was performed. The DUE parameter is the date the current calibration expires. For thermocouple channels, the parameters C0, C100, CRJ, DATE, and DUE are displayed.
1529 Chub-E4 Thermometer Readout User’s Guide By default the password is set to ‘1529’ when the instrument ships from the factory. We recommend that the user change the default password to protect the password-protected settings. Note: Keep your password in a secure location and do not forget it. To enter the password, press the Enter button. Press the LR buttons to highlight the digit to change. Use the UD buttons to scroll through the numbers 0-9. Press the Enter button to save the new setting.
8 Digital Communications Interface Overview 8 8.1 Digital Communications Interface Overview The communication feature allows an external device, such as a computer, to communicate with the 1529 to obtain measurement data and control operating conditions. Communication is accomplished by issuing commands to the 1529 through RS-232, IR, or IEEE-488 communication ports. 8.2 Communications The thermometer readout is equipped with an RS-232 serial interface, an infrared window, and optionally a GPIB port.
1529 Chub-E4 Thermometer Readout User’s Guide All commands sent to the 1529 through the serial interface must be terminated with a carriage return or linefeed character. 8.2.2 GPIB Communications The GPIB interface allows the Model 1529 to be connected to an IEEE-488 bus along with other instruments. A system controller can remotely control the operation of the Model 1529 and read measurements. 8.2.2.1 Capability The Model 1529 GPIB interface conforms to standard IEEE-488.2, 1992.
8 Digital Communications Interface Interface Commands Table 3 Alphabetical List of Commands Command Description Refer To *CLS Clears the status registers Section 8.4.12 *ESE? Returns the Event Status Enable Register Section 8.4.12 *ESE |MIN|MAX|DEF Sets the Event Status Enable Register Section 8.4.12 *ESR? Returns the Event Status Register Section 8.4.12 *IDN? Section 8.4.
1529 Chub-E4 Thermometer Readout User’s Guide Command Description Refer To CALibrate:AUTO Executes the automatic calibration procedure when using fast measurement mode. Section 8.4.5 CALibrate:DATE:CALibrate? [MIN|MAX|DEF] Returns the channel calibration date for the specified channel Section 8.4.5 CALibrate:DATE:CALibrate (,,)|MIN|MAX|DEF Sets the channel calibration date for the specified channel Section 8.4.
8 Digital Communications Interface Interface Commands Command Description Refer To FORMat:STAMp? Returns the extended measurement data format setting Section 8.4.1 FORMat:STAMp Enables extended measurement data format with the FETCh?, MEASure?, and READ? commands Section 8.4.1 INITiate Provided for compatibility but has no effect Section 8.4.2 INITiate:CONTinuous? Provided for compatibility but has no effect Section 8.4.
1529 Chub-E4 Thermometer Readout User’s Guide Command Description Refer To ROUTe:SCAN [] Sets the input channels for scanning Section 8.4.3 ROUTe:SCAN:MODE? [MIN|MAX|DEF] Returns the current scan mode Section 8.4.3 ROUTe:SCAN:MODE |MIN|MAX|DEF Sets the scan mode Section 8.4.3 SENSe:AVERage:COUNt? [MIN|MAX|DEF] Returns the moving average filter setting Section 8.4.2 SENSe:AVERage:COUNt |MIN|MAX|DEF Sets the moving average filter setting Section 8.4.
8 Digital Communications Interface Interface Commands Command Description Refer To SYSTem:COMMunicate:SERial:FEED |MIN|MAX|DEF Sets the state of the serial port printing setting Section 8.4.9 SYSTem:COMMunicate:SERial:LINefeed? [MIN|MAX|DEF] Returns the state of the serial port linefeed setting Section 8.4.9 SYSTem:COMMunicate:SERial:LINefeed |MIN|MAX|DEF Sets the state of the serial port linefeed setting Section 8.4.
1529 Chub-E4 Thermometer Readout User’s Guide Commands consist of a command header and, if necessary, parameter data. All commands must be terminated with either a carriage return (ASCII 0D hex or 13 decimal) or new line character (ASCII 0A hex or 10 decimal). Command headers consist of one or more mnemonics separated by colons (:). Mnemonics may use letter characters, the underscore character (_), and possibly numeric digits as well. Commands are not case sensitive. Mnemonics often have alternate forms.
8 Digital Communications Interface Commands Logging Commands – commands for automatic and demand logging. System Commands – commands for general system configuration parameters. Communication Interface Commands – commands for controlling the interface configuration(serial port, IR, and IEEE). Date and Time Commands – commands for setting the date, time and the date and time formats.
1529 Chub-E4 Thermometer Readout User’s Guide • indicates numeric value is required. • indicates a list of channel numbers is required. • indicates a Boolean value (0 or 1) is required. The mneumonics OFF and ON are also accepted for 0 and 1, respectively. • indicates a conversion mnemoic is required. • indicates a parameter name is required. • indicates a serial number is required. • indicates a resistance value is required.
8 Digital Communications Interface Commands The CALCulate suffix, , specifies the channel (1 to 4). The AVERage suffix, , specifies the calculation type. See Table 4 on page 126 for the Statistical Calculation Types. 8.4.1.3 CALCulate:AVERage:TYPE? Returns the keyword for the specified field type number. CALC:AVER2:TYPE STD The AVERage suffix, , specifies the calculation type number. See Table 4 on page 126 for the Statistical Calculation Types. 8.4.1.
1529 Chub-E4 Thermometer Readout User’s Guide day the measurement was made With this format kohms and millivolts are not converted to ohms and volts. This command may return the same reading if a new reading has not yet been obtained.
8 Digital Communications Interface Commands The SENSe suffix, , specifies the channel (1 to 4). The parameter is ohms for low range PRTs, Kohms for high range PRTs and thermistors, and millivolts for thermocouples. The second returned parameter is always 0 for PRTs and themistors and the reference junction temperature for thermocouples. 8.4.
1529 Chub-E4 Thermometer Readout User’s Guide 0 This command only applies to PRT/Thermistor channels. Executing this command on Thermocouple channels generates a -294, "Incompatible type", error message. The SENSE suffix, , specifies the channel (1 to 4), or memory channel (5 to 14). Specifying the MIN parameter returns a value of 0. Specifying the MAX parameter returns a value of 1. Specifying the DEF parameter returns a value of 0. The *RST command sets the resistance range to the default (DEF). 8.
8 Digital Communications Interface Commands 8.4.2.8 SENSe:RESistance:WIRE |MIN|MAX|DEF Sets the probe wire setting. SENS2:RES:WIRE MIN This command only applies to PRT/Thermistor channels. Executing this command on Thermocouple channels generates a -294, "Incompatible type", error message. The SENSE suffix, , specifies the channel (1 to 4), or memory channel (5 to 14). The parameter must either be 2, 3, or 4.
1529 Chub-E4 Thermometer Readout User’s Guide 8.4.3 Channel Commands The channel commands are used for querying and setting the current channel, the channels to scan, the type of scanning, and the state of the channel scanning. The channel commands are not password protected. 8.4.3.1 ROUTe:CLOSe? Returns the state of the specified channel. ROUT:CLOS? 1 0 The parameter specifies the channel (1 to 4). If the specified channel is enabled, this query returns 1.
8 Digital Communications Interface Commands 8.4.3.6 ROUTe:SCAN? Returns a comma delimited list of the enabled channels. ROUT:SCAN? (@2,3,4) The list of channels is enclosed in parenthesis and preceded with the @ symbol. 8.4.3.7 ROUTe:SCAN Sets the channels for scanning. ROUT:SCAN 2,3 The parameter is a comma delimited list of the channels (1 to 4) to enable. Channels that are omitted from this list are disabled. If the parameter is omitted, all channels are disabled.
1529 Chub-E4 Thermometer Readout User’s Guide CALC2:CONV:CAT? “RES”,“ITS”,”ITS5”,”PT”,”CVD”,”TRES”,”TTEM”,”YSI” The CALCulate suffix, , specifies the channel (1 to 4) or memory channel (5 to 14). Each item in the response list is enclosed in double quotes and separated from other items by a comma. See Table 7 on page 128, for the available conversion types. 8.4.4.
8 Digital Communications Interface Commands type. The acceptable conversion types depend on the channel type. The conversion types and their names are listed in Table 7 on page 128. This command may be password-protected. To access this command: • If the SYST:PASS:CONV? command returns a 0 (probe password-protection is disabled), the password is not required.
1529 Chub-E4 Thermometer Readout User’s Guide CALC2:CONV:PAR:VAL RTPW, 100.0145, A4, 0.0045 The CALCulate suffix, , specifies the channel (1 to 4) or memory channel (5 to 14). The parameter is the name of the parameter as given in Table 8, Conversion Types and Parameters. If the parameter is not applicable to the current conversion type, an error -221, “Settings Conflict”, is generated. The parameter is the desired value of the parameter.
8 Digital Communications Interface Commands can consist of up to eight characters that include any letters, numeric digits, and the underscore ‘_’. This command may be password-protected. To access this command: • If the SYST:PASS:CONV? command returns a 0 (probe password-protection is disabled), the password is not required. • If the SYST:PASS:CONV? command returns a 1 (probe password-protection is enabled), the password must be successfully entered using the SYST:PASS:CEN command (see Section 9.4.
1529 Chub-E4 Thermometer Readout User’s Guide 2000,1,1. Specifying the MAX parameter returns a value of 2099,12,31. Specifying the DEF parameter returns a value of 2000,1,1. 8.4.5.3 CALibrate:DATE:CALibrate (,,)|MIN|MAX|DEF Sets the calibration date for the specified channel. CAL1:DATE:CAL 2000,8,29 The CALibrate suffix, , specifies the channel (1 to 4). This command does not apply to memory channels. The , , and parameters must all be supplied.
8 Digital Communications Interface Commands 8.4.5.6 CALibrate:PARameter:OFFSet? [MIN|MAX|DEF] Returns the calibration offset parameter for the specified channel. CAL1:PAR:OFFS2? –1.2 The CALibrate suffix, , specifies the channel (1 to 4). This command does not apply to memory channels. For PRT/Thermistor channels, the calibration offset suffix specifies the resistance range parameter for PRTs (1) or Thermistors (2).
1529 Chub-E4 Thermometer Readout User’s Guide Thermistors (2). For Thermocouple channels, the calibration scale suffix is ignored and may be omitted. Note: For PRT/Thermistor channels, the value returned by this command is always in ohms. For PRT/Thermistor channels, specifying the MIN parameter returns a value of -9 when the scale suffix is 1 (for PRTs) and -9000 when the scale suffix is 2 (for Thermistors). For Thermocouple channels, specifying the MIN parameter returns a value of -9.
8 Digital Communications Interface Commands suffix is 1 (for PRTs) and 9000 when the linearity suffix is 2 (for Thermistors). Specifying the DEF parameter returns a value of 0. 8.4.5.11 CALibrate: PARameter:LINearity |MIN|MAX|DEF Sets the calibration linearity parameter for the specified channel. CAL1:PAR:LIN1 5 This command only applies to PRT/Thermistor channels. Executing this command on Thermocouple channels generates a -294, "Incompatible type" error message.
1529 Chub-E4 Thermometer Readout User’s Guide the specified channel. Specifying the MIN, MAX, or DEF parameter sets the RJC parameter to the minimum, maximum, or default value respectively. This command is password-protected. To access this command, the password must be successfully entered using the SYST:PASS:CEN command (see Section 9.4.11, Password Commands). 8.4.
8 Digital Communications Interface Commands MIN, MAX, or DEF sets the lamp to the minimum, maximum, or default value respectively. 8.4.6.5 DISPlay:DECimal:FORMat? [MIN|MAX|DEF] Returns the current decimal format setting. DISP:DEC:FORM? 0 A returned value of 0 indicates a period (.) is used as the decimal separator. A returned value of 1 indicates a comma (,) is used as the decimal separator. Specifying the MIN parameter returns a value of 0. Specifying the MAX parameter returns a value of 1.
1529 Chub-E4 Thermometer Readout User’s Guide The WINDow suffix, , specifies the display set (1 to 9). The FIELd suffix, , specifies the field (1 to 8) within the display set. The response consists of two numbers separated by a comma. The first number represents the channel associated with the field. The second number represents the parameter to be displayed in the specified field. See Table 5 on page 126, Field Types, for the field types. 8.4.6.
8 Digital Communications Interface Commands The parameter is the number of measurements to be stored in the auto log during the auto log session. Specifying the MIN, MAX, or DEF parameter sets the number of measurements to auto log to the minimum, maximum, or default respectively. 8.4.7.4 LOGging:AUTomatic:FREE? Returns the number of auto log entries free and stored. LOG:AUT:FREE? 8144,16 The response consists of two numbers separated by a comma.
1529 Chub-E4 Thermometer Readout User’s Guide 8.4.7.8 LOGging:AUTomatic:PRINt [|ALL [,]] Prints the auto log entries. LOG:AUT:PRIN ALL DATA_25 1 DATA_25 2 DATA_25 3 DATA_25 4 DATA_25 1 DATA_25 2 DATA_25 3 DATA_25 4 22.676C 12:19:42 09-05-00 9.960 KO 12:19:44 09-05-00 23.220C 12:19:46 09-05-00 23.245C 12:19:48 09-05-00 22.765C 12:19:52 09-05-00 9.962 KO 12:19:54 09-05-00 23.087C 12:19:56 09-05-00 23.260C 12:19:58 09-05-00...
8 Digital Communications Interface Commands 8.4.7.12 LOGging:AUTomatic:TIMe |MIN|MAX|DEF Sets the auto log interval setting. LOG:AUT:TIM 1 The parameter can be one of the following values: 0.1, 0.2, 0.5, 1, 2, 5, 10, 30, 60, 120, 300, 600, 1800 or 3600. The units are seconds. If a value other than one listed is used, the instrument automatically selects the nearest acceptable value that is less than the value entered. Values greater than 3600 or less than 0.1 are ignored.
1529 Chub-E4 Thermometer Readout User’s Guide Note: Every time a demand log reading is stored, the first entry in the log for that stored reading is the data label and the date. All subsequent entries in the demand log consist of the channel, measurement value, units, and time. 8.4.7.16 LOGging:DEMand:LABel? [MIN|MAX|DEF] Returns the current demand log label setting. LOG:DEM:LAB? 6 Specifying the MIN parameter returns a value of 1. Specifying the MAX parameter returns a value of 25.
8 Digital Communications Interface Commands 8.4.7.20 LOGging:DEMand:STORe Stores the current measurement into the demand log. LOG:DEM:STOR If simultaneous scan mode is enabled, one reading is stored in the log for each enabled channel. 8.4.7.21 LOGging:DEMand:VALue? |MIN|MAX|DEF Returns the specified demand log entry. LOG:DEM:VAL? 10 DATA_25,2,9.961,KO,14,59,35,2000,9,5 The parameter specifies the demand log entry to return.
1529 Chub-E4 Thermometer Readout User’s Guide *IDN? HART,1529,A09001,1.11 8.4.8.2 *OPT? Returns a list of input modules installed. *OPT? PRT,TC Input module types are reported by position, top to bottom, of the two input modules. The returned example is for a 1529 equipped with one 2-channel PRT input module and one 2-channel Thermocouple input module. 8.4.8.3 *RST Sets the instrument operating parameters to defined conditions. *RST The following parameters are set when this command is issued.
8 Digital Communications Interface Commands 8.4.8.6 SYSTem:ERRor? Returns a system error message if any are present in the system error queue. SYST:ERR? 0,“No error” Each error condition produces only one error message at a time. The error queue may contain up to ten messages. The messages are reported in the order they occured. Reading a message from the queue removes the message so the next message can be read.
1529 Chub-E4 Thermometer Readout User’s Guide 8.4.9 Communication Interface Commands The communication interface commands are used for querying and setting serial port, IR, and IEEE configuration parameters. 8.4.9.1 SYSTem:COMMunicate:IR:FEED? [MIN|MAX|DEF] Returns the state of the IR port printing. Example: SYST:COMM:SER:FEED? Response: 0 A value of 1 is returned if IR port printing is enabled. A value of 0 is returned if IR port printing is disabled. Specifying the MIN parameter returns a value of 0.
8 Digital Communications Interface Commands sets the IR mode to IRDA mode. Specifying the MIN, MAX, or DEF parameter sets the IR mode to the minimum, maximum, or default value respectively. 8.4.9.5 SYSTem:COMMunicate:IR:TIMe? [MIN|MAX|DEF] Returns the IR sample period setting. Example: SYST:COMM:IR:TIM? Response: 1 Specifying the MIN parameter returns a value of 0.1. Specifying the MAX parameter returns a value of 3600. Specifying the DEF parameter returns a value of 1. 8.4.9.
1529 Chub-E4 Thermometer Readout User’s Guide SYST:COMM:SER:FDUP? 1 A value of 1 is returned if serial port echo (duplex) is ON. A value of 0 is returned if serial port echo (duplex) is OFF. Specifying the MIN parameter returns a value of 0. Specifying the MAX parameter returns a value of 1. Specifying the DEF parameter returns a value of 1. 8.4.9.10 SYSTem:COMMunicate:SERial:FDUPlex |MIN|MAX|DEF Sets the serial port echo (duplex) setting.
8 Digital Communications Interface Commands 8.4.9.14 SYSTem:COMMunicate:SERial:LINefeed |MIN|MAX|DEF Sets the state of the serial port linefeed setting. SYST:COMM:SER:LIN ON The parameter turns linefeed on (1 or ON) or off (0 or OFF). Specifying the MIN, MAX, or DEF parameter sets the linefeed to the minimum, maximum, or default respectively. 8.4.9.15 SYSTem:COMMunicate:SERial:TIMe? [MIN|MAX|DEF] Returns the serial port sample period setting.
1529 Chub-E4 Thermometer Readout User’s Guide The parameter turns the keypad lockout on (1 or ON) or off (0 or OFF). Specifying the MIN, MAX, or DEF parameter sets the keypad lockout to the minimum, maximum, or default respectively. 8.4.9.19 SYSTem:POWer:BATTery? Returns the current battery charge level. SYST:POW:BATT? 90 The returned value indicates the current percentage of charge remaining in the battery. The battery charge level is approximate and should be used only as a guideline. 8.4.9.
8 Digital Communications Interface Commands The parameter specifies the number of the desired date format. See Table 11 on page 130, Date Formats, for a list of acceptable time formats. Specifying the MIN, MAX, or DEF parameter sets the date format to the minimum, maximum, or default respectively. 8.4.10.3 DISPlay:TIME:FORMat? [MIN|MAX|DEF] Returns a number indicating the current time format. DISP:TIME:FORM? 1 The return value is either a 0 or 1.
1529 Chub-E4 Thermometer Readout User’s Guide 8.4.10.7 SYSTem:TIME? Returns the current system time. SYST:TIME? 11,43,23 The response is returned in the format, ,,. Note: The system time is always returned using 24-hour format regardless of the current time format setting. 8.4.10.8 SYSTem:TIME ,, Sets the current system time to the specified hour, minute, and second. SYST:TIME 11,43,23 The , , and parameters must all be supplied.
8 Digital Communications Interface Commands SYST:PASS:CEN:STAT? 0 The response is either 0 (disabled) or 1 (enabled). A response of 0 indicates password-protected settings cannot be accessed. A response of 1 indicates the password was successfully entered and password-protected settings can be accessed. 8.4.11.4 SYSTem:PASSword:CONVersion? [MIN|MAX|DEF] Returns the current probe password-protected state.
1529 Chub-E4 Thermometer Readout User’s Guide 8.4.12 Status Commands The status commands are used for querying and setting the state of the instrument registers. For details on the operation of the status registers refer to the IEEE-488.2 and SCPI standards. 8.4.12.1 *CLS Clears the status registers. *CLS 8.4.12.2 *ESE? Returns the Event Status Enable Register. *ESE? 255 8.4.12.3 *ESE |MIN|MAX|DEF Sets the Event Status Enable Register. *ESE 48 8.4.12.4 *ESR? Returns the Event Status Register.
8 Digital Communications Interface Commands 8.4.12.8 *TST? Performs a self-test and reports any errors that are found. *TST? 0 8.4.12.9 STATus:MEASure? Reads and clears the Measurement Status Register. STAT:MEAS? 1 The assignment of the bits in this register is as follows: bit 0: channel 1 measurement complete bit 1: channel 2 measurement complete bit 2: channel 3 measurement complete bit 3: channel 4 measurement complete bits 4-15: not used 8.4.12.
1529 Chub-E4 Thermometer Readout User’s Guide STAT:MEAS:ENAB 15 8.4.12.13 STATus:OPERation? Reads and clears the Operation Status Register. STAT:OPER? 16 The assignment of the bits in this register is as follows: bits 0-3: not used bit 4: measurement complete bits 5-15: not used 8.4.12.14 STATus:OPERation:CONDition? Returns the Operation Status Condition Register.
8 Digital Communications Interface Commands bit 4: measurement invalid bits 5-15: not used 8.4.12.18 STATus:QUEStionable:CONDition? Returns the Questionable Status Condition Register. STAT:QUES:COND? 16 The assignment of the bits in this register is as follows: bits 0-3: not used bit 4: measurement invalid bits 5-15: not used 8.4.12.19 STATus:QUEStionable:ENABle? [MIN|MAX|DEF] Returns the Questionable Status Enable Register. STAT:QUES:ENAB? 255 8.4.12.
1529 Chub-E4 Thermometer Readout User’s Guide 8.4.13 Statistical Calculation Types The statistical calculation types are listed in the following table. Table 4 Statistical Calculation Types 8.4.14 Number Type Keyword 1 Average AVE 2 Standard Deviation STD 3 Minimum MIN 4 Maximum MAX 5 Spread SPR 6 N (Number of Samples) STN Field Types The bottom portion of the main display is capable of showing up to eight fields. These fields are selectable from the following table.
8 Digital Communications Interface Commands Number Keyword Field Type 18 ALOG Logging Indicator 19 BATT Battery Percent Remaining 20 MEAS Number of Seconds Until Next Measurement Note: When the field type reference (REF) is selected, the displayed keyword changes depending on the probe type. The reference display keywords are detailed in the following table. Table 6 Reference (REF) Keywords Probe Type Keyword Description RES RIN Resistance ITS-90 ITS-SR5 RTP R(0.
1529 Chub-E4 Thermometer Readout User’s Guide 8.4.15 Conversion Types and Parameters Table 7 lists the probe types, conversion types, mnemonics, and serial port responses. Table 8 lists the conversioin types and their parameters.
8 Digital Communications Interface Commands Conversion Type Parameters TC-K VIN[mV] TC-B TC-E TC-J TC-N TC-R TC-S TC-T TC-AU/PT TC-POLY RJC, RJT, T1, ADJ1, T2, ADJ2, T3, ADJ3 RJC, RJT, T1, ADJ1, T2, ADJ2, T3, ADJ3 RJC, RJT, T1, ADJ1, T2, ADJ2, T3, ADJ3 RJC, RJT, T1, ADJ1, T2, ADJ2, T3, ADJ3 RJC, RJT, T1, ADJ1, T2, ADJ2, T3, ADJ3 RJC, RJT, T1, ADJ1, T2, ADJ2, T3, ADJ3 RJC, RJT, T1, ADJ1, T2, ADJ2, T3, ADJ3 RJC, RJT, T1, ADJ1, T2, ADJ2, T3, ADJ3 RJC, RJT, T1, ADJ1, T2, ADJ2, T3, ADJ3 RJC, RJT, mV(2
1529 Chub-E4 Thermometer Readout User’s Guide 8.4.17 Date and Time Formats The following tables list the acceptable date and time formats and their number setting.
9 Calibration PRT and Thermistor Calibration 9 Calibration Each channel of the 1529 is calibrated independently of the other channels and has its own set of calibration parameters. The 1529 should be calibrated at regular intervals to ensure that it continues to measure with proper accuracy. Calibration should only be done by qualified, authorized personnel. When the 1529 is recalibrated, all four channels are calibrated each calibration cycle.
1529 Chub-E4 Thermometer Readout User’s Guide The calibration parameters C0, C100, and C400 can be adjusted to optimize the accuracy. These password-protected parameters are accessed from the CALIBRATION function of the SYSTEM menu. 9.1.2 PRT Calibration Procedure Calibration requires adjustment of the C0, C100, and C400 parameters at three specific input resistances. If the resistances used are approximately 0Ω, 100Ω and 400Ω respectively the adjustments are independent and the procedure is simple.
9 Calibration PRT and Thermistor Calibration 9.1.3 3. Connect a 400Ω resistor (6 ppm accuracy) to the input and measure its resistance. Note the average error in the measurement. Adjust the C400 parameter by subtracting the measured error. For example, if the input is exactly 400.0000Ω and the readout shows 399.9913Ω, adjust the C400 parameter by adding 0.0087. 4. Record the date in the DATE parameter and set the DUE parameter to the desired calibration interval. 5.
1529 Chub-E4 Thermometer Readout User’s Guide 9.2 2. Connect a 10 kΩ resistor (25 ppm accuracy) to the input and measure its resistance. Note the average error in the measurement. Adjust the C10K parameter by subtracting the measured error. For example, if the input is exactly 10.00000 kΩ and the readout shows 10.00295 kΩ, adjust the C10K parameter by subtracting 2.95. 3. Connect a 100 kΩ resistor (25 ppm accuracy) to the input and measure its resistance. Note the average error in the measurement.
9 Calibration Thermocouple Calibration Table 14 Calibration Parameters Parameter Description C0 Adjusts the voltage accuracy of at 0 mV C100 Adjusts the voltage accuracy of at 100 mV CRJ Adjusts the internal RJC accuracy DATE Records the date the thermocouple channel was calibrated DUE Records the date the thermocouple channel calibration expires The calibration parameters can be accessed from the CALIBRATION function of SYSTEM menu 9.2.
1529 Chub-E4 Thermometer Readout User’s Guide sured error. For example, if the thermocouple temperature is actually 0.0°C but the 1529 reads 0.184°C, the CRJ parameter should be adjusted by subtracting 0.184. If it was previously 0.000 it should now be –0.184. 136 6. Record the date with the DATE parameter. Set the DUE date to the desired calibration interval. 7. Repeat the procedure for any other thermocouple channels.
10 Maintenance 10 Maintenance • The calibration instrument has been designed with the utmost care. Ease of operation and simplicity of maintenance have been a central theme in the product development. Therefore, with proper care the instrument should require very little maintenance. Avoid operating the instrument in oily, wet, dirty, or dusty environments. • If the outside of the instrument becomes soiled, it may be wiped clean with a damp cloth and mild detergent.
11 Troubleshooting Troubleshooting 11 Troubleshooting In case you run into difficulty while operating the 1529 system, this section provides some suggestions that may help you solve the problem. Below are several situations that may arise followed by possible causes and suggested actions you might take. 11.1 Troubleshooting The following table lists possible error messages, their causes, and suggested actions.
1529 Chub-E4 Thermometer Readout User’s Guide Problem Solution Incorrect resistance or voltage reading While attempting to measure resistance or voltage, the display shows an incorrect value or no value at all (. . . . . . . . . . ). Consider the following possibilities: Poor or incorrect connection of the probe. A common mistake is to connect the wires of the probe to the wrong terminals. Check the wiring carefully, especially when using a four-wire PRT (see Section 6.4.1).
11 Troubleshooting Downloading Auto Logged Data Message Recommended Action SYSTEMS: IR PORT FAILURE Cycle the power. SYSTEMS: BATTERY NOT INSTALLED Cycle the power. Check that the battery is properly connected. Replace the battery. CHANNELS: FAILURE Cycle the power. CALIBRATION: DUE FOR RECAL Check that the instrument date is correct. Recalibrate the instrument and set the recalibration date accordingly.
1529 Chub-E4 Thermometer Readout User’s Guide a) Set up the terminal program to use the correct COM port and baud rate. Configure the communication settings to use 8 data bits, 1 stop bit, no parity and no flow control. b) If you want to save the downloaded data to a file, configure your terminal program to capture the incoming text and save it to a text file. Refer to your terminal program’s documentation for details on how to do this. 3. Determine how many logged readings are stored in the 1529’s memory.
11 Troubleshooting Frequently Asked Questions The instrument was designed specifically as a test and measuring device. Compliance to the EMC directive is through IEC 61326-1 Electrical equipment for measurement, control and laboratory use – EMC requirements (1998). As noted in the IEC 61326-1, the instrument can have varying configurations. The instrument was tested in a typical configuration with shielded, grounded probe and RS-232 cables.
1529 Chub-E4 Thermometer Readout User’s Guide 4. How long does the battery last from full charge? About 8 hours from full charge with the backlight off. 5. How do I know when the battery is at full charge? The charging indicator LED located on the back panel displays amber while charging and then turns green when the batteries are fully charged (only when the AC adapter is connected). The front panel indicator at the bottom right shows when the batteries are in use and their approximate charge state.
11 Troubleshooting Frequently Asked Questions 11.5.3 2. What are the implications of the fast measurement mode in terms of accuracy? Accuracy is reduced when using the Model 1529 in fast measurement mode. Refer to Section 8.1.1 for a better description of the fast measurement mode and its limitations. 3.
1529 Chub-E4 Thermometer Readout User’s Guide 11.5.4 11.5.5 146 Output 1. How do I get data from the Model 1529 to my PC? Data can be transferred to your PC via an RS-232 interface or by IR communications through the use of the optional IR dongle and software available through Hart. 2. Is the IR output on the Model 1529 compatible with the IR port on my desktop laser printer? The IR port on the Model 1529 communicates with any IrDA compatible printer.
Index Index ! probe 38, 41, 139 2-wire probe 39 - 40 3-wire probe 39 - 40 4-wire probe 39 - 40 A AC adapter 21, 25 accessories 19 ASTM E1137 40 AUTO LOG 60 AUTO-CAL 35 average 33 B backlight 25, 35, 53 battery 21, 25 charging 21 baud rate 71 buttons 17, 141 C calibration 131, 141 CALIBRATION 75 CALIBRATION EXPIRED 141 Callendar-Van Dusen 40 channel selection 32 CHANNEL menu 29 CHANNEL MODE 33 CLEAR STATS 48 coefficients COMM SETUP 70 commands 80 communication 70, 79 conformity 142 contrast 17, 25, 14
Index E EDIT FIELDS 51 EDIT PROBE 36 EMC 142 ENABLE CHANNEL 32 environment 10 error 140 exit 17, 29 F fast measurement 26, 31 features 7, 17 field data 49 - 51 FIELDS menu 47 filter 33 G GPIB 79 GPIB port 72 I IEC-751 40 IEEE-488 72, 79 IR period 72 IR port 72, 142 IRDA 72 ITS-90 38 - 39 L lamp 35, 53 linefeed 71 log count 62 LOG HISTORY 56 log period 62 148 LOG STATS 66 logging 27, 60, 141 LOGGING menu 53 LOGGING OPTIONS 61 M maintenance 137 MEASURE PERIOD 30, 62 measurement 15, 25 memory 141 menu 1
Index serial number 37 SYSTEM RESET 77 type 37 wires 23, 39 - 41 PROBE menu 35 PRT 23 PT-100 40 R rack mounting 19 range resistance 39 - 41 reference junction 43, 50 reset 77 resistance 41, 50 resolution 35, 53 RJC 43 RS-232 71, 79 RTD 40 S scan 33 SELECT FIELDS 49 self-test 25, 140 sensor 23 serial interface 79 serial number 37, 69 serial period 71 serial port 71 specifications 9 START 62 statistics 48, 50 Steinhart-Hart 41 STOP 62 STORE READING 55 SYSTEM menu 69 T TEST PROBE 44 thermistor 23, 41 - 4
