Specification Sheet

KANTA N°3
Product data sheet
6
1/2
" (16.5cm) midrange
Flax cone
TMD suspension
NIC motor
Precise, detailed midrange
2 x 8" (21cm) bass
Flax cone
NIC magnetic circuit
Very deep, articulated bass
Magnetic grille
Easy handling
Kanta N°3 is the reference product for the line. This 3-way loudspeaker combines depth, impact and articulation
in the bass. The heightened midrange definition and neutrality are the result of Flax technology innovations, TMD
suspension and NIC. The latest generation IAL tweeter provides the ability to reproduce the tiniest details with
clinical precision. With a resolutely modern, ingenious design, this sound equipment will be at its best in a room
from 430 to 860ft
2
(40 to 80m
2
).
Latest generation
IAL3 Beryllium tweeter
High-density Polymer
front panel
Inert bae for enhanced
sound definition
Multi-port Powerflow
technology
No dynamic compression
Front and rear ports
Moulded multi-ply cabinet
with great neutrality
Kanta N°3, Walnut High Gloss cabinet, Black Lacquer front panel
Kanta N°3, Walnut Mat cabinet, Dark Grey Mat front panel
Key points
• Reference product for the Kanta line
• Extended bass frequency response
• Transducers integrating Focal’s latest technologies
• Speaker drivers developed and manufactured in France by Focal
• Numerous standard finishes
Type
3-way bass-reflex floorstanding loudspeaker
Drivers
2 x 8" (21cm) Flax driver with NIC motor
6
1/2
" (16.5cm) Flax midrange with TMD
suspension and NIC motor 1
1/16
" (27mm) ‘IAL3’
pure Beryllium inverted dome tweeter
Sensitivity (2,83V/1m)
91dB
Frequency Response (+/-3dB)
33Hz - 40kHz
Low Frequency Point (- 6dB)
26Hz
Nominal Impedance
8 Ohms
Minimum Impedance
3 Ohms
Recommended Amplifier Power
40 - 400W
Crossover Frequency
250 Hz - 2,500Hz
Dimensions (HxWxD)
50
25/64
x 15
13/64
x 20
15/32
" (1,280 x 386 x 520mm)
Net weight (with front grille)
101.6lbs (46kg)
Packaging dimensions (HxWxD)
58
17/64
x 19
3/32
x 29
21/64
" (1,480 x 485 x 745mm)
Total weight (including packaging)
116.1lbs (53kg)
Focal
®
is a trademark of Focal-JMLab
®
- www.focal.com - SCCG - 04/01/2021 - v1
Cabinet &
Front panel
Black Lacquer
Cabinet &
Front panel
Carrara
White
Cabinet
Walnut Mat
Front panel
Dark Grey Mat
Cabinet
Walnut Mat
Front panel
Ivory Mat
Cabinet
Walnut HG
Front panel
Black Lacquer
