Specifications Sheet

23
62,5 4,5
86
142
9,3
167
158
8x
5,5
Performance
CREATE YOUR SOUND
Focal
®
is a trademark of Focal-JMlab
®
-Tel. [phone] - www.focal.com - Images may not conform exactly to specific product. Photos L’Atelier Sylvain Madelon-SCAB-161018/1
MECHANICAL DRAWING
AUDITOR
RCX-165
• Inverted dome tweeter
• Polypropylene cone
• Steel basket
Woofer (6
1/2
")
Nominal power 60W RMS
Maximum power 120W
Sensitivity (2,83V/1m) 91.5dB
Frequency response 60Hz-21kHz
Cone type Polypropylene
Surround type Butyl
Nom. impedance 4
DC resistance 3.3
VC diameter 25mm 1"
Net weight 900g 1.98lbs
PARAMETERS
Fs 80Hz
Vas 9l
Qts 0.95
Qes 1.2
Qms 7
Re 3.3
Sd 132cm
2
Cms 0.32mm/N
Mms 12.3g
BI 4.3 N/A
SPECIFICATIONS
FREQUENCY RESPONSE/IMPEDANCE
Frequency response 0° Frequency response 30° Impedance Z
